- Page 1 YSC-8331 USER MANUAL XI’AN TYPICAL INDUSTRIES CO.,LTD.
-
Page 2: Table Of Contents
Contents Page Notice Work environment Notice of installation Notice of safety Power Connection Single phase 220V power connection Three phase 380V power connection Connector Diagram Function of Operation Box Operation of the Normal Function Free sewing mode Bar tacking mode Program mode Parameter setup Parameter recover... -
Page 3: Notice
1. Notice YSC-8331 is used in system of industry sewing machine. For perfect operation and safety, installation and operation must be supervised by professional. 1.1 Work environment ▲ Please use 220V AC in ±10% ranges. ▲ To avoid the false operate, please keep the product away from the high electromagnetic interference. -
Page 4: Power Connection
2. Power Connection 2.1 Single phase 220V power connection Ground wire (green & yellow) must be grounding. 2.2 Three phase 380V power connection... -
Page 5: Connector Diagram
3. Connector Diagram Attention: for direct-driven is safety SW., and for belt-driven is Synchronizer. -
Page 6: Function Of Operation Box
4. Function of Operation Box P107 operation box diagram Operation Function Double start tacking, A is the stitches of forth sewing; B is the stitches of back sewing. They are both in range 1~15. Start Tacking Selection Single start tacking, A is the stitches of forth sewing;... - Page 7 ▲ Once the pedal is stepped forward, F, G stitches will be completed with E times. ▲ Constant-Stitch Sewing will perform the Program Sewing number of segments and times as setting, when the stitches are zero, machine will stop immediately. ▲...
-
Page 8: Operation Of The Normal Function
5. Operation of the Normal Function 5.1 Free sewing mode If either is enable, then the mode is free sewing. to enable or disable the start tacking. to enable or disable the end tacking. Turning wheel button clockwise or anticlockwise to move the cursor, push wheel button to twinkle the parameter want to modify, then turning wheel button clockwise or anticlockwise to change parameter, push wheel button to save the change, or push... -
Page 9: Bar Tacking Mode
5.2 Bar tacking mode is enable, then the mode is bar tacking. Turning wheel button clockwise or anticlockwise to move the cursor, push wheel button to twinkle the parameter want to modify, then turning wheel button clockwise or anticlockwise to change parameter, push wheel button to save the change, or push to cancel change. -
Page 10: Program Mode
5.3 Program mode is enable, then the mode is program mode. Change “Seg” parameter to select the segment which wants to setup. Each segment can use to enable or disable the start tacking. Each segment can use to enable or disable the end tacking. -
Page 11: Parameter Setup
5.4 Parameter setup Press can enter the parameter menu, press it again will back to sewing mode interface. See the picture above, the current cursor is under “S”, which indicates the parameter type, push wheel button to twinkle the “S”, then can change the type you want, total 9 types can be selected: speed parameter timing parameter... -
Page 12: Parameter Recover
5.5 Parameter recover When in parameter menu, if cursor move to the first word, push wheel button can enter parameter recover function. Two choices can be made, recover to “Last value” or “Default value”. After select, push wheel button will display “Are you sure?”, push wheel button again to confirm, push will back to last step. -
Page 13: General Parameter Table (Part)
6. General Parameter Table (part) 6.1 Speed parameter Name Range Default Description 500~5000 Max speed 4000 Maximum speed. (s/m) 150~500 Min speed Minimum speed. (s/m) Speed of start 500~2500 2000 Speed of start tacking. tacking (s/m) Speed of end 500~2500 2000 Speed of end tacking. -
Page 14: Enable Parameter
Release time of the REV SOL. 1~200 RVS release time Decrease parameter (ms) Increase parameter Delay time of 1~200 Timing before the wiper solenoid act. wiper (ms) Action time of 1~200 Timing for the wiper solenoid action. wiper (ms) Delay time of foot 1~500 Timing before the foot lifter solenoid is lifter... - Page 15 set to “ON”, the switch is reverse switch at sewing and is stitch correction switch at stop. When set to “ON”, enable the reverse and stitch correction switch both are Stitch valid. When set to “OFF”, disable the correction with ON~OFF double key be valid at the same time, double button...
-
Page 16: Degree Parameter
start tacking of constant-stitch sewing will C-S sewing automatically after the start tacking is finished when it is “ON”. When it is “OFF” or disable the automatic sewing mode, machine will stop automatically after the start tacking is finished. It is valid only for constant-stitch sewing. If enable automatic sewing mode, the tacking trimming... -
Page 17: Special Parameter
0～359 Up lever Up lever degree. (°) 0～359 Down lever Needle bar down degree. (°) 0～359 Trimmer act Trimmer act degree. (°) Trimmer 0～359 Trimmer release degree. release (°) 0～359 Reverse act Reverse SOL. act degree. (°) Reverse 0～359 Reverse SOL. act release degree. release (°) 0～359... - Page 18 When O06 is “ON”, the Foot Foot lifter release solenoid will released 5~30(s) time automatically after time desired. The duty cycle of PWM for signal of 10~99 reverse solenoid. The power will be Duty of RVS output greater if this value is bigger, at the same time, the heat is more.
-
Page 19: Important Parameter
“ON” to enable the safety switch Safety SW. enable ON~OFF function. Motor driven mode 0: belt driven; 1: direct driven. Motor rotate 0: clockwise; 1: anticlockwise. direction Running time of 1~60(s) The running time of aging test. aging test Idle time of aging 1~60(s) The idle time of aging test. - Page 20 Balance position’s 250~3300 voltage of pedal 1100 (mV) output Foot lift position’s 250~3300 voltage of pedal (mV) output Trimming position’s 250~3300 voltage of pedal (mV) output Schmitt voltage of 0~500 pedal output (mV) Kp of velocity loop 0~9999 4000 regulator Kp gain scale of velocity loop 0~99...
-
Page 21: Network Parameter
Stop terminal 20~100 velocity (s/m) 6.7 Network parameter 6.8 USB parameter 6.9 Admin parameter Name Range Default Descriptions Speed parameter When “ON”, speed ON~OFF lock enable parameters can’t be modified. Time parameter When “ON”, time ON~OFF lock enable parameters can’t be modified. Enable parameter When it is “ON”, the enable ON~OFF... -
Page 22: Signal Checking
Bus over current Check the load. Load is too heavy Check the load. Position check error Check synchronizer, see 8.2. Encoder error Check encoder, see 8.4. Machine type error Check identifier, see 8.6. Trimmer SOL. error Check SOL. whether direct short. REV SOL. - Page 23 8.4 Motor encoder Turn the hand wheel by hand equably, display the encode count and hall signal of motor, range is 0~7. If the fault state appeared, then display “ERRO”. Display code Descriptions QEI: The encode count of motor. The hall’s range is 0~7, If the fault state appeared, then Hall: display E.
- Page 24 Phase A current sample value. Phase B current sample value. 8.14 Degree First to setup zero point, use to change degree type, turn hand wheel equably, display the current degree. Zero Index Turn hand wheel to top dead center, and then press wheel button to set zero degree point.
- Page 25 Display code Descriptions Fault code AC voltage Bus voltage VCC voltage The main control voltage. Sol. voltage The solenoid control voltage. Current Id Current Iq R_speed Reference speed. F_speed Feedback speed. Degree Date Time...
- Page 26 ： No.1 Taibai South Road, Xi’an, P.R.China 710068 Tel：+86-29-88279162 88279163 Fax：029-88279161 83911111 E-mail: typical@chinatypical.com Http://www.chinatypical.com...
