- Page 1 Installation Guide Corner Entry Shower Doors SP1900A Series Français, page “Français-1” Español, página “Español-1” 1034049-2-E...
-
Page 2: Tools And Materials
Tools and Materials Drill and Masking Tape Center Level Pencil & Felt Safety Glasses Assorted Tape Measure Punch Tip Marker Drill Bits Plus: • Drop Cloth 100% File Caulk Gun Claw Assorted Silicone Sealant Hammer Screwdrivers Before You Begin WARNING: Risk of personal injury. Do not cut the tempered glass. If the glass is cut, the glass will shatter and may cause personal injury. -
Page 3: Parts Identification
Wall Jamb Wall Frame Rubber Bumper Top/Bottom Track Top Corner Bumper Screw #8-18 x 3/4" Top/Bottom Track Insert Moving Panel Side Roller Screw #8-32 x 3/8" Frame Seal Fixed Panel Roller Corner Bracket Adjustment Block Adjustment Interlocking Screw Handle #8-18 x 3" Bottom Corner Plastic Bumper... - Page 4 Showerhead can Toward Wall be on either side. Pencil Outside Edge Anchor Level Wall Jamb Press and hold legs together. Receptor Size 38" (96.5 cm) x 38" (96.5 cm) Shower Base Dimension A = 35-15/16" (91.3 cm) 1. Mark and Drill the Mounting Holes Measure 35-15/16″...
- Page 5 Screwdriver Wall Mounting Screw Adjustment Block Screwdriver Wall Jamb Lip Wall #8-18 x 1-1/4" Jamb Panhead Adjustment Screw Block Hole Shower Wall Jamb Location Groove 2. Install the Adjustment Blocks Lay both wall jambs down on a flat surface with the lip facing up. Slide an adjustment block into each end of the channel of each wall jamb.
- Page 6 Track Wall Frame Adjustment Block Wall Jamb Shower Side Fixed Panel Wall Frame Adjustment Block Track #8-18 x 3" Fixed Panel Flathead Screw Shower Front Side 4. Install the Fixed Panels Slide the wall frame of the fixed panel over the wall jamb. Rest the fixed panel on the shower ledge.
- Page 7 Steel Side of Roller against Top Frame Flange #8-32 x 3/8" Roller Screw Plastic Clip Moving Panel Panel Bottom Guide Slot Frame 5. Install the Rollers to the Moving Panels Assemble two rollers on each moving panel with #8-32 x 3/8″ roller screws. Ensure the steel side of the roller is against the top frame flange.
-
Page 8: Install The Bumpers
Roller 3/4" (1.9 cm) Top Track 4" Roller (10.2 cm) Screw Bumper Roller (Top) Groove Wall Frame Wall Frame Bottom 3/4" (1.9 cm) Track Bumper (Bottom) Shower 4" Moving (10.2 cm) Panel Bottom Track Slot 7. Install the Moving Panels With the top of the moving panel angled away from you, insert the rollers into the roller groove of the top track. - Page 9 Corner Bracket #8-18 x 7/8" Screw Top/Bottom Top Track Insert Track Insert Top Corner Bumper #8-18 x 7/8" Screw Bottom Track Top Track Bottom Track Top/Bottom Track #8-18 x 7/8" Screw #8-18 x 7/8" Screw Insert (Installed) Bottom Corner Bumper Bottom Bottom Insert...
- Page 10 Side Frame Seal Interlocking Handle #8-18 x 3/8" Screw 11. Install the Handles and Seals NOTE: Perform the procedure below from inside the shower. Position an interlocking handle on the outside edge of each moving panel. Secure the interlocking handle with four #8-18 x 3/8″ screws. Attach a side frame seal to the inside edge of each moving panel with four #8-18 x 3/8″...
- Page 11 Top Track Roller Screw Moving Panel Small Adjustment Screw Interlocking Handle 12. Test and Adjust the Moving Panels Slide one of the moving panels into the closed position. Slowly slide the second moving panel into the closed position. Ensure each panel slides smoothly and the panels interlock at the corner.
- Page 12 Seal here. Seal here. Seal here. Seal here. 13. Caulk the Shower Doors CAUTION: Risk of property damage. Apply caulk or silicone sealant around the outside of the frame only. Applying caulk or silicone sealant to the inside of the door will cause leakage and damage. CAUTION: Risk of property damage.
-
Page 13: Outils Et Matériels
Guide d’installation Portes d’entrée de douche en angle Outils et matériels Crayon à Ruban- Mètre Poinçon Niveau à bulle Lunettes Perceuse et papier et feutre cache ruban de protection mèches assorties Plus: • Toile de protection Joint en Tournevis Lime Pistolet à... -
Page 14: Identification Des Pièces
Montant du mur Cadre du mur Amortisseur caoutchouc Rail supérieur/inférieur Vis d'amortisseur supérieur en angle #8-18 x 3/4" Insertion rail supérieur/inférieur Panneau amovible Joint Vis rouleau de cadre latéral # 8-32 x 3/8" Panneau fixé Rouleau Support de coin Bloc de réglage Poignée Vis de réglage... - Page 15 Pomme de douche peut Vers le mur être de chaque côté. Crayon Rebord extérieur à papier Ancrage Niveau à bulle Montant du mur Presser et maintenir les pieds ensemble. Taille du receveur 38" (96,5 cm) x 38" (96,5 cm) Dimension A = 35-15/16" (91,3 cm) Base douche 1.
- Page 16 Tournevis Vis de fixation murale Bloc de réglage Tournevis Rebord du Montant Vis #8-18 x montant du mur du mur Bloc de 1-1/4" réglage Trou Douche Montant du mur Emplacement de la rainure 2. Installer les blocs de réglage Poser les deux montants du mur sur une surface plane avec le rebord vers le haut. Glisser un bloc de réglage dans chaque extrémité...
- Page 17 Rail Cadre du mur Bloc de réglage Montant du mur Côté douche Panneau fixe Cadre du mur Bloc de réglage Rail Panneau fixe # 8-18 x 3" Douche Côté avant 4. Installer les panneaux fixes Glisser le cadre du mur du panneau fixe sur le montant du mur. Reposer le panneau fixe sur le rebord de douche.
- Page 18 Côté acier du rouleau contre la bride du cadre supérieur Vis rouleau # 8-32 x 3/8" Clip en Panneau plastique amovible Guide de Cadre panneau inférieur 5. Installer les rouleaux sur les panneaux amovibles Assembler deux rouleaux sur chaque panneau amovible avec des vis #8-32 x 3/8″. S’assurer que le côté...
- Page 19 Rouleau 3/4" Rail (1,9 cm) supérieur 4" Rouleau (10,2 cm) Butée Rainure (supérieure) rouleau Cadre du Cadre du mur Rail 3/4" (1,9 cm) inférieur Butée (supérieure) Douche 4" Panneau (10,2 cm) amovible Rainure rail inférieur 7. Installer les panneaux amovibles Avec le dessus du panneau amovible incliné...
- Page 20 Support de coin Vis #8-18 x 7/8" Rail supérieur Insertion rail Insertion supérieur/inférieur Amortisseur en angle supérieur Vis #8-18 x 7/8" Rail inférieur Rail supérieur Rail inférieur Insertion rail supérieur/inférieur Vis #8-18 x 7/8" (installée) Vis #8-18 x 7/8" Amortisseur en angle inférieur Rail inférieur Insertion...
