TRANSLATION OF THE ORIGINAL INSTRUCTIONS
We advise you to read this manual carefully, as it contains all the instructions for maintaining
the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Table of contents
4
4
8
8
8
8
8
9
10
10
11
11
12
13
14
14
16
17
18
23
23
25
27
32
33
34
36
37
39
41
41
46
48
3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Smeg BG91IAN2
Summary of Contents for Smeg BG91IAN2
-
Page 1: Table Of Contents
5.2 Electrical connection 5.3 Instructions for the installer TRANSLATION OF THE ORIGINAL INSTRUCTIONS We advise you to read this manual carefully, as it contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com... -
Page 2: Instructions
Instructions 1 Instructions not be carried out by unsupervised children. 1.1 General safety instructions • Be aware of how rapidly the cooking zones heat up. Do not Risk of personal injury place empty pans on the heat. • During use the appliance and its Danger of overheating. - Page 3 Instructions compartment (where present) of a qualified technician. when the oven is on and still hot. • If the power supply cable is • The items inside the storage damaged, contact technical compartment could be very hot support immediately and they will after using the oven.
- Page 4 Instructions • Never leave objects on the substances such as lemon juice or cooking surface. vinegar on the hob. • DO NOT USE THE APPLIANCE • Do not put empty pans or frying TO HEAT ROOMS FOR ANY pans on switched on cooking REASON.
- Page 5 Instructions detergents (e.g. scouring • Use cables withstanding a powders, stain removers and temperature of at least 90 °C. metallic sponges) on glass parts. • The tightening torque of the • Do not wash the removable screws of the terminal board components such as the hob leads must be 1.5 - 2 Nm.
-
Page 6: Manufacturer Liability
Instructions 1.2 Manufacturer liability 1.5 This user manual The manufacturer declines all liability This user manual is an integral part of for damage to persons or property the appliance and must therefore be caused by: kept in its entirety and within the user's reach for the whole working •... -
Page 7: How To Read The User Manual
Instructions • Deliver the appliance to the 1.7 How to read the user manual appropriate recycling centre for This user manual uses the following reading electrical and electronic conventions: equipment waste, or return it to Instructions the retailer when purchasing an General information on this user equivalent product, on a one for manual, on safety and final... -
Page 8: To Save Energy
Instructions 1.8 To save energy 1.9 Information for European Control Bodies • Only preheat the appliance if the recipe requires you to do so. Fan forced mode • Unless otherwise indicated on the the ECO function used to define the energy package, defrost frozen foods efficiency class complies with the specifications of European standard EN... -
Page 9: Description
Description 2 Description 2.1 General Description 1 Cooking hob 5 Door 2 Control panel 6 Fan 3 Light bulb 7 Storage compartment 4 Seal Rack/tray support frames... -
Page 10: Cooking Hob
Description 2.2 Cooking hob Power draw in booster Zone Outside diameter (mm) Max. power draw (W)* function (W) * 2300 3000 1300 1400 2300 3000 1300 1400 2300 3000 Power levels are approximate and can vary according to the pan used or the settings made. •... -
Page 11: Control Panel
Description 2.3 Control panel 1 Programmer clock 4 Function knob For displaying the current time, setting The oven's various functions are suitable for programmed cooking operations and the different cooking methods. After selecting minute minder timer. the required function, set the cooking temperature using the temperature knob. -
Page 12: Other Parts
Description 2.4 Other parts 2.5 Available accessories Shelves Deep tray The appliance features shelves to position trays and racks at different heights. The insertion heights are indicated from the bottom upwards (see 2.1 General Description). Interior lighting The appliance’s interior lighting comes on: Useful for collecting fat from foods placed •... - Page 13 Description Tray rack To be placed over the top of the tray; for cooking foods which may drip. The accessories intended to come into contact with food are made of materials that comply with the provisions of current legislation. Supplied and optional accessories can be requested to Authorised Service Centres.
