nRAY series
Wireless Wire nRAY (nRAYG-60adpair)

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
All installation methods for mounting an access point on any wall surface is subject to the acceptance of local jurisdiction.
The Installation of the equipment must comply with local and national electrical codes.
This product is intended to be mounted outdoors on a pole but can also be installed indoors. Please read the mounting instructions carefully before
beginning installation. Failure to use the correct hardware and configuration or to follow the correct procedures could result in a hazardous situation to
people and damage to the system.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.
This is a class A device. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate
measures.

Quickstart

Please follow these quick steps to set up your device:
Unscrew the cover to reach the Ethernet port;
Guide Ethernet cable through the opening;
Plug into the Ethernet port and screw clockwise tightly, to ensure water protection;
Connect the PoE injector into the computer;
Connect the power adapter to the PoE injector;
Download WinBox configuration tool
Default IP: 192.168.88.2 and 192.168.88.3, user name:
By default devices are configured as W60G Bridge;
Once connected, configure the device, so it has an active Internet connection
software manually;
Upgrade the RouterOS software to the latest version
Connect again and choose your Region, this can be done in the Wireless menu W60G tab;
Double click on the W60G interface, go to the Wireless tab and choose your Region;

Powering

The device accepts power 802.3af/at PoE in 12 – 57 V DC .
The power consumption under maximum load can reach 6 W.
Connecting to a PoE Adapter:
1.
Connect the Ethernet cable from the device to the PoE+DATA port of the PoE adapter.
2.
https://mt.lv/winbox
, or use Web browser;
admin,
and please find the password on the sticker;
https://mt.lv/upgrade
https://mt.lv/configuration
, or proceed to the next step to upgrade
;

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the nRAY Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MikroTik nRAY Series

  • Page 1 It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed. This is a class A device. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate measures.
  • Page 2 Connect an Ethernet cable from your local network (LAN) to the PoE adapter. Connect the power cord to the adapter, and then plug the power cord into a power outlet. Mounting The device is designed to be used outdoors and mounted on the pole. When mounting, please ensure that the drain hole is pointing downwards.
  • Page 3 Attach the assembly to the pole. Add mount bracket and use two 13 mm nuts to secure the device. Aim tool usage The device has led arrows on the back of the unit. Aim using the to reach precise alignment. ...
  • Page 4 LAN side (all access is blocked from the Internet port by default). Seek additional help from your local trainers or become a trainer of yourself. https://mikrotik.com/training/about For recovery purposes, it is possible to boot the device for reinstallation, see section...
  • Page 5 Federal Communication Commission Interference Statement FCC ID: TV7RAY60 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 6 Информация о дате изготовления устройства указана в конце серийного номера на его наклейке через дробь. Первая цифра означает номер года (последняя цифра года), две последующие означают номер недели. Изготовитель: Mikrotikls SIA, Aizkraukles iela 23, Riga, LV-1006, Латвия, support@mikrotik.com. Сделано в Китае, Латвии или Литве. Cм. на упаковке.
  • Page 7 Canali operativi / massima potenza di uscita Canales operacionales / potencia de salida máxima Операционные каналы / максимальная выходная мощность Note. Information contained here is subject to change. Please visit the product page on   www.mikrotik.com   for the most up to date version of this document.
