TCL LED24D2710 Operation Manual
  1. Manuals
  2. Brands
  3. TCL Manuals
  4. LED TV
  5. LED24D2710
  6. Operation manual

TCL LED24D2710 Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TCL MULTIMEDIA TECHNOLOGY HOLDINGS LIMITED
GPD R&D CENTER GRAPHIC DESIGN STUDIO
GPD
DESIGN SECTION
牌子名称:
TCL LED24D2710 (MT31BP-AP) RUSSIA
(BRAND NAME)
B.O.M.编号:
( B . O . M . N O )
平面设计室
相关美工资料内部局域网查阅路径: \\10.118.1.66\goc\工程业务中心(TOT)\设计中心\结构设计部\平面设计室\平面设计技术资料库\美工制作表
内容：
稿件比例(SCALE)
i)
尺寸(SIZE)
ii)
颜色(COLOUR)
iii)
英语在前，俄语在后
俄语请以客户确认业务审签为准！
TCL 设计
DESIGN BY TCL:
制 作 人
PREPARED BY：
(EXPORT)
P R O D U C T I O N
H7-YD271NTW-UR0A
:
1:1
:
143X210MM
:
PRINT IN BLACK ON WHITE BACKGROUND.
白底黑字。
客户提供
DESIGN BY CUS.:
项目/美工 工程师
ENG.CHECKED BY:
物料编号：
内
型
日
F O R M
美 工 资 料 升 级 专 用 栏
生效ODF和时间
EFQ126824W
ODF ＆ DATE:
张立
数字签名人 张立
DN： cn=张立， ou=Huizhou，
dc=com
日期： 2016.10.13 10:03:16
+08'00'
72-YD27MP-X319F
容：
OPERATION MANUAL
24D2710
号：
期：
2016-10-13
样稿：
SAMPLE:
刘洋
业务中心/项目经理
CONFIRM
BY：
21
数字签名者：刘洋
DN：cn=刘洋, o, ou,
email=vasya.liu@tcl.c
om, c=<无
日期：2016.10.13
15:45:29 +08'00'

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LED24D2710 and is the answer not in the manual?

Questions and answers

Related Manuals for TCL LED24D2710

Summary of Contents for TCL LED24D2710

  • Page 1 TCL MULTIMEDIA TECHNOLOGY HOLDINGS LIMITED 72-YD27MP-X319F 物料编号： GPD R&D CENTER GRAPHIC DESIGN STUDIO 内 容： OPERATION MANUAL 24D2710 型 号： 日 期： 2016-10-13 DESIGN SECTION (EXPORT) P R O D U C T I O N F O R M 美...
  • Page 2 LED24D2710...

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction Precautions ............................Product ............................. Power and Plug ..........................Power Cord and Signal Cable ......................Use Environment ..........................Cleaning ............................Hanging the TV Set on the Wall ......................Important Information ........................Buttons on the TV ..........................

  • Page 4: Chapter 1: Introduction

    Chapter 1 Introduction Keep the set away from direct sunlight. Precautions The set shall not be exposed to dripps or splashes and no objects filled with liquids, such as vases, shall be Read all of the instructions before operating the set. placed on the set.

  • Page 5: Buttons On The Tv

    Introduction Buttons on the TV Take a certain model for an example: PRO. PRO. button Turns the TV on or standby. (Note: for some models, the button turns the TV on or off.) 2. SOURCE button Press to select signal source. .
  • Page 6 Introduction YPbPr/AV component sockets (input)+ AV/VGA/COMPONENT AUDIO IN YPbPr/VIDEO These YPbPr adapter can be used to connect a device that has component video COMPONENT/ sockets, such as a DVD player. The component adapter can recognize if the device AV IN you're connecting to is Y Pb Pr compatible or Y Cb Cr compatible.

  • Page 7: Remote Control Functions

    To open the corresponding submenu and activate a setting menus; to freeze/unfreeze the picture in digital TV mode. Enters the Quick access. NOTES 1、Do not mix old and new batteries or different types. 2、When the batteries are to be exhausted, the leakage may occur and cause the damage to the remote.

  • Page 8: Chapter 2: General Operation

    Chapter 2 General Operation Switching on Follow the instructions on this page on how to switch on your TV set and the remote control before going on to following pages describing how to use the channel set-up procedure. 1. Insert two AAA batteries in the remote control. Precautions on using batteries: - Only use the battery types specified.

  • Page 9: Initial Set-Up

    General Operation Initial Set-up Using Menu System This section explores the menus of your TV. Each menu Initial set-up involves selecting all the settings required to is outlined and detailed to help you get the most from be able to search for and store all the channels you can your TV.

  • Page 10: Automatic Channel Set-Up

    General Operation Automatic Channel Set-up When you have finished, press Menu to return, or press This option allows the TV to search for, find and store all Exit to close the menu. the available analog and digital channels. Follow all the steps in turn specified hereafter. Automatic Update Channel install This allows you to update all available channels, without...

  • Page 11: Chapter 3: Advanced Functions

    Chapter 3 Advanced Functions direction button to choose between these options: Low/High/Auto /Off/Middle. Adjusting the Picture MPEG NR (Noise Reduction): this feature allows you to reduce visible interference caused by MPEG The menus for adjusting the picture are used to obtain compression.

  • Page 12: Selecting A Signal Source

    Advanced Functions Auto volume control (only available in TV mode): Input lock: this option allows you to lock a certain select On mode to reduce the annoying blasts in external source you want to lock. Press the OK or right volume during commercial breaks and also amplifies direction button to display Input lock menu, then press softer sounds in program material.

  • Page 13: Special Functions

    Advanced Functions Subtitle: this enables subtitle for digital TV channels. Auto synchronization: use the left or right direction Select Subtitle option, press the OK or right direction to select On or Off. If On selected, the TV will get the button to display its submenus: time automatically from DTV signals, and the Time item cannot be adjusted.

  • Page 14: Mhl Functions

    Advanced Functions MHL Functions MHL Function (Mobile High-definition Link) Decoding page language: press Menu on the remote You can use the following functions by connecting control and select Options > Decoding page the TV HDMI port identified with MHL and the USB language.

  • Page 15: Usb Functions

    Advanced Functions 2. Use the left/right/up/down buttons to select a song in USB Functions either main or sub file content browser in the same way as in photo display function, press Menu to display the Your TV is fitted with a USB connector that enables you to music menu in the folder mode.

  • Page 16: Chapter 4: Other Information

    Chapter 4 Other Information Troubleshooting Most problems you encounter with your TV can be 1. Adjust the position and orientation of the indoor/outdoor corrected by consulting the following troubleshooting list. antenna. 2. Check the connection of antenna. No picture, no sound 3.
  • Page 17 LED24D2710...
  • Page 20 PRO. PRO.
  • Page 24 Первоначальные настройки Выполнено Поздравляем! Начальная настройка выполнена. Нажимите кнопку [ok],чтобы завершить работу мастера.
  • Page 26 Норм.
  • Page 31 72-YD27MP-X319F...
  • Page 32 Система звука Источник питания D/K, B/G, I, NICAM 110-240 В , 50/60 Гц принимаемого сигнала Система цветности SECAM, PAL 110-240 В , 50/60 Гц принимаемого сигнала LED24D2710 Model Screen size 24" Формат сигнала Format of signal DVB-C/T/T2 200 cd/m2 Brightness...

Table of Contents
