User's Guide
For use with models : LE50FHDE3010
/ LE58FHDE3010
Need assistance?
visit our website at www.tclusa.com
or call 1-877-300-8837
Figures and illustrations in this User's Guide are
provided for reference only and may di er from
actual product appearance. Product design and
speci cations may be changed without notice.
Advertisement
Table of Contents
Related Manuals for TCL LE50FHDE3010
Summary of Contents for TCL LE50FHDE3010
- Page 1 User’s Guide For use with models : LE50FHDE3010 / LE58FHDE3010 Need assistance? visit our website at www.tclusa.com or call 1-877-300-8837 Figures and illustrations in this User’s Guide are provided for reference only and may di er from actual product appearance. Product design and...
-
Page 2: Important Information
Product Registration Please register your TCL purchase on-line at www.tclusa.com. It will make it easier to contact you should it ever be necessary. Registration is not required for warranty coverage. -
Page 3: Important Safety Instructions
Important Safety Instructions 1. Read and follow all instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 5. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 4: Table Of Contents
Table of Contents Important Information ........ 1 Geometry ............15 Advanced Settings ........15 Important Safety Instructions ..... 2 Sound Menu ..........15 Chapter 1 - Connections and Setup Equalizer ............15 Before Initial Setup ........4 SRS TruSurround HD ........15 Check Supplied Parts ........ -
Page 5: Chapter 1 Connections And Setup
Chapter 1 Connections and Setup Before Initial Setup Protect Against Power Surges • Connect all components before you plug any power cords into the wall outlet or power strip. • NEVER plug your TV into an outlet that is controlled by a wall switch. •... -
Page 6: Attaching Your Tv To The Table Stand
Connections and Setup Attaching Your TV to the Table Stand Your TV comes without the table stand attached so that you can choose to mount your TV either to its table stand or to a wall (wall mount sold separately). If you want to mount your TV to the wall, don’t attach the table stand. -
Page 7: Buttons On Tv
Connections and Setup Buttons on TV If you cannot locate your remote, you can use the TV panel buttons on your TV to operate many TV features. Selects channels stored in the channel list or acts as the up/ CH+/- down arrow (▲/▼) through the menu items. -
Page 8: Choose Your Connections
Connections and Setup USB: Allows you to connect a compatible mass storage device. HDMI 1 / DVI IN (High-Definition Multimedia Interface/Digital Visual Interface): Provides an uncompressed digital connection that carries both video and audio data by way of an integrated mini-plug cable. Since HDMI technology is based on Digital Visual Interface (DVI), the jack on the back of your TV is also compatible with DVI components. - Page 9 Connections and Setup HDMI Connection (Best) Set-top box HDMI 2 IN HDMI 2 IN HDMI cable Same connection to HDMI 1/HDMI 3 IN Same connection to HDMI 1/HDMI 3 IN Component Video Connection (Better) Composite Video Connection (Good) VIDEO AUDIO AUDIO AUDIO AUDIO...
