- Page 1 Washing Machine User Manual WR84PB44DG Document Number= 2820526359_EN/ 01-11-17.(16:49)
- Page 2 Dear Customer, Please read this user manual first! Thank you for preferring a Beko product. We hope that you get the best results from our product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
CONTENTS 1. General safety instructions 1.1 Children's safety ...........................5 1.2 Product safety ..........................6 1.3 Electrical safety..........................6 1.4 Hot surface safety ........................7 1.5 Other ..............................7 2. Instructions for environmental protection 2.1 Compliance with WEEE Directive ..................8 2.2 Disposing of the waste product ................... 8 2.3 Package information ......................... - Page 4 8.4.5 When the detergent and/or softener run(s) out: ..............32 8.4.6 Adding detergent or softener to the wrong compartment: ..........32 8.4.7 Choosing the detergent ........................32 8.4.8 Adjusting detergent amount ......................33 8.4.9 Using tablet and capsule liquid detergents ................33 8.4.10 Using starch............................33 8.4.11 Using limescale remover ......................... 33 8.4.12 Using bleaches ...........................
-
Page 5: General Safety Instructions
1. General safety instructions 1.1 Children's safety • Children under the age of should be kept away unless continuously supervised. • This product can be used by children at and WARNING! above years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are supervised or trained on the safe usage of the product and... -
Page 6: Product Safety
1.2 Product safety • Unplug the product when not in use. • Always have the installation and repairing procedures carried out by the Authorised WARNING! Service Agent. • Do not force open the locked loading door. The door will open immediately after the washing cycle has ended. -
Page 7: Hot Surface Safety
1.4 Hot surface safety • The glass of the loading door gets too hot while washing at high temperatures. Therefore, especially do not allow children touch the glass WARNING! while washing. 1.5 Other • Do not use combustible, flammable and other similar chemicals for product cleaning or other purposes. -
Page 8: Instructions For Environmental Protection
2. Instructions for environmental protection 2.1 Compliance with WEEE Directive This product does not contain harmful and forbidden materials described in the "Regulation on the Control of the Waste Electrical and Electronic Equipment" issued by T.R. Ministry of Environment and Urbanization. It complies with the WEEE Directive. 2.2 Disposing of the waste product This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. -
Page 9: What You Can Do For Energy Saving
2.4 What you can do for energy saving • Comply with the information in the programme and consumption table section. - If the washing machine is overloaded, its washing performance will drop. CAUTION! - Moreover, noise and vibration problems may occur. Following information will help you use the product in an ecological and energy-efficient manner. -
Page 10: Intended Use
Intended use a) This product has been designed for domestic use. b) It is not suitable for commercial use and it must not be used for anything other than its intended use. c) Suitable for textile washable in washing machines. d) The manufacturer waives any responsibility arisen from incorrect usage or transportation. -
Page 11: Your Product
4. Your product 4.1 Overview 1- Power cable 2- Upper table 3- Control panel 4- Water discharge hose 5- Loading door 6- Filter cap 7- Adjustable feet 8- Detergent drawer EN / 11 Washing Machine / User’s Manual... -
Page 12: Package Contents
4.2 Package contents Power cable Water discharge hose Transportation safety bolts Mains water inlet hose User manual Plastic plug assembly • Figures in this manual are schematic and may not match the product exactly. NOTE EN / 12 Washing Machine / User’s Manual... -
Page 13: Control Panel
4.3 Control panel WR84PB44DG Lingerie Cottons Anti Allergy Cottons Eco On / Shirts Synthetics Fast+ Temperature Daily Quick StainExpert Super Short Spin Time Delay Dark Care Mixed Fabrics Sports Woollens Down Wear Delicates Night Extra Start / AutoDosing Mode Rinse... -
Page 14: Screenshot
4.4 Screenshot Temperature indicator 2 - Temperature symbol 3 - No water symbol 4 - Programme follow-up indicator 5 - Quick wash indicator 6 - Duration information Auxiliary functions light 1 8 - Dosing symbols 9 - Auxiliary functions light 2 10 - Delayed start enabled symbol 11 - Door lock is engaged symbol 12 - Child lock enabled symbol 13 - Auxiliary functions light 3... -
Page 15: Technical Specifications
5.Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Beko Model name WR84PB44DG Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 0,915 Energy consumption of the standard 60°C cotton programme at partial load (kWh) -
Page 16: Installation
6. Installation 6.1 Appropriate installation location • Damaged products cause risks for your safety. - Prior to installation, visually check if the product has any defects on it. WARNING! - If so, do not have it installed. • Do not place the product on a floor without sufficient capacity to carry the load. - Otherwise, the product or the floor may be damaged. CAUTION! - Total weight of the washing machine and the dryer -with full load- when they are placed on top of each other is... -
Page 17: Removing Packaging Reinforcement
6.2 Removing packaging reinforcement • Seek someone's help for this procedure. - Risk of getting injured. CAUTION! To remove the packaging reinforcement; a) Tilt the product backwards. b) Remove the packaging reinforcement by pulling the ribbon. EN / 17 Washing Machine / User’s Manual... -
