Annex 2: Elements configuration Lyon / C-Lyon / Zafir
1. Introduction
The steps necessary to configure the Addressable Control Panel LYON are given below.
The addressable system includes the following elements:
Addressable sensors
Addressable key
Master module
Relay modules
Technical signals module
Relay and Technical signal module
Loop isolator base
Addressable siren
Each of these elements has a programming label. This number is assigned at the factory.
When an element search operation is conducted using the control unit, it finds all the loop elements, storing the
type of element and the assigned programming number.
The basic purpose of this procedure is that, by conducting this search, all these numbers can be passed to the
control unit memory and for them to be assigned to the loop where the search was conducted.
NOTE: Before assigning a point, it is highly advisable to obtain the programming lists with all the data.
Digital fire detection control panel
LYON REMOTE PLUS
Optical sensor
Heat sensor
Optical and Heat sensor A30XHA
Multi-sensor
1 relay
2 relay
FIRE PROTECTION MANUFACTURER
C / Compositor Wagner, 8 –P.I. Can Jardí 08191 - RUBÍ (Barcelona) ESPAÑA.
Tlf.: +34 935 862 690 – cofem@cofem.com
A30XHAS A50S
A30XTA A50H
A50SH
A30XHTCO A50HSCO
PUCAY
KMAY
MDA1Y
MDA2Y
MSTAY / MSTAY8
MYOA / F
KABY
SIRAY / SIRAYL / SIRAY+BSLC
– www.cofem.com
/ I
/ I
/ I
