CHAPTER 2: PRODUCT DESCRIPTION
Order codes
DGPR – * – ** – ** – ** – ** – *** – **** – **** – **** – **** – ****
DGPR S
C
21/78 (LPS-O) Integration
50RE Integration
50/62BF Integration
DGP to G60 Setting
conversion
21/78 to G60 Setting
conversion
50RE to G60 Setting
conversion
50/62BF to G60 Setting
conversion
GPP Drawing update
GPM-S Option
64S Settings

Specifications

MULTILIN DGPR – INSTRUCTION MANUAL
This section lists the order codes for the Multilin DGPR.
The G60 order code provided in the package is
G60-UA4-HKH-F8M-H6P-M8M-P6M-U6C-WRH
For more information, see the Order Codes section in the G60 instruction manual.
Order codes are subject to change without notice. See the ordering page at
https://store.gegridsolutions.com/
Table 1 outlines order codes. As an example, with
DGPR-S-D1-RE0-BF0-GS1-DS0-RES0-BFS0-DWG0-GPM0-64S0, the D1 option means that a
Line Protection System (LPS-O) cover plate is included, while the GS1 options means that
DGP settings are to be converted to the G60 settings. That is, GE converts DGP settings and
uploads them to the G60. The LPS-O cover plate is mounted in the replacement of the LPS-
O unit when it is removed from the panel.
Table 1: DGPR order codes
D0
D1
RE0
RE1
BF0
BF1
GS0
GS1
DS0
DS1
Specifications are subject to change without notice.
G60 CONTROL POWER
high range 125 to 250 V AC/DC
low range 24 to 48 V DC
CT INPUTS-SECONDARY RATING
_____/5A
_____/1A
for the latest options.
RES0
RES1
BFS0
BFS1
DWG0
DWG1
GPM0
GPM1
300 V = Max 10 mA
300 V = Max 10 mA
ORDER CODES
Standard with G60
Custom with G60 order code specified
None
3 RU cover plate for LPS-O
None
Cover plate for 50RE relay
None
Cover plate for 50/62 BF relay
None
DGPR settings required, converted
from original DGP settings
None
21/78 as installed settings to be
integrated with G60 settings
None
50RE as installed settings to be
integrated with G60 settings
None
50/62 BF as installed settings to be
integrated with G60 settings
None
Generator protection panel (GPP) and
layout drawings update for DGPR
replacement
None
GPM-S (GPMSG + GPMSB +
204-SD-43737 CT) to be included as
ship loose items
64S0 None
64S1 64S settings to be integrated with G60
settings
