Summary of Contents for Chiayo SM-2100 IrDA
- Page 1 SM-2100 IrDA Operation manual UHF Belt-pack Transmitter CHIAYO ELECTRONICS CO., LTD.
- Page 2 SM-2100 IrDA UHF Belt-pack Transmitter Parts and functions 1 Antenna 5 Battery compartment 9 IrDA sensor area 2 High-impedance gain control 6 Cover release button 10 Audio input connector 3 Low-impedance gain control 7 Power switch 11 Charging contacts 4 IrDA synchronizing button 8 Battery power LED Battery installation &...
- Page 3 Instructions Channel synchronizing of the receiver and transmitter 630 000 FREQ 30cm 10~30cm Align infrared areas of the receiver and transmitter within 10~30cm. Changing the receiver’s channel Press the synchronizing button of the transmitter. The transmitter's LED will grow to denote transmitting the frequency to the receiver and synchronizing the channels.
- Page 4 CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw ｜ Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan Tel: 886-2-27415741 ｜ Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan Tel: 886-5-2711000 ｜ Fax: 886-5-5767611...