Page 18: Removing Transportation Safety Bolts
6.3 Removing transportation safety bolts • Remove the transportation safety bolts before operating the product! - Otherwise, the product will be damaged. CAUTION! a) Loosen all transportation safety bolts with an appropriate wrench until they turn freely. b) Remove transportation safety bolts by turning them gently. c) After removing bolts, close the holes with plugs provided in the user manual bag. -
Page 19: Connecting Water Supply
6.4 Connecting water supply • The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). (It is necessary to have 10 – 80 litres of water flowing from the fully open tap per minute.) CAUTION! - Attach a pressure reducing valve if water pressure is higher. • Do not use old or used water inlet hoses on the new product. - It may cause stains on your laundry. • Do not plug the product's cold water inlet to hot water outlet. -
Page 20: Connecting The Water Draining Hose To The Drain
6.5 Connecting the water draining hose to the drain • Attach the end of the drain hose directly to waste water drain, washbasin or bathtub. • Do not contact the discharged water. Risk of being burnt as the water may be hot. CAUTION! • Fix the water drain hose end completely to prevent risk of dislocation. a) Connect the water drain hose to a minimum height of 40 cm and a maximum height of 100 cm. b) The product may fail if water drain hose is at or close to floor level (under 40 cm) as it would take water in and out continuously. -
Page 21: Adjusting The Feet
6.6 Adjusting the feet • Adjust feet so that the product will be balanced on the location it will be used. - Balance the machine by adjusting the feet. CAUTION! - Check for any play by pressing the product from upper diagonal edges. - Otherwise, the product may move from its place and cause crushing and vibration problems. -
Page 22: Electrical Connection
6.7 Electrical connection • Damaged power cables must be replaced by the Authorised Service Agents. DANGER! a) Connect the product to a grounded outlet protected by a 16 A fuse. • Our company shall not be liable for any damages that will arise when the product is used without grounding in NOTE accordance with the local regulations. • If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified electrician install a 16 Amp fuse. • Do not make connections via extension cables or multi- plugs. b) Connection must comply with national regulations. c) The wiring for the electrical outlet circuit must be sufficient to meet the appliance requirements. -
Page 23: Electrical Requirements
6.8 Electrical requirements a) Before you insert the plug into the wall socket make sure that the voltage and the frequency shown in the rating label corresponds to your electricity supply. b) We recommend that this appliance be connected to the mains supply via a suitable switched and fused socket in a readily accessible position. -
Page 24: Fitting A Different Plug
6.9 Fitting a different plug As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals on your plug, proceed as follows: a) Connect the green - yellow or green (earth) wire to the terminal in the plug marked ‘E’ or with the symbol coloured green and yellow or green. -
Page 25: Initial Use
7. Initial use 7.1 Drum cleaning • Apply drum cleaning without any laundry in the product. NOTE a) Use the Drum Cleaning programme. b) Set the temperature to the level recommended on the special drum cleaning agent package which can be provided from Authorised Service Agents. c) Before starting the programme, put 1 pouch of special drum cleaning agent (if the special agent could not be supplied, put max. 1 teaspoon of (max. 100 g) of powder anti-limescale) into the main wash detergent compartment. -
Page 26: Preparing To Wash
8. Preparing to wash 8.1 Sorting the laundry a) Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. a) Follow instructions on the garment tags. a) Do not wash colours and whites together. New and dark coloured cottons may release a lot of dye. -
Page 27: Preparing Laundry For Washing
8.2 Preparing laundry for washing a) Remove the metal pieces such as support wire, belt buckle or metal buttons or wash the clothes by putting them in a laundry bag or pillow case. b) Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out before washing. -
Page 28: Using Detergent And Softener
8.4 Using detergent and softener 8.4.1 Detergent drawer The detergent drawer is composed of three compartments: – (1) Liquid detergent compartment – (2) Powder detergent compartment – (3) Softener compartment 8.4.2 Detergent, softener and other cleaning agents • When using detergent, softener, starch, fabric dye, bleach and descaling agents to be added through the detergent NOTE container 2, read the manufacturer's instructions written on the package and follow the dosages specified. -
Page 29: Auto Dosing
a) Add detergent and softener before starting the washing programme. b) Place the detergent bag or the dispensing ball directly among the laundry in the product. c) There is no pre-wash compartment or pre-wash option in your product. • Close the detergent drawer before starting the washing programme and never open the drawer while the product is running. - Page 30 c) When adding liquid detergent or softener, do not exceed the tip of the «Max» label. d) Close the lid. e) Close the detergent drawer by pushing it slowly. f) After closing the detergent drawer, the flashing dosing symbol ( ) will start to light up steadily. g) This indicates that the components are filled and the drawer is closed.
