TRANSLATION OF THE ORIGINAL INSTRUCTIONS
We advise you to read this manual carefully, as it contains all the instructions for maintaining
the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
cerca il tuo prodotto tra le
migliori offerte di Cucine e Piani cottura

Table of contents

Smeg B90GMXI9
o
50
50
54
55
55
55
55
56
57
58
58
59
60
61
63
63
64
65
65
67
70
71
72
74
75
77
79
79
82
87
92
94
49

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B90GMXI9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg B90GMXI9

Summary of Contents for Smeg B90GMXI9

  • Page 1: Table Of Contents

    5.4 Electrical connection 5.5 Instructions for the installer TRANSLATION OF THE ORIGINAL INSTRUCTIONS We advise you to read this manual carefully, as it contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com...

  • Page 2: Instructions

    Instructions 1 Instructions • Keep children under the age of 8 away from the appliance when it 1.1 General safety instructions is in use. • Cleaning and maintenance must Risk of personal injury not be carried out by • During use the appliance and its unsupervised children.
  • Page 3 Instructions • While cooking do not place • DO NOT USE AEROSOLS IN metal objects, such as cutlery or THE VICINITY OF THIS dishes on the hob surface as they APPLIANCE WHILST IT IS IN may overheat. USE. • Do not insert pointed metal •...
  • Page 4 Instructions Risk of damaging the appliance • DO NOT USE THE APPLIANCE TO HEAT ROOMS FOR ANY • Do not use abrasive or corrosive REASON. detergents (e.g. scouring • Do not spray any spray products powders, stain removers and near the oven. metallic sponges) on glass parts.
  • Page 5 Instructions • All pans must have smooth, flat • Do not wash the removable bottoms. components such as the hob grids, flame-spreader crowns and • If any liquid does boil over or spill, burner caps in a dishwasher. remove the excess from the hob. •...

  • Page 6: Manufacturer Liability

    Instructions • Installation using a hose must be • Use cables withstanding a carried out so that the length of temperature of at least 90 °C. the hose does not exceed • The tightening torque of the 2 metres when fully extended for screws of the terminal board steel hoses and 1.5 metres for leads must be 1.5 - 2 Nm.

  • Page 7: Appliance Purpose

    Instructions 1.3 Appliance purpose 1.6 Disposal • This appliance is intended for This appliance must be disposed of separately from cooking food in the home other waste (Directives environment. Every other use is 2002/95/EC, 2002/96/EC, considered inappropriate. 2003/108/EC). The appliance •...

  • Page 8: How To Read The User Manual

    Instructions • Deliver the appliance to the 1.7 How to read the user manual appropriate recycling centre for This user manual uses the following reading electrical and electronic conventions: equipment waste, or return it to Instructions the retailer when purchasing an General information on this user equivalent product, on a one for manual, on safety and final...

  • Page 9: Description

    Description 2 Description General Description 1 Upstand 6 Door 2 Cooking hob 7 Fan 3 Control panel 8 Storage compartment 4 Left bulb Rack/tray support frames 5 Seal...

  • Page 10: Cooking Hob

    Description 2.1 Cooking hob AUX = Auxiliary burner R = Rapid burner SR = Semi-rapid burner UR = Ultra-rapid burner 2.2 Control panel 1 Timer knob 2 Function knob Allows you to set manual cooking or a timer The oven's various functions are suitable for with automatic oven switch off at the end of different cooking methods.

  • Page 11: Other Parts

    Description 3 Temperature knob Interior lighting This knob allows you to select the cooking The appliance’s interior lighting comes on: temperature. • When the door is opened. Turn the knob clockwise to the required • When any function is selected, apart value, between the minimum and maximum from the function.

  • Page 12: Available Accessories

    Description 2.4 Available accessories Ring reducer Deep tray Useful when using small cookware. Not all accessories are available on some models. Useful for collecting fat from foods placed The oven accessories intended to on the rack above. come into contact with food are Tray rack made of materials that comply with the provisions of current legislation.

  • Page 13: Use

    3 Use High temperature inside the storage compartment Instructions Danger of burns High temperature inside the oven • Do not open the storage compartment during use when the appliance is on and still hot. Danger of burns • The items inside the storage compartment could be very hot after •...
  • Page 14 Malfunctions High temperature inside the storage compartment Any of the following indicate a malfunction and you should contact a service centre: Danger of fire or explosion • Yellowing of the burner plate. • Do not spray any spray product near the •...

