CHAINTECH 6AJA4T User Manual page 11

Chapter 2
Pin Definition
1~2 Normal (default)
2~3 Clear CMOS Data
FSB JP2A JP2B
Auto 1~2 1~2
66 2~3 2~3
100MHz Open 2~3
133MHz Open Open
RATIO 5.5 6 6.5 7 7.5
A Off On Off Off Off On Off Off On On On Off On Off
B Off On Off On On Off On On On Off Off Off Off Off
C Off On On On Off On On Off Off Off On On Off On
D On Off On Off Off Off On On On Off On Off On On
Pin Definition
1~2 Disable (default)
2~3 Enable
Pin Definition
1~2 Enable
2~3 Disable
8
8 8.5 9 9.5 10 10.5 11 11.5 12
This board is able to be turned on by a USB keyboard hot key
or a USB mouse click.