-
Page 31: Dose Selection And Cancellation Or Powder Detergent Use
8.4.4 Dose selection and cancellation or powder detergent use a) For some programmes of the machine, liquid detergent could not be selected. In such cases, powder detergent should be used. Please see the Programme Table for details. b) After selecting the temperature, spin speed and auxiliary function, start the programme by pressing the started/pause button. -
Page 32: When The Detergent And/Or Softener Run(S) Out
c) If the liquid detergent symbol is off, this means that you can wash your laundry with powder detergent. d) If the softener symbol is off, this means no softener will be used in the rinsing step. The first position on the display: means liquid detergent is active, softener is on. -
Page 33: Adjusting Detergent Amount
8.4.8 Adjusting detergent amount a) The amount of washing detergent to be used depends on the amount of laundry, the degree of soiling and water hardness. b) Do not use amounts exceeding the dosage quantities recommended on the detergent package to avoid excessive foam and poor rinsing. c) Use lesser detergent for small amounts or lightly soiled clothes. 8.4.9 Using tablet and capsule liquid detergents a) If tablet is a capsule with liquid detergent, put it directly into the drum before washing. -
Page 34: Programmes And Auxiliary Functions
9. Programmes and Auxiliary Functions 9.1 Programme selection • Programmes are limited with the highest spin speed appropriate for that particular type of fabric. NOTE • When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature. • Always select the relevant lowest required temperature. Higher temperature means higher electricity consumption. a) Select the desired programme with the Programme Selection button. • If no programme is started or no key is pressed within 10 minute during programme selection process, the product NOTE... -
Page 35: Programmes
9.2 Programmes • You can see laundry type and washing suggestions on clothing tags. NOTE • Cottons Eco Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other programmes, it provides high energy and water savings. Actual water temperature may be different from the stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), periods in programme stages may automatically get shorter. - Page 36 "Woolens programme of this machine is approved by “The Woolmark Company” for washing machine-washable woolen products provided that the products are washed in accordance with the instructions on the product tag and the instructions published by the manufacturer of this machine. " M1325”...
- Page 37 • Spin+Drain Use to drain the water in the product. • Rinse Use when you want to rinse or starch separately. • Shirts This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics altogether. It reduces wrinkles. When the "Quick Wash" setting button is pressed, the Pre-treatment algorithm is executed.
- Page 38 • StainExpert The machine has a special stain programme which enables the removal of different types of stains in the most effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate and pigmenting clothes and laundry in this programme. Before washing, garment tags should be checked (recommended for cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes, bed sheets, duvet covers, pillowcases, bath-beach towels, towels, socks, cotton...
- Page 39 Coffee Fruit juice Ketchup When the "Quick Wash" button is pressed twice Red wine Starch Coal • Select the stain programme. • Select the stain you want to clean by locating it in the groups above and using the "Quick Wash" setting button. For detailed information, see the Programme settings section. • Read the garment tag carefully and ensure that correct temperature and spin speed are selected. • Down Wear Use this programme to wash your coats, vest, jackets etc. containing feathers with a "machine-washable"...
-
Page 40: Programme Table
9.3 Programme table Auxiliary functions Selectable temperature Programme range °C 2,40 1400 • Cold-90 • • • 1,70 1400 • Cold-90 • • • Cottons 0,85 1400 • • • • Cold-90 0,55 1400 • Cold-90 • • • 60** 0,915 1400 •... - Page 41 ** “Cotton Economic 40°C" and "Cotton Economic 60°C" are standard programmes. These programmes are known as "40°C cotton standard programme" and "60°C cotton standard programme" and indicated with the symbols on the panel. • Water and power consumption may vary from the above table subject to the changes in water pressure, water NOTE hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage. • You can see the washing time of the programme you have selected on the display of the product.