  • Page 15: To Save Energy

    3.1 To save energy 3.2 Using the accessories • Preheat the appliance only if the recipe Ring reducers requires it. The ring reducers must be placed on the • Unless differently stated on the package, hob grids. Make sure they are placed defrost frozen food before placing it in properly.

  • Page 16: Using The Hob

    Racks and trays 3.3 Using the hob All the appliance’s control and monitoring Racks and trays have to be inserted into the devices are located together on the front side guides until they come to a complete panel. The burner controlled by each knob stop.

  • Page 17: Using The Storage Compartment

    3.4 Using the storage compartment Correct positioning of the flame- spreader crowns and burner caps The storage compartment is at the bottom of the cooker. To open it, pull the handle Before lighting the hob burners, make sure towards you. It can be used to store that the flame-spreader crowns are cookware or metallic objects necessary correctly positioned in their housings with...
  • Page 18 Functions list Static Grill As the heat comes from above and The heat coming from the grill element gives perfect grilling results below at the same time, this system above all for thin and medium is particularly suitable for certain thickness meat and, in combination types of food.

  • Page 19: Cooking Advice

    3.6 Cooking advice General advice This function is particularly suitable • Use a fan assisted function to achieve for cooking on a single shelf with consistent cooking at several levels. low energy consumption. • It is not possible to shorten cooking times Ideal for cooking meat, fish and by increasing the temperature (the food vegetables.
  • Page 20 • With the Grill function, we recommend Advice for defrosting and proving that you turn the temperature knob to the • Place frozen foods without their maximum value near the symbol packaging in a lidless container on the first shelf of the oven. optimise cooking.
  • Page 21 Cooking information table Weight Temperature Food Function Shelf Time (minutes) (kg) (°C) Lasagne 3 - 4 Static 220 - 230 45 - 50 Pasta bake 3 - 4 Static 220 - 230 45 - 50 Roasted veal Turbo/Round 180 - 190 90 - 100 Pork loin Turbo/Round...

  • Page 22: Cleaning And Maintenance

    Cleaning and maintenance 4 Cleaning and maintenance Ordinary daily cleaning Always use specific products only that do Instructions not contain abrasives or chlorine-based acids. Improper use Pour the product onto a damp cloth and Risk of damage to surfaces wipe the surface, rinse thoroughly and dry with a soft cloth or a microfibre cloth.

  • Page 23: Cleaning The Hob

    Cleaning and maintenance 4.1 Cleaning the hob Igniters and thermocouples For correct operation the igniters and Cooking hob grids thermocouples must always be perfectly Remove the grids and clean them in clean. Check them frequently and clean lukewarm water and non-abrasive them with a damp cloth if necessary.

  • Page 24: Cleaning The Door

    Cleaning and maintenance 4.2 Cleaning the door 3. To reassemble the door, put the hinges in the relevant slots in the oven, making sure Removing the door that grooved sections A are resting For easier cleaning it is recommended to completely in the slots.
  • Page 25 Cleaning and maintenance Removing the internal glass panes 5. Remove the intermediate glass pane by lifting it upwards. For easier cleaning the internal glass panes of the door can be removed. 1. Open the door. 2. Position the locking hooks in the hinge holes to prevent accidental closing of the door.

  • Page 26: Cleaning The Oven Cavity

    Cleaning and maintenance 4.3 Cleaning the oven cavity Removing racks/trays support frames In order to keep your oven in the best Removing the rack/tray support frames possible condition, clean it regularly after enables the sides to be cleaned more letting it cool down. easily.

  • Page 27: Vapor Clean

    Cleaning and maintenance 4.4 Vapor Clean • Pour approximately 40 cc of water into the tray. Make sure it does not overflow Vapor Clean is an assisted out of the cavity. cleaning procedure which facilitates the removal of dirt. Thanks to this process, it is possible to clean the inside of the oven very easily.
  • Page 28 Cleaning and maintenance Vapor Clean cycle setting End of the Vapor Clean cycle 1. Turn the function knob to the symbol 4. Open the door and wipe away the less stubborn dirt with a microfibre cloth. and the temperature knob to the 5.

  • Page 29: Extraordinary Maintenance

    Cleaning and maintenance 4.5 Extraordinary maintenance 4. Slide out and remove the light bulb. Replacing the internal light bulb Live parts Danger of electrocution • Unplug the appliance from the mains. The oven is fitted with a 40W light Do not touch the halogen light bulb.
  • Page 30 Cleaning and maintenance Installing and removing the seal Seal maintenance tips To remove the seal: The seal should be soft and elastic. • Unhook the clips located in the 4 corners • To keep the seal clean, use a non- and in the centre, then pull the seal abrasive sponge and wash with outwards.

