- Page 1 FunMaster 72 Internal Bombay Kit AK-504_BB Page 1...
- Page 2 AK-504_BB Kit # Kit Contents: Laser Cut Sheets Qty. Name ..Description 1 ..LC-504-BB-01 .......3mm X 8” X 24” Laser Cut POPLAR PLY 1 .
- Page 3 Building the Internal Bombay 1...Place a small drop of thin C/A glue into the small holes in parts B-02, B-03 and B-05. This will soak into the wood to harden it. Also apply a small amount of glue to the edges near the holes.
- Page 4 5...Glue the B-07 / B-08 hinges to the B-06 doors. The B-07 on the hinges face inboard...face each other as shown. 6...Test fit the doors to the bombay. Insert the 2-56 screws and nuts not quite tight. The doors should swing freely. Sand the parts to allow the proper movement.
- Page 5 9...Cut the 1/32” x 12” music wire in half to make two 6” pieces. Make a 1/4” long 90 degree bend in one end of each wire. Cut the two 1/16” aluminum tubes to a length of 3-3/8”. 10...Slide the tubes onto the music wire. Position the tube 1/2” from the 90 degree bend and secure the tube to the wire with thin C/A glue.