-
Page 42: Auxiliary Function Selection
9.4 Auxiliary function selection • When you try to change an auxiliary function that is not allowed to be selected with the current programme, NOTE indicator light of the relevant auxiliary function will not flash, only an audio warning is given. Frames of available options will be lit. • If a second auxiliary function conflicting with the first one is selected before starting the product, the function selected first will be canceled and the second auxiliary function selection will remain active. • An auxiliary function that is not compatible with the programme cannot be selected. -
Page 43: Auxiliary Functions
9.4.1 Auxiliary functions • Extra Rinse This function enables the product to make another rinsing in addition to the one already made after the main wash. Thus, the risk for sensitive skins (babies, allergic skins, etc.) to be effected by the minimal detergent remnants on the laundry can be reduced. -
Page 44: Functions/Programmes Selected By Pressing The Function Buttons For
9.4.2 "Functions/Programmes Selected by Pressing the Function Buttons for 3 Seconds" • Drum Clean 3’’ • This is not a washing programme. It is a maintenance programme. • Do not run this programme when there are any objects in CAUTION! the machine. If you try to do so, the machine detects that there is a load inside and aborts the programme. Press and hold the auxiliary function button 1 for 3 seconds to select the programme. - Page 45 • Auto Dosing Setting You can enable this function by pressing the auxiliary function key 3 for 3 seconds. With this function, the dosing amounts of the Liquid Detergent and Softener are changed. Changing the dosing amounts of Liquid Detergent and Softener: a) Press and hold Auxiliary Function button 3 for 3 seconds. b) You can press the “Temperature” selection button to change the liquid detergent dosing levels as below.
- Page 46 • Child Lock 3’’ Use Child Lock function to prevent children from tampering with the product. Thus you can avoid any changes in a running programme. • You can switch on and off the product with On / Off button when the Child Lock is active. When you switch on the NOTE product again, programme will resume from where it has stopped.
-
Page 47: Programme Setting
10. Programme setting 10.1 Temperature selection a) Whenever a new programme is selected, the recommended temperature for the selected programme appears on the temperature indicator. b) To decrease the temperature, press the Temperature Adjustment button. Temperature will decrease gradually. c) It turns back to the beginning after "Cold" option and arrives at the highest temperature selectable according to the programme. -
Page 48: Quick Wash Setting (Fast+)
• Rinse Hold If you are not going to unload your clothes immediately after the programme completes, you can use rinse hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled when there is no water in the machine. -
Page 49: Starting The Programme
10.4 Starting the programme a) Press Start / Pause button to start the programme. b) Programme follow-up light showing the startup of the programme will turn on. 2 45 10.5 Programme steps a) The symbols below appear on programme follow-up indicator after the programme starts. -
Page 50: End Of Programme
10.6 End of programme a) "End" symbol appears on the display when the programme is complete. 2 45 • If you do not press any button for 10 minutes, the product will turn off automatically. Display and all indicators are NOTE turned off. • Completed programme steps will be displayed if you press On / Off button. b) Remove your laundry. c) Switch off the product by pressing and holding the On/Off button for 3 seconds. -
Page 51: Programme Options
11. Programme options 11.1 Setting the end time • Do not use liquid detergents without a liquid cup when you activate End Time function. There is the risk of staining of NOTE the clothes. • When the End Time selection is completed, the time appears on the display is the end time chosen plus the duration of the selected programme. a) With the End Time function, the startup of the programme can be delayed up to 24 hours. After pressing End Time button, the programme's estimated ending time is displayed. -
Page 52: Cancelling The End Time Setting
Adding laundry during End Time countdown. a) Press the Start / Pause button. b) The loading door will open and the door symbol on the display will go off. c) Open the loading door and add laundry. d) Close the loading door. f) Press the Start / Pause button. -
Page 53: Cancelling The Programme
c) If the water level in the machine is suitable, the door lock will be deactivated and the door will open, allowing you to add garments. The door lock icon on the display goes off when the door lock is deactivated. -
Page 54: Additional Features
12. Additional features 12.1 Activating and deactivating the audio warning a) Press and hold 1st and 2nd auxiliary function buttons for 3 seconds to activate and deactivate the audio warning. b) Programme selection display on the panel will count down as “3, 2, 1”. c) If the audio warning is active it will be deactivated and vice versa. 12.2 Loading door lock a) Press Start / Pause button to lock the loading door for safety purposes after starting any process. -
