- Page 1 SM-7100 IrDA Operation manual UHF Belt-pack Transmitter CHIAYO ELECTRONICS CO.,LTD.
- Page 2 SM-7100 IrDA UHF Belt-pack Transmitter Parts and functions 1 Antenna 10 Cover release 2 LCD button 3 Menu button 11 Audio mute switch 4 Setting button 12 Battery power LED 5 Power switch 13 IrDA sensor area 6 High-impedance gain...
- Page 3 Instructions Channel synchronizing of the receiver and transmitter 630 000 FREQ 30cm 10~30cm Align infrared areas of the receiver and transmitter within 10~30cm. Changing the receiver’s channel Press the synchronizing button of the transmitter. The transmitter's LED will grow to denote transmitting the frequency to the receiver and synchronizing the channels.
- Page 4 Frequency: 470~789 MHz, Maximal power: 6 mW Frequency: 823~832 MHz, Maximal power: 7.2 mW CE declaration info: www.chiayo.com.tw/declaration.html CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw ｜ Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan Tel: 886-2-27415741 ｜ Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan Tel: 886-5-2711000 ｜...
