TCL LED23E4200 Service Manual page 6

TCL MULTIMEDIA
LCD TV SPECIFICATION RELEASE
Version: V1.0
Model: LED23E4200/MS306D-LA
Panel Size (inch)
Category
Aspect Ratio
Color Temperature
Backlight Adjustable
Scaler Mode
Picture Effect
Film Mode (3:2 pull down)
Picture Enhancement
Comb Filter
Dynamic Niose Reduction
Adaptive Deinterlacing
Blue Stretch
Black Stretch
Motion Compensation
DLTI
DCTI
Dynamic Skin Correction
DNR
Panel Specification
Back Light Unit
Panel supplier
Viewing Technology
Display Resolution
Brightness (cd/m2)
Contrast Ratio
Response Time
Viewing Angle (H/V)
Life Time
Color
SOUND
Speakers
Audio Power Output
DVSS (Dolby Virtual Surround)
DDAS (Digital Dynimic Audio System)
AVC (Auto Volume Control)
BBE
SRS
MTS
Sound Features
Sound Control
Function
Parental Guidance
CCD (Closed Caption)
Teletext
Macro Vision
Calendar
Clock/Timers
Lock
OSD Language
OSD Features
REC
GUIDE
AUDIO Language
Screen Saver
Melody
Software Upgrade
Game
USB Connection
Demo function
Hotel
Other Functions
Design and specifications are subject to change without notice!
Issued Date: 2014.05.28
24"
LCD TV
16:9
Medium/Warm/Cool
Yes
Auto/4:3/16:9 /Zoom1/Zoom2/Panorama
4 picture effects preset (Standard/Dynamic/Mild/User)
Auto
3D
3D
3D
Yes
Yes
Yes
Yes
Yes
Yes
Yes(Off/Low/Middle/High)
LED
SAMSUNG 4A-LD23O7-SS1GTA
16:9
1366*768
200
4000:1
8ms
155°/155°
＞30,000hrs (min)
16.7M (8 bit)
Integrated speakers (Bottom side)
4.5W+4.5W
X
YES
YES
X
X
Yes(Stereo/Mono/SAP)
AV Stereo,Mstar Surround
Volume, Balance,5 Band EQ, 5 mode presets
(Movie/Sports/Standard/Music/User)
Yes
Yes
X
X
X
Yes
Yes(Parental Guidance and Content Lock at DTV )
English/Portuguese/Spanish
16 Bit COLOURS
Yes(at DTV)
Yes(at DTV)
Yes(at DTV)
option
X
Yes(By USB)
Yes
Yes.Movie /Music/Photo/ Text
X
In factory mode
--
SIGNAL FORMAT CAPABILITY
Component Video Format
DVI Video Format
HDMI Video Format
PC Compatibility
TERMINALS
Audio/CVBS Input (Composite)
S-Video Input
Audio Input for S-Video
YPbPr Input
Audio Input for YPbPr
YCbCr Input
Audio Input for YCbCr
VGA Input(RGB)
Audio Input for RGB
DVI
Audio Input for DVI
HDMI
Audio/CVBS Output (Composite)
SPDIF
Headphone Output
RF Input(Antenna)
USB 2.0
Basic Info.
TV System
DTV System
AV System
Channels(analog)
DTV Channels(digital)
Chassis
Certification
Power Supply
Power Consumption-TV on
Power Consumption-Standby
Default Color of Front Cabinet
Keyboard Position
Base Stand Detachable
Unpackaged Dimension for Main Body (L*H*D) (mm)
With Base Stand (mm)
Without Base Stand (mm)
Packaged Dimension (L*H*D)
Main Body (mm)
Speaker Box
Base Stand
Net Weight (Kg)
Gross Weight (Kg)
Container Loading
20 feet
40 feet
40 feet high
ACCESSORIES
Operation Manual
Remote Control Mode
Base Stand
Speaker Box
Wall Mount
Others
Drafted by:
Approved by:
Y,Pb/Cb,Pr/Cr:up to 1080P
Up to XGA for HDMI-PC
up to 1080P
Up to SXGA
2 AUDIO R/L+2 Video: AV IN AV2:Share
with for "Y" ,
X
X
1
1
Share with for "YPbPr"
Share with for "YPbPr"
1 (D-Sub,15 Pins)
Share with for "YPbPr"
Share with "HDMI" PORT
Share with for "YPbPr"
2
1(Audio Output For Mini JACK;CVBS Output
For RCA )
1
X
2 (Antenna,Cable) F Type
1(at side)
NTSC-M,PAL M/N
ISDB-T
PAL,NTSC
Antenna：2～69；CATV：1～125
Antenna：7～69
MS306D-LA
CB
AC 110V-240V 50/60Hz
30W
≤0.5W
Back
Yes
543*379.7*159.7
543*339.5*56.5
614*109*420
NO
Packaged with ALL
3.65
4.2
1065
2230
2530
English(Default)
RC200 (with two 7# batteries)
Integrated Packaging
Integrated
Optional
AC Power cord
Page 1 of 1