Page 55: Opening The Loading Door In Case Of Power Failure
12.2.1 Opening the loading door in case of power failure: • In case of power failure, you can use the loading door emergency handle under the pump filter cap to open the NOTE loading door manually. • To avoid any water overflow before opening the loading door, make sure there is no water left inside the machine. WARNING! a) Open the pump filter cap. b) Release the loading door emergency handle located at the rear side of the filter cap. -
Page 56: Maintenance And Cleaning
13. Maintenance and cleaning 13.1 Cleaning the detergent drawer 13.1.1 When to clean a) If you see hardened, viscous detergent or softener when you open the dosing container lid, b) If you are not satisfied with the washing results (the detergent or softener may not be taken into the washing medium since it is hardened), c) If the liquids in the compartment do not decrease for a long time... -
Page 57: Cleaning
13.1.2. Cleaning: Before cleaning, press the On/Off button to switch of the product and unplug it. • It is recommended for you to wear a glove to avoid contacting the detergent you will take out of the NOTE detergent drawer and other washing agents. a) Press the blue part in the middle of the detergent drawer and then pull the drawer towards yourself to take it out. -
Page 58: Cleaning The Loading Door
g) Use a flat screwdriver to remove the tabs holding the upper cover of the detergent drawer (there are 6 tabs in total: two on the right side of the drawer, two on the left and two at the back) and wash the inside of the drawer. -
Page 59: Cleaning The Water Intake Filters
13.4 Cleaning the water intake filters There is a filter at the end of each water intake valve at the rear of the product and also at the end of each water intake hose where they are connected to the tap. These filters prevent foreign substances and dirt in the water to enter the product. -
Page 60: Cleaning Dirty Filters
13.5.1 Cleaning dirty filters • Temperature of the water inside the product may rise up to 90ºC. To avoid the risk of scalding, clean the filter after the water inside the product has cooled down. CAUTION! a) Unplug the product. b) Open the filter cap. c) Proceed as follows for draining water. - Pull the emergency draining hose out from its seat. -
Page 61: Troubleshooting
14. Troubleshooting Problem Cause Solution Programs do not Start / Pause / Cancel button is • Press Start / Pause / Cancel button. not pressed. start after the It may be difficult to close • Reduce the amount of laundry and make loading door is sure that the loading door is closed the loading door in case of... - Page 62 Problem Cause Solution No water can be Water is inside the invisible • This is not a failure. part of the product. seen in the product during washing. Loading door cannot Loading door lock is activated • Drain the water by running the Pump or because of the water level in Spin programme.
- Page 63 Problem Cause Solution Programme There is unbalanced load in the • Automatic unbalanced load detection system is activated due to the product. time does not unbalanced distribution of the laundry in countdown. (*) the product. Product does not There is unbalanced load in the • Automatic unbalanced load detection product.
- Page 64 Problem Cause Solution Washing Odours and bacteria layers • Leave the detergent drawer as well as the loading door of the product ajar are formed on the drum as a performance is result of continuous washing after each washing. Thus, a humid poor: Clothes smell at lower temperatures and/or environment favorable for bacteria...
- Page 65 Problem Cause Solution Detergent residue Detergent was put in wet • Dry the detergent drawer before putting in detergent. drawer. in the detergent drawer. (**) Detergent has gotten damp. • Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 66 Problem Cause Solution Laundry remains Excessive foam has occurred • Use recommended amount of detergent. and automatic foam wet at the end of absorption system has been the programme. (*) activated due to too much detergent usage. (*) The product does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the product and to its surrounding environment.
- Page 67 Service once the manufacturers guarantee has expired. If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee agreement document. Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Beko Customer Help-Line. Tel: 0845 600 4911 e-mail:service@beko.co.uk...
- Page 68 Guarantee Washing Machine Your new Beko product is guaranteed against the cost of breakdown repairs for twelve months from the date of the original purchase. What is covered? • Repairs necessary as a result of faulty materials, defective components or manufacturing defect. • The cost of functional replacement parts, but excluding consumable items. • The labour costs of a Beko approved repairer to carry out the repair. What is not covered? • Transit, delivery or accidental damage or misuse and abuse.
