ACTIVATE G60 RELAY

Activate G60 relay

Install software

Connect G60 relay

Connect using RS232 port

26
The G60 needs to be activated by setting it to "Programmed" mode. This can be done on
the front panel of the G60 or in the EnerVista UR Setup software. The path is SETTINGS
PRODUCT SETUP > INSTALLATION > RELAY SETTINGS. For more information, see the G60
instruction manual.
Communication with the DGPR unit can be done via the front panel or a computer with
EnerVista UR Setup software.
The G60 includes EnerVista UR Setup software that needs to be installed on a computer.
Follow the procedure in the G60 instruction manual to install the software. There is no
additional software for the DGPR or its test switches.
The G60 is connected typically to a network for communication with other devices, for
example using an Ethernet port. It also connects to a computer running the EnerVista
software, either on-site using the RS232 port or remotely using an Ethernet port.
There are three ways to connect the G60:
• RS232 port
• Ethernet port
• RS485 port
The G60 has a nine-pin RS232 serial port on its front panel, as shown in Figure 29, which
makes it useful for connecting the computer to the device in the field.
