Coyote
S tainless
S teel
E lectric
G rill
Use
&
C are
M anual
C1EL120SM
PUT SERIES NO. LABEL HERE
For Indoor or Outdoor Use
IMPORTANT: Read all instructions before use
To installer or person assembling grill: Notate your serial number on the grill prior to use
To consumer: Keep this manual for future reference.
COYOTE OUTDOOR LIVING, INC.
www.coyoteoutdoor.com
Advertisement
Table of Contents
Related Manuals for Coyote C1ELCT21
Summary of Contents for Coyote C1ELCT21
- Page 1 Coyote S tainless S teel E lectric G rill Use & C are M anual C1EL120SM PUT SERIES NO. LABEL HERE For Indoor or Outdoor Use IMPORTANT: Read all instructions before use To installer or person assembling grill: Notate your serial number on the grill prior to use To consumer: Keep this manual for future reference.
- Page 2 Welcome & Congratulations Congratulations on your purchase of a new grill! We are very proud of our product and we are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority. Please read this manual carefully to understand all the instructions about how to install, operate and maintain for optimum performance and longevity.
-
Page 3: Table Of Contents
Table of Contents Danger • Product Specifications…..... 2 Safety Instructions ...... 3 Danger: Locating the Grill ......5 DO NOT use grill with a damaged Operations & Features ..... 7 power cord. Electrical shock can occur Care & Maintenance…..…....8 with exposure to water or another Warranty......………..…..12 liquid. -
Page 4: Product Specifications
Product Specifications 120V AC - 1300 WATTS - 11 AMPS – 60 HZ Overall dimensions: 18 1/8” (W) x 16 1/4” (D) x 11 3/8” ( H ) Cutout dimensions: 16 1/4” (W) x 15 1/4” (D) x 3 3/8” (H) Note: Measurements in pictures below are for the product. -
Page 5: Safety Instructions
Safety Instructions WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. General Safety Instructions The area surrounding your new grill should be kept clean and free from flammable liquids and other combustible materials such as mops, rags or brooms, as well as solvents, cleaning fluids, and gasoline. - Page 6 covered hand when opening the grill hood and only do so slowly to allow heat and steam to escape. 21. NEVER heat any unopened glass or metal container of food on the grill. Pressure may build up and cause the container to burst, possibly resulting in serious personal injury or damage to the grill.
-
Page 7: Locating The Grill
Locating the Grill COUNTERTOP CUT-OUT 16" CUT-OUT WIDTH SIDE CABINET 4" REAR - BACKSPLASH 15" CUT-OUT DEPTH 30" COUNTERTOP 13" TO COMBUSTIBLE FRONT " 18" MATERIALS 2" 2" SEE COUNTERTOP CUT-OUT TOP RIGHT TO COMBUSTIBLE TO COMBUSTIBLE 36" FLOOR TO COUNTERTOP SIDE VIEW FRONT VIEW... - Page 8 The hood on a Coyote grill pivots mainly on the body. If you have a wall or partition behind the unit that would block ventilation, then a minimum of 2" clearance from the back of the grill, to the wall is needed for the purpose of ventilation.
-
Page 9: Operations & Features
Wash the grate thoroughly with soapy water and a non-abrasive cloth. o Make sure to only use the Coyote spatula and toolset that came with your grill, or other high temp non-abrasive tools, to ensure no damage to the Teflon coated cooking grate. -
Page 10: Care & Maintenance
ü Never pierce foods while they are cooking on the Grill, as this will dry them out. ü Turn foods infrequently. Some chefs say that a good steak should never be turned more than once. ü Apply sugar-based sauces such as commercial barbecue sauces only during the latter stages of cooking, to prevent charring. - Page 11 Flavorizers You must clean the flavorizers after or before each use of the grill to ensure no build-up of grease can occur, which could cause a grease fire. Excessive smoke, is a good indication that there is too much grease built-up near (or on) the element. The briquettes are made of ceramic and the tray it rests in are made of 304 stainless steel.
- Page 12 8) No stainless steel polish was ever used after one of the above mentioned acts took place. Ways to Avoid Rust on your Grill: 2) Always purchase a Coyote Grill cover for your unit. This will ensure that your cover is correct fit and breathable, while providing the protection needed to keep all other contaminants off of the surface.
- Page 13 these kits, you will not polish the unit until you are done re-scratching the entire product you are working on. With a scratch kit, the goal is to literally re-scratch the entire surface, so that the original grains are replaced by your new scratched-in grains. With this practice, you must be willing to do the entire surface as you will notice a start and stop point.
-
Page 14: Warranty
Limited Warranty Coyote Outdoor warrants to the original purchaser at the original site of delivery with proof of purchase of each Coyote Electric Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below. -
Page 15: Parts Listings
or service, damages caused by flashback fire or grease fires, as set out in the Owner’s Manual. This warranty does not cover scratches, dents, corrosion or discoloration caused by weather, heat, abrasive and chemical cleaners, pool or spa chemicals, and/or any tools used in the assembly or installation of this unit. -
Page 16: Pedestal Stand
Assembly with the Pedestal Stand Assembly of the Built-In Version 14 ... -
Page 17: Permanent Post
C1ELCT21 Permanent Mount Instructions Installation Instructions: 1. Remove the 4 bolts (A) on the bottom of the stand 2. Locate the anchor plate (B) in its final position and mark your anchor points 3. Install your anchors and then secure your anchor plate to the ground 4.