  • Page 31: Installation

    Installation 5 Installation Connection with a rubber hose Verify that all following conditions are met: 5.1 Gas connection • The hose is attached to the hose connector with safety clamps. Gas leak • No part of the hose is in contact with hot Danger of explosion walls (max.
  • Page 32 Installation Carefully screw the hose connector 3 to the Connection with a steel hose appliance’s gas connector 1 (½” thread Make the connection to the gas mains ISO 228-1), placing the seal 2 between using a continuous wall steel hose whose them.
  • Page 33 Installation Connection to LPG Room ventilation Use a pressure regulator and make the The appliance should be installed in rooms connection on the gas cylinder following that have a permanent air supply in the guidelines set out in the standards in accordance with the standards in force.

  • Page 34: Adaptation To Different Types Of Gas

    Installation 5.2 Adaptation to different types of In case of operation with other types of gas, the burner nozzles must be changed and the minimum flame adjusted on the gas cocks. Replacing nozzles 1. Remove the grids, burner caps and flame-spreader crowns to access the burner cups.
  • Page 35 Installation Adjusting the minimum setting for natural Adjusting the minimum setting for LPG or town gas Tighten the screw located at the side of the Light the burner and turn it to the minimum tap rod clockwise all the way. position.
  • Page 36 Installation Gas types and Countries Gas types IT GB-IE FR-BE DE AT NL ES PT SE RU DK PL HU 1 Natural gas G20 • • • • • • • • • • 20 mbar • G20/25 20/25 mbar 2 Natural gas G20 •...
  • Page 37 Installation Burner and nozzle characteristics tables 1 Natural gas G20 Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W) 1600 2 Natural gas G20 Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) (H8) Reduced flow rate (W) 1600...
  • Page 38 Installation 7 LPG G30/31 Rated heating capacity (kW) 1.75 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W) 1600 Rated flow rate G30 (g/h) Rated flow rate G31 (g/h) 8 LPG G30/31 Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W) 1600...

  • Page 39: Positioning

    Installation 5.3 Positioning Any wall units positioned above the worktop of the appliance must be at a Heavy appliance minimum distance of at least Y mm. If a Crushing hazard hood is installed above the hob, refer to the hood instruction manual to ensure the correct clearance is left.
  • Page 40 Installation Appliance overall dimensions 900 mm 600 mm B - Class 2 subclass 1 min. 150 mm (Built-in appliance) 900 - 915 mm 750 mm 450 mm 900 mm Minimum distance from side walls or other flammable material. Minimum cabinet width (=A). C - Class 2 subclass 1 (Built-in appliance) The appliance must be installed by...
  • Page 41 Installation Dimensions of the appliance: locations of Positioning and levelling gas and electric connections (mm) Heavy appliance Risk of damage to the appliance • Insert the front feet first and then the rear ones. After making the electrical and/or gas connections, screw the four adjustable feet supplied with the appliance.
  • Page 42 Installation 3. Assemble the fastening bracket. Fastening to the wall The anti-tip devices must be installed in order to prevent the appliance from tipping over. 1. Screw the wall fastening plate to the rear of the appliance. 4. Align the base of the hook on the fastening bracket with the base of the slot on the wall fastening plate.
  • Page 43 Installation 5. Align the base of the fastening bracket 7. Move the bracket onto the wall and with the ground and tighten the screws mark the position of the holes to be to fix the measurements. drilled in the wall. 8.

  • Page 44: Electrical Connection

    Installation 5.4 Electrical connection Assembling the upstand The upstand provided is an Power voltage integral part of the product; it must Danger of electrocution be fastened to the appliance prior to installation. • Have the electrical connection performed by authorised technicians. The upstand must always be positioned and •...
  • Page 45 Installation The appliance can work in the following Fixed connection modes: Fit the power line with an all-pole • 220-240 V 1N~ disconnection switch, with at least 3 mm between its contacts, in compliance with installation regulations. The circuit breaker should be located near the appliance and in an easily reachable position.

  • Page 46: Instructions For The Installer

    Installation 5.5 Instructions for the installer • The plug must be accessible after installation. Do not bend or trap the power cable. • The appliance must be installed according to the installation diagrams. • Do not try to unscrew or force the threaded elbow of the fitting.
