After the adjustment of HDMI1, you can switch to other source AV, PC
and YPbPr and repeat step 1—6 to do the WB adjustment.
Note: For some small size LED panel,the color coordination of
specifications is not X=0.280/Y=0.290,and we recommend you adopt the
values from panel specifications.
5.5. ADC Calibration and White Balance Adjustment (automatic)
The process of adjusting ADC and White Balance automatically is out
of the range of this file, Please refer to the relevant technical file
of HuiZhou factory of TCL.

6.Chip list of software programming before SMT

Following chips must be programmed before SMT by tools
Position Chip type
U202
EN25Q32

7.Software update

Method of SW update:
1） Download the bin file "MS306C_TCL.bin or MS306D_TCL.bin"to the
root directory of your USB device (DO not change the file name); Then
insert the USB device to USB interface of TV set.
Note：MS306C_TCL.bin software update file is for MS306C chassis
MS306D_TCL.bin software update file is for MS306D chassis
2）
Upgrading method 1
1，using the remote, enter the "Picture" submenu of the OSD; choosing
the "contrast" item and press 9,7,3 and 5 in series, Factory Menu will
appear in the left top of screen.
2,Select the "USB UPDATE" item , press left or right key to enter the
update box;
Software description
HDMI HDCP Key, System Software
第 10 页共 11 页
etc.
