  • Page 1 Pro Spotter Operations and Maintenance Manual For Commercial Use Only Model No. TE010-G03-U...
  • Page 2 NOTES...
  • Page 3: Table Of Contents

    CONTENTS Getting Started Introduction......................1 Warranty.........................2 Grounding Instructions..................3 Important Safety Instructions................4 Cleaning Agents.....................6 Technical Specifications..................7 Operating Instructions Key Features......................7 Controls........................8 Operation.......................9 Transport and Storage..................10 Maintenance......................11 Fault Diagnosis.....................12...
  • Page 4: Introduction

    INTRODUCTION Your new Tornado unit is a high quality, precision-made product. All parts used in the manufacturing of this unit have passed rigid quality control standards prior to assembly. Please safeguard the original receipt/invoice given at the time of purchase. If you experience any problems with your unit during the warranty period, the original receipt/invoice will act as proof of purchase.
  • Page 5: Warranty

    WARRANTY Warranty Within 30 days of purchase, to activate product warranty, go to: https://tornadovac.com/services/warranty-registration- form.aspx For warranty information go to www.tornadovac.com. Warning Labels Prior to operating the unit, read and understand completely this owner’s manual paying special attention to warning labels. These labels indicate a potentially hazardous situation that could result in death or serious injury if not avoided.
  • Page 6: Grounding Instructions

    GROUNDING INSTRUCTION This appliance must be grounded. If it should electrically malfunction, grounding provides a path of least resistance for the current to reduce the risk of electric shock. This machine is equipped with a cord having an equipment grounding conductor and grounding plug.
  • Page 7: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read and understand this owner’s manual and all labels on the unit before operating. Safety is a combination of common sense, staying alert, and knowing how your unit works. To reduce the risk of personal injury or damage to your unit, use only as indicated in this manual.
  • Page 8 In the event of accidental contact with any such substances (e.g., due to spills) follow the decontamination procedures in force at the user site. If in any doubt about the condition of the machine, contact Tornado or the dealer/ agent who supplied the machine.
  • Page 9: Cleaning Agents

    CLEANING AGENTS When using cleaning and care agents, the manufacturer’s danger warnings must • be followed, and proper PPE must be worn per manufacturer’s instruction. • Only use low-foaming, non-combustible cleaning agents which DO NOT contain generally health-hazardous substances. • Use defoamer at all times to prevent damaging the vacuum motor. •...
  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS Specification Value Model TE010-G003-U Input Voltage 115 VAC Hertz Plug Type Solution Tank 3.5 Gal/13.2 l Recovery Tank 2.5 Gal/9.5 l Dimensions 24” x 14” x 23”/61cm x 36 cm x 58 cm Weight 35 lbs./16kg Waterlift 89”/226 cm CFM/CMM 104/3 Solution Pressure...
  • Page 11: Controls

    KEY FEATURES Solution Hose Connection CONTROLS 3-Way Switch...
  • Page 12: Operation

    OPERATION Filling the Pro Spotter • Unplug the unit. • Disconnect the solution and recovery tanks. • Remove the upper recovery tank. • Add water and/or chemicals to the lower solution tank. Fill only to the fill line indicated on the label on the inside of the solution tank. The tank will hold up to 3.5 gallons.
  • Page 13: Transport And Storage

    TRANSPORT AND STORAGE Transport: 1. Take extreme care when moving the machine up or down steps or stairs. 2. Incorrect lifting techniques may result in personal injury. 3. As stated earlier in this manual, this machine is heavy. Do not attempt to lift the machine without assistance.
  • Page 14: Maintenance

    4. NOZZLE MAINTENANCE – If the spray of the nozzle becomes blocked, wash the nozzle in clean water ensuring that the nozzle is clear prior to refitting. Besides those outlined above, all additional servicing and repairs should only be performed by an Authorized Tornado Servicing Agent.
  • Page 15: Fault Diagnosis

    TROUBLESHOOTING The following checks may be performed by the operator. Any other service or attempt to service by the operator will void the warranty. TROUBLESHOOTING Possible Cause Solution Problem Pump is not primed. Depress lever on hand tool to No Spray release pressure.
  • Page 16 PART DIAGRAM...
  • Page 17 Shut Off Disk X9087 Washer X9088 Screw 8-18 x 1/2” PX103AG Lid Gasket X9518 Deflector X9062 Float X9082-KIT Stand Pipe Sub-Assembly X2046-YEL Tornado Label X9999 Hose Assembly 7DL003 Hose Clamp PX46 Lock Nut X9079 Gasket X2045 Fill Label X1920BLK Solution Tank PC66 Hose Barb 1/4”H x 1/8MPT...
  • Page 18 PART LIST No. Part No. Description X8497B Switch Label X9048 Rocker Switch X8008N Steel Conduit Lock Nut 1/2” Strain Relief X9719 Power Cord 18 AWG 20’ 19565 Screw #10 16 x 1/2” 7CZ001 Hose, Vacuum 2 In Dia Bulk Grey See Cut Lengths PX215 Hose Clamp...
  • Page 19 Tornado Industries, LLC 3101 Wichita Court Ft. Worth, TX 76140-1755 Phone: 800-VACUUMS Fax: 1-817-551-0719 WWW.TORNADOVAC.COM Record of Purchase Serial Number: ________________________________ Purchase Date: _______________________________ Dealer: _______________________________________ Phone Number: _______________________________ T-OM-TE010-G03-U 02/2022...