-
Page 14: Use
3 Use Improper use Risk of damage to surfaces Instructions High temperature inside the oven • Do not cover the bottom of the oven during use cavity with aluminium or tin foil sheets. Danger of burns • If you wish to use greaseproof paper, place it so that it will not interfere with the •... -
Page 15: Using The Accessories
3.1 Using the accessories High temperature inside the storage compartment during use Racks and trays Danger of fire or explosion Racks and trays have to be inserted into the side guides until they come to a complete • Do not spray any spray product near the stop. -
Page 16: Using The Hob
3.2 Using the hob Unsuitable cookware: • Copper, stainless steel, aluminium, On first connection to the electrical fireproof glass, wood, ceramic and mains, an automatic check will be terracotta cookware. carried out that will switch on all To see whether the pan is suitable, bring a indicator lights for a few seconds. - Page 17 Cookware recognition Limiting the cooking duration When there is no saucepan on a cooking The hob has an automatic device which zone or if the saucepan is too small, no limits the duration of use. energy will be transmitted and the symbol If the cooking zone settings are not changed, the maximum duration of will appear on the display.
- Page 18 Advice on energy-saving Power levels • The diameter of the base of the pan must The power in the cooking zone can be correspond to the diameter of the adjusted to various levels. The table shows the levels suitable for various types of cooking zone.
- Page 19 Heating accelerator Booster function Each cooking zone is equipped The booster function allows the with a heating accelerator that cooking zone to be activated at allows the maximum power to be maximum power for as long as 5 delivered for a time that is minutes.
- Page 20 The flashing of a power level indicates that 2. Turn the front left and front right cooking it will be automatically limited to a new level zone knobs anticlockwise at the same selected by the power control module. time to position “A”, and keep them in this position for 3 seconds.
-
Page 21: Using The Storage Compartment
The last power setting will remain After a prolonged period of selected even in the event of a interruption to the power supply, power failure. the control lock will be deactivated. If this is the case, turn Possible cooking zone combinations it back on as described above. - Page 22 2. Select the temperature using the Small grill temperature knob. Using only the heat released from the central element, this function Ensure that the programmer clock allows you to grill small portions of shows the cooking duration meat and fish for making kebabs, symbol , otherwise it will not toasted sandwiches and any types...
-
Page 23: Cooking Advice
Fan with round heating element The ECO function is a delicate cooking function and is The combination of the fan and the recommended for food round heating element withstanding temperatures lower (incorporated in the rear of the than 210 °C; in case of cooking oven) allows you to cook different at higher temperatures, select foods on several levels, as long as... - Page 24 • With the Fan grill function, we Advice for defrosting and proving recommend that you preheat the oven • Place frozen foods without their before grilling. packaging in a lidless container on the • We recommend placing the food at the first shelf of the oven.
-
Page 25: Programmer Clock
3.6 Programmer clock Setting the time If the time is not set, the oven will not switch on. On the first use, or after a power failure, the digits will be flashing on the appliance’s display. 1. Hold down the clock key for two seconds. - Page 26 Timed cooking 7. Press the clock key to reset the programmer clock. Timed cooking is the function which allows a cooking operation It is not possible to set a cooking to be started and then ended after time of more than 10 hours. a specific length of time set by the user.
- Page 27 10. Return the function and temperature 4. Use the key to set the knobs to 0. required minutes. (for example 1 hour) 11. To turn off the buzzer just press any key 5. Press the menu key . The text of the programmer clock.
- Page 28 Modifying the set data Minute minder timer 1. Press the clock key The minute minder timer does not stop the cooking operation but 2. Use the value increase and value rather informs the user when the set time has run out. decrease keys to set the number of minutes required.
- Page 29 Cooking information table Weight Temperature Runner position Food Function Time (minutes) from the bottom (kg) (°C) Lasagne 3 - 4 Static 220 - 230 45 - 50 Pasta bake 3 - 4 Static 220 - 230 45 - 50 Roasted veal Turbo/Fan assisted 180 - 190 90 - 100...
-
Page 30: Cleaning And Maintenance
Cleaning and maintenance 4 Cleaning and maintenance Cleaning the surfaces To keep the surfaces in good condition, Instructions they should be cleaned regularly after use. Let them cool first. Improper use Risk of damage to surfaces Ordinary daily cleaning Always use specific products only that do •... -
Page 31: Cleaning The Hob
Cleaning and maintenance 4.1 Cleaning the hob Weekly cleaning Clean and maintain the hob once a week Cleaning the glass ceramic hob using an ordinary glass ceramic cleaning Light coloured marks from pans with product. Always follow the manufacturer’s aluminium bases can be easily cleaned off instructions. -
Page 32: Cleaning The Door
Cleaning and maintenance 4.2 Cleaning the door 3. To reassemble the door, put the hinges in the relevant slots in the oven, making sure Removing the door that grooved sections A are resting For easier cleaning, the door can be completely in the slots. - Page 33 Cleaning and maintenance Removing the internal glass panes 5. Remove the intermediate glass pane by lifting it upwards. For easier cleaning, the internal glass panes of the door can be removed. 1. Open the door. 2. Position the locking hooks in the hinge holes to prevent accidental closing of the door.
