Simply Better Connections
ATEN Control System
VK112EU 12-button Keypad (EU, 2 Gang)
The VK112EU is a fully-customizable 12-button keypad designed for use with the ATEN Control System. The keypad
provides an interface to control devices in a room from a standard wall mounted faceplate. Created with flexibility in
mind, the 2-gang keypad can be laid out in 125 different combinations of 6 to 12 buttons that snap together as easy
as Lego's. By connecting to the VK2200 / VK1200 / VK2100A / VK1100A Control Box or VK0100 / VK0200 Control
Pad over a LAN, users will find it's effortless using VK6000 software to configure the desired control of any connected
device from the keypad. With the buttons ready to go, users have instant and smart control of the facilities from a
keypad or keypads that can manage any device in the room. The VK112EU is an affordable solution, perfect to serve as
the primary interface in meeting rooms, or as secondary device control in classrooms and conference centers.
White
Black
Note: This model is also available in black color
Custom button placement on the keypad can be set in 125 different combinations of 6 to 12 buttons.
1
product. To place an order, please contact your regional ATEN representative.
The example above shows the 12 most commonly used.
Part number: VK112EU1, which is a built-to-order

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VK112EU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ATEN VK112EU

  • Page 1 With the buttons ready to go, users have instant and smart control of the facilities from a keypad or keypads that can manage any device in the room. The VK112EU is an affordable solution, perfect to serve as the primary interface in meeting rooms, or as secondary device control in classrooms and conference centers.
  • Page 2 This superior flexibility facilitates system integrators who need to quickly answer to customer requirements and changes that are demanded. The VK112EU’s LAN port supports Power over Ethernet (PoE) that allows both data and electric power to be transmitted over one single Ethernet cable, eliminating the need of Single Cable Installation an extra power source and extra wiring.
  • Page 3 Simply Better Connections Installation Setup Set Keypad Layout Pair with Control Box Configure Settings Controller ID VK6000 Configurator VK2200 Software VK112EU Keypad ID Curtain Projector Projector Lighting Video Matrix Power ATEN Unizon Lift Screen Conditioning Control Swtich Projector Distribution Unit...
  • Page 4 © Copyright 2022 ATEN International Co. Ltd. Phone: 886-2-8692-6789 Fax: 886-2-8692-6767 ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. www.aten.com E-mail: marketing@aten.com...
