IB-WF200HD
Manual IB-WF200HD
V. 1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IB-WF200HD and is the answer not in the manual?

Questions and answers

Related Manuals for Icy Box IB-WF200HD

Summary of Contents for Icy Box IB-WF200HD

  • Page 1 IB-WF200HD Manual IB-WF200HD V. 1.5...

  • Page 2: Table Of Contents

    Content Content ........2 Main screen ........8 Settings ......... 9 Device ........3 Browse files by directory ....11 Packing content ......3 Browse files by category ....13 Product View ......3 Music Player........14 Assembly ........4 IOS App .......

  • Page 3: Device

    Device Packing content Before assembly please check packing content: Enclosure Cover HDD screws Enclosure screws Rubber cushion PCB cover sticker Power supply USB 3.0 cable Rubber feet CD (manual) Quick installation (Multilanguage) Product View DC 5V Input USB 3.0 Reset 5.

  • Page 4: Assembly

    Assembly Open the cover Insert the HDD in the shielding Screw the shielding to the HDD. Plug the rubber cushion on top to the screws.
  • Page 5 Insert the HDD with shielding in the enclosure connecting the SATA connectors. Place the cover back on the enclosure Screw the cover to the enclosure Stick the foot stands over the screws...

  • Page 6: Technical Data

    Technical data Specification Hard Disk Any 2.5” SATA I or II HDD with 9.5 mm height Battery 2800 mAh Li-Polymer Up to 4 hours continuous streaming (depending on HDD type) USB 3.0 (USB 2.0 downwards compatible) Windows XP, Vista, 7, 8, Mac OS X 10.x File system FAT 32, NTFS support...

  • Page 7: Operation

    Apps In order to get access with your mobile device you have to download the ICY BOX Link App in your App Store (iOS) or Play Store (Android). Now connect your mobile device via WLAN to the ICY BOX IB-WF200HD.

  • Page 8: Android App

    All files Browse files on your IB-WF200HD via root directory being able to alter directory structure and execute various commands on files and directories. Music Browse files on your IB-WF200HD via categories of files and open or download Photos files. Videos...

  • Page 9: Settings

    Settings In the settings menu a couple of fundamental adjustments about the WLAN, Time, Connectivity, language etc. can be made. When accessing the settings menu the first time a user name and password will be requested. Enter user name: admin Enter password (default: admin) Tap „Login“...
  • Page 10 Select time of inactivity after which the IB-WF200HD will shut down automatically to save battery capacity. Date & Time Alter the IB-WF200HD system time and time zone manually, take over time settings from your local device (“Copy from PC”) or select automatic time settings (internet access required).

  • Page 11: Browse Files By Directory

    Change WLAN security settings The change of the default WLAN password is strictly recommended to keep your privacy secure. Return to Main Screen Select WLAN Channel or set to “Auto” Select to enable or disable (not recommended) WLAN security Enter new WLAN password here (change from default to personal is strictly recommended) To exit the dialogue without changes tap on „Cancel“...
  • Page 12 Button Description Indicates you are in the “All files” perspective of browsing files on the IB- WF200HD. Tapping on it returns you to the main screen Move one directory up Go down this directory Open document Open music file Open picture Open video file Open unknown format file Tap refreshes listing...

  • Page 13: Browse Files By Category

    A tap on the referring file’s or directory’s context menu icon opens a context menu like the following (may differ on object type): Tap to initiate to copy the referring file or directory Tap to delete the referring file or directory Tap to download the referring file to your mobile device Tap to move the referring file or directory...

  • Page 14: Music Player

    Return to Main Screen Refresh content Upload Picture or Video from mobile device’s camera Selected objects are highlighted yellow. Tap to select all. Tap to download selection to your mobile device. Cancel selection Music Player Slide to position inside the track Total time length of the track Filling of white line indicates loading status Current time position in track...

  • Page 15: Ios App

    Fast forward Next track IOS App Main screen After opening the ICY BOX Link App you will find the main screen: Select top directory Select category Select Settings On the main screen you will find a couple of buttons guiding you to the following most important...

  • Page 16: Settings

    All files Browse files on your IB-WF200HD via root directory being able to alter directory structure and execute various commands on files and directories. Music Browse files on your IB-WF200HD via categories of files and open or download Photos files. Videos...
  • Page 17 After entering the correct user name and password you will be forwarded to the settings menu: Change Device Name (same as WLAN ID) Change WLAN security settings Configure network up link Configure power saving options Change administrator’s password Firmware Upgrade Reset settings to factory Default Time Settings Restart device...
  • Page 18 Select time of inactivity after which the IB-WF200HD will shut down automatically to save battery capacity. Date & Time Alter the IB-WF200HD system time and time zone manually, take over time settings from your local device (“Copy from PC”) or select automatic time settings (internet access required).

  • Page 19: Browse Files By Directory

    Change WLAN security settings The change of the default WLAN password is strictly recommended to keep your privacy secure. Select WLAN Channel or set to “Auto” Select to enable or disable (not recommended) WLAN security Enter new WLAN password here (change from default to personal is strictly recommended) To exit the dialogue without changes tap on „Cancel“...
  • Page 20 Button Description Indicates You are in the “All files” perspective of browsing files on the IB- WF200HD. Tapping on it returns you to the main screen Move one directory up Go down this directory Open document Open music file Open picture Open video file Open unknown format file Tap refreshes listing...

  • Page 21: Browse Files By Category

    A tap on the referring file’s or directory’s context menu icon opens a context menu like the following (may differ on object type): Tap to initiate to copy the referring file or directory Tap to delete the referring file or directory Tap to download the referring file to your mobile device Tap to move the referring file or directory...

  • Page 22: Music Player

    Refresh content Selected objects are highlighted yellow. Tap to select all. Tap to download selection to your mobile device. Cancel selection Music Player Slide to position inside the track Total time length of the track Filling of white line indicates loading status Tap to get back to previous browse screen Current time position in track Control icons...
  • Page 23 Button Description Previous track Rewind Play Pause Fast forward Next track...

  • Page 24: Gpl Statement

    GPL Statement License information for the software used in the unit. This product contains Free Software which is licensed under the GNU General Public License version 2 or greater. After you purchase this product, you may procure, modify or distribute the source code of the GPL/LGPL software that is used in this product.
  • Page 25 TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION 0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The "Program", below, refers to any such program or work, and a "work based on the Program"...
  • Page 26 executable. However, as a special exception, the source code distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompa- nies the executable.
  • Page 27 IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION. 12.