-
Page 34: Cleaning The Oven Cavity
Cleaning and maintenance 4.3 Cleaning the oven cavity Removing racks/trays support frames For the best oven cavity upkeep, clean it Removing the rack/tray support frames regularly after having allowed it to cool. enables the sides to be cleaned more easily. Avoid letting food residue dry inside the oven cavity, as this could damage the To remove the rack/tray support frames:... -
Page 35: Vapor Clean
Cleaning and maintenance 4.4 Vapor Clean • Pour approximately 40 cc of water into the tray. Make sure it does not overflow Vapor Clean is an assisted out of the cavity. cleaning procedure which facilitates the removal of dirt. Thanks to this process, it is possible to clean the inside of the oven very easily. - Page 36 Cleaning and maintenance Vapor Clean cycle setting End of the Vapor Clean cycle 1. Turn the function knob to the symbol 4. Open the door and wipe away the less stubborn dirt with a microfibre cloth. and the temperature knob to the 5.
-
Page 37: Extraordinary Maintenance
Cleaning and maintenance 4.5 Extraordinary maintenance 4. Slide out and remove the light bulb. Replacing the internal light bulb Live parts Danger of electrocution • Unplug the appliance from the mains. The oven is fitted with a 40W light Do not touch the halogen light bulb. - Page 38 Cleaning and maintenance Installing and removing the seal To remove the seal: • Unhook the clips located in the 4 corners and in the centre, then pull the seal outwards. To refit the seal: • Hook the clips located in the 4 corners and in the centre onto the seal.
-
Page 39: Installation
Installation 5 Installation Any wall units positioned above the worktop of the appliance must be at a 5.1 Positioning minimum distance of at least Y mm. If a hood is installed above the hob, refer to the Heavy appliance hood instruction manual to ensure the Crushing hazard correct clearance is left. - Page 40 Installation Appliance overall dimensions 900 mm 600 mm B - Class 2 subclass 1 min. 150 mm (Built-in appliance) 900 - 915 mm 750 mm 450 mm 900 mm Minimum distance from side walls or other flammable material. Minimum cabinet width (=A). C - Class 2 subclass 1 (Built-in appliance) The appliance must be installed by...
- Page 41 Installation Dimensions of the appliance: locations of Positioning and levelling gas and electric connections (mm) Heavy appliance Risk of damage to the appliance • Insert the front feet first and then the rear ones. • After making the gas and electrical connections, screw on the four feet supplied with the appliance.
- Page 42 Installation 3. Assemble the fastening bracket. Fastening to the wall The anti-tip devices must be installed in order to prevent the appliance from tipping over. 1. Screw the wall fastening plate to the rear of the appliance. 4. Align the base of the hook on the fastening bracket with the base of the slot on the wall fastening plate.
- Page 43 Installation 5. Align the base of the fastening bracket 7. Move the bracket onto the wall and with the ground and tighten the screws mark the position of the holes to be to fix the measurements. drilled in the wall. 6.
-
Page 44: Electrical Connection
Installation 5.2 Electrical connection The appliance can work in the following modes: Power voltage • 220-240 V 2~ Danger of electrocution • Have the electrical connection performed by authorised technicians. • Use personal protective equipment. 3 x 10 mm² three-core cable. •... - Page 45 Installation Access to the terminal board The aforementioned power cables are sized taking into account the To connect the power supply cable, access coincidence factor (in compliance to the terminal board on the rear cover: with standard EN 60335-2-6). 1. Remove the screws securing the lid to the rear cover.
-
Page 46: Instructions For The Installer
Installation Loosen the cable fastener screw before installing the power supply cable. 4. At the end, reposition the lid on the rear cover and secure it with the previously removed screws. 5.3 Instructions for the installer • Do not bend or trap the power cable. •...