-
Page 10: Mhl Function
When using MHL • Interoperability with MHL devices of other manufacturers is not guaranteed. • TCL does not provide any guarantee, therefore, against operational failure such as that described below when an MHL source is connected to the TV. - No picture or sound - Some of the functions do not work by remote operation from the TV •... -
Page 11: Remote Control Functions
Connections and Setup Remote Control Functions INPUT Press INPUT repeatedly to select the video input (Alphanumeric buttons) Enters a channel number, then press OK (or let the entry timeout). INPUT • (dot) To enter a digital channel with a sub-channel, enter the main channel;... -
Page 12: Obtain The Signal
Connections and Setup Obtain the Signal The first step in connecting your TV is obtaining the signal. The back panel of your TV allows you to receive analog and/or digital channels by using the HDMI or ANT/CABLE/SAT connections. To obtain the best quality, use the HDMI connection. -
Page 13: Setup Wizard
Connections and Setup Setup Wizard Perform the following steps before you press on the remote control unit. • Insert the batteries into the remote control unit. • Connect the antenna cable to the TV. • Plug in the AC cord to the AC outlet. The first time you switch the set on, the Setup Wizard opens, which guides you through the setup process. -
Page 14: Chapter 2 - Menu Operation
Chapter 2 Menu Operation Menu Display The following are just illustrations of the menu display. Some menu items may not be displayed depending on the selected input source. Source Picture Picture Mode < Vibrant > Source Source Brightness Contrast Component Saturation Picture Picture... -
Page 15: Using Menu System
Menu Operation Using Menu System display the menu screen. Press▲/▼ to select “Picture”, then press OK/► to display options. This section explores the menus of your TV. Each menu is outlined and detailed to help you get the Picture Mode most from your TV. -
Page 16: Geometry
Menu Operation conditions). The five-band equalizer allows you to adjust the audio frequency settings. You can select one of the Note: When “Dynamic Light Sensor” or “Dynamic five preset options or create a custom preset. Backlight” is set to “Off”, the power consumption may exceed the requirements of the ENERGY Sound Mode: Allows you to choose a specific STAR®... -
Page 17: Audio Language
Menu Operation if available. SAP audio is broadcast in mono only. 1. Select “Setting > Channel > Favorite”, press SAP is also used to broadcast a program’s audio OK/► to enter, a list of available channels with descriptions of the video for the visually displayed. -
Page 18: Parental Control
Menu Operation the TV’s sound is muted. The captioning unlocked. information is not displayed when the sound is V-Chip reads the program’s age-based rating (TV- not muted. MA, TV-14, etc.) and content themes (Violence Analog CC Option: This option lets you select (V), Adult Language (L), etc.). -
Page 19: Menu Operation
Menu Operation In the US TV Ratings panel you can customize Parental guidance the program blocking of the following TV Viewer 14 and over ratings: Adult TV–Y All children Canadian French Ratings: TV–Y7 Children 7 years and older General audience TV–G General audience 8 ans+... -
Page 20: Time Setting
Menu Operation Time Setting The USB feature on your TV allows you to play audio files (format supported: MP3) or display Time Zone pictures (format supported: JPEG). To utilize this You can set the correct Time Zone for your area. feature, follow these steps: Auto Sync - Press ◄/►... -
Page 21: Chapter 3 Other Information
Chapter 3 Other Information Frequently Asked Questions (FAQs) What’s the quickest way to view High Definition (HD) video? Connect an off-air antenna to the ANT/CABLE/SAT IN to view free local digital channels. You may need to purchase an antenna. Visit www.antennaweb.org for assistance in deciding what type of antenna to use to receive the local digital channels available to you. -
Page 22: Troubleshooting
Other Information Troubleshooting Most problems you encounter with your TV can be corrected by consulting the following troubleshooting list. TV Problems The TV won’t turn on. • Make sure the TV is plugged in. • Check the wall receptacle (or extension cord) to make sure it is “live” by plugging in another device. •... -
Page 23: Other Information
TV and turn it on. See if the problem is fixed. If the problem remains, then please visit www.tclusa. com for updated FAQs or contact TCL Customer Support at the support number provided in your Warranty under “How To Get Service.”... -
Page 24: Care And Cleaning
Other Information Care and Cleaning Caution: Turn OFF your TV before cleaning. You can clean the TV as required, using a soft lint-free cloth. Be sure to occasionally dust the ventilation slots in the cabinet to help assure adequate ventilation. IMPORTANT: Never use strong cleaning agents, such as ammonia-based cleaners, or abrasive powder. -
Page 25: Limited Warranty
WITH RESPECT TO ANY PRODUCT USED FOR INSTITUTIONAL OR OTHER COMMERCIAL PURPOSES (INCLUDING BUT NOT LIMITED TO RENTAL PURPOSES). What your warranty covers: Defects in materials or workmanship to the original owner of this TCL product when purchased from an Authorized Dealer of TCL brand products and packaged with this warranty statement. -
Page 26: Product Registration
Product Registration: Please register your TCL purchase on-line at www.tclusa.com. It will make it easier to contact you should it ever be necessary. Registration is not required for warranty coverage. Limitation of Warranty: THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. - Page 27 Product design and specifications may be changed without notice. TTE Technology, Inc. 555 S. Promenade Ave., Suite 103, Corona, CA 92879 TCL and associated marks are trademarks of TCL S.A.used under license to TTE Corporation. Part No.: 72-58MS39-XNA1B...
