Summary of Contents for Makita LM001CX3
- Page 1 INSTRUCTION MANUAL Battery Powered Lawn Mower LM001C Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: LM001C Mowing width (blade diameter) 534 mm No load speed Normal mode 2,800 min Soft no-load mode 2,300 - 2,800 min Noise reduction mode 2,300 min Part number of replacement Straight mower blade 191D52-7 mower blade Swing back mower blades *1 191D50-1 Swing back mower blades *2 191D48-8... -
Page 3: Safety Warnings
Noise EC Declaration of Conformity The typical A-weighted noise level determined accord- For European countries only ing to EN60335-2-77: The EC declaration of conformity is included as Annex A to this instruction manual. NOTE: The values have been measured with the mower equipped with the straight mower blade. - Page 4 Switch on the mower carefully according to instructions and with feet well away from the blade(s). Take care against injury to feet and hands from the mower blades. Always ensure that the ventilation openings are kept clear of debris. 10. Mow across the face of slopes, never up and down.
- Page 5 25. If the mower starts to vibrate abnormally 13. Do not wash the machine with high pressure water. (check immediately) 14. When washing the machine, be sure to remove the - inspect for damage, battery and lock key, and pour water toward the bot- - replace or repair any damaged parts, tom of the machine to which the blade is attached.
- Page 6 CAUTION: Only use genuine Makita batteries. Use and even an explosion. of non-genuine Makita batteries, or batteries that have been If electrolyte gets into your eyes, rinse them out altered, may result in the battery bursting causing fires, with clear water and seek medical attention right personal injury and damage. It will also void the Makita...
-
Page 7: Installing The Handle
Firmly tighten 4 bolts which were temporarily ASSEMBLY tightened in step 1 using box wrench 13. Align the hole in the lower handle with the hole in the upper handle, then insert the bolt from inside, and WARNING: Always be sure that the lock key then tighten the nut from outside with box wrench 13. -
Page 8: Removing The Mulching Plug
Attach the top clip to the frame as shown in the Removing the mulching plug figure. Open the rear cover. ► 1 . Clip ► 1 . Rear cover Attach all the clips to the frame as shown in the figure. Make sure that all the clips are securely attached Remove the mulching plug while holding down the to the frame. - Page 9 Hold the handle of the grass basket, and then Attaching the discharge attachment hook the grass basket on the rod of the mower body as shown in the figure. Open the rear cover, and then remove the grass basket. ► 1 . Rod 2. Handle 3. Grass basket ► 1 .
-
Page 10: Functional Description
Install the portable power pack to the machine as FUNCTIONAL shown in the figure. DESCRIPTION Installing or removing portable power pack CAUTION: Always switch off the machine before installing or removing the portable power pack. CAUTION: Hold the machine and the portable power pack firmly when installing or removing portable power pack. Failure to hold them firmly may cause them to slip off your hands and result in damage to the machine and portable power pack and... - Page 11 Install the portable power pack to the machine NOTICE: Do not insert the socket forcibly. If as shown in the figure. Lock the locking levers on both the socket cannot be inserted easily, it is not being sides of the portable power pack. inserted correctly. NOTICE: When disconnecting the socket from the plug, do not hold the cord but hold the socket.
-
Page 12: Overload Protection
Control panel NOTICE: Do not insert the socket forcibly. If the socket cannot be inserted easily, it is not being inserted correctly. The control panel has the main power switch and the mode switching button. NOTICE: When disconnecting the socket from the plug, do not hold the cord but hold the socket. -
Page 13: Adjusting The Mowing Height
If you notice anything unusual with either of the Remove the lock key, and then pull the mowing height lock key or switch, stop the operation immediately and adjusting lever outward of the mower body and move it have them checked by your nearest Makita Authorized to your desired mowing height. Service Center. 13 ENGLISH... - Page 14 Grass level indicator Grass level indicator shows the volume of mowed grass. When the grass basket is not full, the indicator floats while the blades are running. ► 1 . Mowing height adjusting lever The table below shows the relationship between the ► 1 . Grass level indicator number on the mower body and the approximate mow- ing height.
-
Page 15: Adjusting The Handle Height
Electric brake This machine is equipped with an electric brake. If the machine consistently fails to quickly stop the mower blades after releasing the switch lever, have the machine serviced at Makita Authorized Service Center. ► 1 . Speed lever The traveling speed can be adjusted with the speed lever. -
Page 16: Operation
OPERATION Mowing WARNING: Before mowing, clear away sticks and stones from mowing area. Furthermore, clear away any weeds from mowing area in advance. WARNING: Always wear the safety goggles or safety glasses with side shields when operating the mower. CAUTION: If the cut grass or foreign object blocks up inside of the mower body, be sure to remove the lock key and battery cartridge and... -
Page 17: Emptying The Grass Basket
NOTICE: Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. 17 ENGLISH... -
Page 18: Carrying The Mower
Removing the mower blade Carrying the mower For models equipped with straight mower When carrying the mower, hold the front grip and rear blade grip with two people as shown in the figure. Put the mower on its side so that the mowing height adjusting lever comes to the upper side. To lock the blade, insert the pin into a hole on the mower body. - Page 19 For models equipped with swing back To remove the individual mower blade, turn the bolt counterclockwise with box wrench 17 while holding mower blades the base plate. Put the mower on its side so that the mowing height adjusting lever comes to the upper side. To lock the base plate, insert the pin into a hole on the mower body through a hole on the base plate.
-
Page 20: Troubleshooting
To install the mower blades, perform the removal proce- dure in reverse. TROUBLESHOOTING Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to disassemble the machine. Instead, ask Makita Authorized Service Centers, always using Makita replacement parts for repairs. State of abnormality Probable cause (malfunction) Remedy Mower does not start. - Page 24 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885868-229 www.makita.com 20201215...
