- Page 1 Terminal IF-57xx Time Recording Terminal 00-57xx-04xx...
-
Page 2: Table Of Contents
Table of contents General information......................Short description....................... Scope of delivery ...................... Target group ......................Intended use ......................Safety........................Abbreviations ......................Cable lengths and cable types.................. System overview........................Modes of operation ....................Encrypted data transfer .................... Mounting the terminal ......................Installation site ......................Fastening the back panel of the housing .............. - Page 3 UK Declaration of Conformity ................... 22 EU Declaration of Conformity ................... 22 © 2022 Interflex Datensysteme GmbH | IF-57xx Time Recording Terminal | 07.22...
-
Page 4: General Information
1 General information 1 General information 1.1 Short description Terminals of the If-57x5 series include the following functions: Contactless identification and data recording Integration in 10/100 MB Ethernet networks Power supply via PoE (Power over Ethernet) or with 18 - 24 V low-voltage Intuitive operation and clear user feedback via touch display Connection of max. -
Page 5: Intended Use
1 General information 1.4 Intended use Terminals of this series are designed for reading credentials, for transferring the recorded data to the access control system and for controlling the connected components, in accordance with the specifications in section Technical specifications Any other use is not in accordance with the intended purpose and therefore not permitted. -
Page 6: Cable Lengths And Cable Types
1 General information Electromagnetic Compatibility Electrostatic discharge Ground IEEE Institute of Electrical and Electronics Engineers NC contact Normally closed contact NO contact Normally open contact Power over Ethernet RFID Radio-Frequency Identification Shield Secure shell 1.7 Cable lengths and cable types Cable function Max. -
Page 7: System Overview
2 System overview 2 System overview Host system IF-5xxx Terminal for time and attendance recording External power supply (optional) power PoE device: Switch or power injector supply unit and fuse protection I/O connector board I/O controller board IF-800 Terminal for access control 2.1 Modes of operation Online mode In this operating mode, data is continuously exchanged between the device and the parent host... -
Page 8: Encrypted Data Transfer
2 System overview Offline mode If there is no transfer of data between the device and the parent host system (e.g. the IF-6040 system), the device will automatically switch to offline mode. There, it records all bookings and events and autonomously makes decisions based on configured conditions. In the event of a positive decision, a response and/or a signal for activating an output relay, for example, are transmitted to the booking location. -
Page 9: Mounting The Terminal
3 Mounting the terminal 3 Mounting the terminal 3.1 Installation site NOTICE Damage due to the manipulation of the terminal Manipulation of the terminal can lead to data loss. a) Install the I/O controller board in a secured area b) Secure the installation location of the I/O controller board additionally with a anti-tamper switch ... - Page 10 3 Mounting the terminal 3 bore holes for wall mounting Threaded bushing for fastening an optional 24 V interface (75-5735-0004) Threaded bolt for securing the PoE Threaded bushing for fastening an connector optional I/O controller board (75-700-0141) Bore holes for mounting via appliance Plain washer case Flush box...
-
Page 11: Mounting And Connecting The Poe Connector
3 Mounting the terminal 3.3 Mounting and connecting the PoE connector Back panel of housing Network cable Screws for fastening the PoE connector Flat conductor cable to the back panel of the housing 1. Screw the PoE connector to the threaded bolt on the back panel of the housing using both screws provided . -
Page 12: Initial Operation
4 Initial operation 4 Initial operation From a technical point of view, the terminals have an integrated controller. That is why the term Controller will be used in this section. With the appropriate accessories (see table), the following options are available for connecting the host computer to the controller: Via WLAN with the IF-ServiceApp 75-99-0013 Via service interface or USB... - Page 13 4 Initial operation 5. Start communication with Open 6. Login with username fieldservice 7. Define a password Details on valid password requirements and how to change a password can be found underUsers and passwords. Only after entering a password are the network services started and the network connection can be established.
-
Page 14: Checking And Setting Network Parameters
4 Initial operation 4.2 Checking and setting network parameters The netpar -? command lists the call parameters of the netpar command: fieldservice@IF‑xxx:~ netpar -? Display or change network parameters (legacy) Please consider using nmtui or nmcli instead. Usage: /opt/interflex/bin/netpar [OPTION] ... - Page 15 4 Initial operation fieldservice@IF‑xxx:~ netpar -x IPv4 address/netmask [172.18.12.65/16]: IPv4 gateway [172.18.70.1]: Port [2001]: Hostname [IF‑xxx]: Connection 'netpar' (e046c1c5-2eb5-4be0-8655-4f79acffc8bc) successfully deleted. Connection 'netpar' (8ff8bd2e-7229-4914-a214-3d60dc0e7f16) successfully added. Activate profile netpar Connection successfully activated (D-Bus active path: /org/freedesktop/ NetworkManager/ActiveConnection/3) Current profile: netpar IPv4 address/netmask: 172.18.12.65/16 IPv4 gateway: 172.18.70.1 IPv4 address/netmask (active): 172.18.12.65/16...
-
Page 16: Configuring The Interfaces And The Booking Memory
4 Initial operation 4.3 Configuring the interfaces and the booking memory Via the command oc -h, you can change interface settings adjust the size of the booking memory Press the Enter key to confirm values that you do not wish to change. ... -
Page 17: Listing The Configuration Data Of Terminals
4 Initial operation 4.4 Listing the configuration data of terminals The cfg command lists the configuration data of terminals. fieldservice@IF xxxx:~ cfg Terminal configuration IF xxxx/4735 IT-2018.02.0-794-g91e557d6d26e Host: Ethernet ---------------------------------------------------------------- No B A HA TNo type HWU SWU display keys read.1 read.2 In/Out I/O -- - - -- --------- ------- ----- ----- ------- ------ ------ -- 1 1 A 1 0 IF611 3.00 7.b ../.. -
Page 18: Restarting The Controller
4 Initial operation 4.5 Restarting the controller Some changes require a restart of the controller. You can do this directly on the controller or with the appropriate commands via the console. RUN LED DIP switch Reset button Warm boot A warm boot performs the following actions: Close application Restart application Associated console command: oc -s or factory-reset application-restart... - Page 19 4 Initial operation Cold boot All settings made on the controller via IF-6040 or OC Task are deleted or reset to default. System or operating system settings, such as the IP address or password, are retained. Use the cold boot during initial operation and in the event of malfunctions that cannot be remedied by other means, e.g., a warm boot.
-
Page 20: Technical Specifications
5 Technical specifications 4. Reset switch position: Associated console command: factory-reset full 5 Technical specifications Power supply Nominal voltage 18 to 24 V AC/DC Power supply via Ethernet PoE IEEE 802.3at of power class 0 (up to 13 W) Power consumption Max. 12 VA Fuse PTC resistor Equipment... -
Page 21: Disposal
6 Disposal Humidity Max. 95%, non-condensing Ambient temperature +4° C bis +40° C Dimensions (W x H x D): 163 x 87 x 45.8 mm Color Black or white Installation type Surface-mounted Cable feed Flush-mounting (surface-mounting with spacer possible) Weight 0.4 kg Housing material Thermally tempered white glass on a polycarbonate body... -
Page 22: Declarations Of Conformity
The original manual is in German. Other languages are translations of the original manual. Version: 07.22 Interflex Datensysteme GmbH +49 711 1322 - 0 Epplestraße 225 (Haus 3) interflex.info@allegion.com 70567 Stuttgart, Germany www.interflex.com © 2022 Interflex Datensysteme GmbH | All specifications are subject to change without notice.
