Compaq Evo D310 MT Supplementary Manual

Compaq Evo D310 Microtower
Illustrated Parts Map
Compaq Evo Family of Personal Computers
Microtower Models
s
b

System Unit

1 Access panel
2 Chassis
3 Power supply, PFC, worldwide
4 Front bezel assembly includes plain front bezel,
5 1/4" bezel blank, and bezel insert for EMEA and
Blue Angel use only
* Front bezel assembly includes silver front bezel,
5 1/4" bezel blank, and bezel insert supporting 2
USB and 2 audio ports
* Not shown

Mass Storage Devices

1 20 GB\5400 RPM Hard drive
20 GB\7200 RPM Hard drive
* 40 GB\5400 RPM Hard drive
* 40 GB\7200 RPM Hard drive
* 60 GB\5400 RPM Hard drive
* 80 GB\7200 RPM Quiet hard drive
2 48X CD-ROM drive
* 16/10/40/12X CD ROM drive
* 40/10/40 CDRW drive
* 16X DVD drive
* DVD R/RW
3 Diskette drive
* Not shown
© 2002, 2005 Hewlett-Packard Development Company, L.P
Compaq, the Compaq logo, Evo, HP and the HP logo are
trademarks of Hewlett-Packard Development Company,
Intel, Celeron, and Pentium are trademarks of Intel
Corporation in the United States and other countries.
All other product names mentioned herein may be
trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided "as is" without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional

Cables

* Front panel audio cable
* Front panel USB cable
* Audio cable for CD
not spared
1 Diskette drive cable
not spared
2 Hard drive/CD-ROM cable, 10", dual device
277979-001
* Hard drive/CD-ROM cable, 14", dual device
299170-001
*Not shown
299171-001
Keyboards (not illustrated)
Easy Access Keyboard, PS2
Connector
Arabic
Belgian
Danish
Finnish
French
Italian
International
Latin American Spanish
Norwegian
People's Republic of China -AA1
249408-001
260671-001
236921-001
286692-001
286693-001
250185-001
232320-001
281749-001
286711-001
278647-001
250109-001
278644-001
L.P.
warranty.
December 2005
June 2002
Document Part Number 292400-002
255440-001
289574-001
149806-001
257309-001
257047-001
257048-001
271122-xxx
-171 Portuguese
-181 Spanish
-081 Swedish
-351 Swiss
-051 Taiwanese
-061 Thai
-B31 United Kingdom
-161 U.S.
-091 U.S.
U.S.

Standard and Optional Boards

1 System board for Intel processor, with thermal
grease

Memory Modules

2 128 MB RAM, DDR
* 256 MB RAM, DDR
* 512 MB RAM, DDR

Miscellaneous Boards

3 Front audio/USB I/O board
* Lucent PCI Modem
* 3COM NIC

Intel Celeron Processors with thermal grease

4 1.7 GHz
* 1.8 GHz
* 2.0 GHz

Intel Pentium P4 Processors with thermal grease

4 2.26 GHz\512K cache
* 2.4 GHz\512K cache
* 2.0 GHz\512K cache
* 1.9 GHz\256K cache
* 1.8 GHz\256K cache
1.7 GHz\256K cache

Graphics Controllers

* nVIDIA NV11, 64 MB memory, with ATX bracket
* nVIDIA NV17, 64 MB memory, TV
* DVI ADD graphics

Other Cards

* Not shown
Miscellaneous Parts
-131
1 Front bezel assembly includes plain front bezel,
-071
5 1/4" bezel blank, and bezel insert 2 for EMEA
and Blue Angel use only
-101
1 Front bezel assembly includes silver front bezel,
-111
5 1/4" bezel blank, and bezel insert 3 supporting 2
USB and 2 audio ports
-AB1
3 Bezel insert supporting 2 USB and 2 audio ports
-281
* Power switch holder
-031

Heatsink assembly Type 1, includes:

-001
4 Fan assembly with mounting base and attaching screws
-002
5 Heatsink
-004

Heatsink assembly Type 2, includes:

6 Heatsink with fan assembly and retaining clips
* Heatsink mounting base and attaching screws
* Mouse, 2-button with ratchet wheel
* DiskOnKey, 8 MB
Miscellaneous plastics kit, includes:
* Bezel blank (166775-002)
* Power switch spring (not this product)
* LED holder (not this product)
* Cable clip (not this product)
* 3.5" to 5.25" Drive bay adapter
*Not shown
283983-001
285648-001
285649-001
285650-001
284247-001
239411-001
253951-001
288691-001
288692-001
309578-001
288688-001
288689-001
273051-001
255436-001
255435-001
252919-001
279777-001
267526-001
279778-001
299170-001
299171-001
292209-001
287077-001
289576-001
300871-001
237241-001
249911-001
257051-001
313224-001
