Sun Cluster 3.0-3.1 With Sun
StorEdge 3510 or 3511 FC RAID
Array Manual
For Solaris OS
Sun Microsystems, Inc.
4150 Network Circle
Santa Clara, CA 95054
U.S.A.
Part No: 817–1673–15
January 2006, Revision A

Advertisement

Table of Contents
loading

Related Manuals for Sun Microsystems StorEdge 3510

Summary of Contents for Sun Microsystems StorEdge 3510

  • Page 1 Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual For Solaris OS Sun Microsystems, Inc. 4150 Network Circle Santa Clara, CA 95054 U.S.A. Part No: 817–1673–15 January 2006, Revision A...
  • Page 2 Etats-Unis et dans d’autres pays; elle est licenciée exclusivement par X/Open Company, Ltd. Sun, Sun Microsystems, le logo Sun, le logo Solaris, le logo Java Coffee Cup, docs.sun.com, Java et Solaris sont des marques de fabrique ou des marques déposées de Sun Microsystems, Inc.

  • Page 3: Table Of Contents

    Contents Preface Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays Installing Storage Arrays Storage Array Cabling Configurations M How to Install a Storage Array Adding a Storage Array to a Running Cluster M How to Perform Initial Configuration Tasks on the Storage Array...
  • Page 4 Index Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 5: Preface

    Preface The Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual provides procedures specific to Sun StorEdge™ 3510 and 3511 FC RAID storage arrays placed in a Sun™ Cluster environment. Use this manual with any version of Sun Cluster 3.0 or 3.1 software on SPARC™...
  • Page 6 All Sun Cluster documentation is available at http://docs.sun.com. Documentation that is not available at http://docs.sun.com is listed with the appropriate URL. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...
  • Page 7 Sun StorEdge 3000 Family RAID Firmware 4.1x User’s Guide 817–3711 Sun StorEdge 3000 Family Best Practices Manual 816–7325 Sun StorEdge 3510 FC Array Release Notes 816-7301 Sun StorEdge 3511 FC Array with SATA Release Notes 817–6597 Sun StorEdge 3000 Family FRU Installation Guide...
  • Page 8 Displays system diagnostic information prtdiag -v Displays Sun Cluster release and package version /usr/cluster/bin/scinstall information Also have available the contents of the /var/adm/messages file. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...
  • Page 9 Documentation, Support, and Training The Sun web site provides information about the following additional resources: Documentation (http://www.sun.com/documentation/) Support (http://www.sun.com/support/) Training (http://www.sun.com/training/) Typographic Conventions The following table describes the typographic conventions that are used in this book. Typographic Conventions TABLE P–4 Typeface Meaning Example...
  • Page 10 For information about the training courses that Sun offers and to enroll in a class, visit Sun Training at http://training.sun.com/. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 11: Installing And Maintaining Sun Storedge 3510 And 3511 Fibre Channel Raid Arrays

    CHAPTER Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays This chapter describes the procedures for installing, configuring, and maintaining the Sun™ StorEdge™ 3510 FC RAID array and the Sun StorEdge 3511 FC RAID array with SATA in a Sun™ Cluster environment. This chapter contains the following main topics: “Installing Storage Arrays”...

  • Page 12: Storage Array Cabling Configurations

    Node A Node C Node B Node D Sun StorEdge 3510 Direct Attach Storage (DAS) Configuration With Multipathing and Two FIGURE 1–1 Controllers Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...
  • Page 13 The two-controller SAN configurations allow 32 LUNs to be mapped to each pair of host channels. Since these configurations use multipathing, each node sees a total of 64 LUNs. Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...
  • Page 14 Node B Node C Node D Switch 1 Switch 2 Sun StorEdge 3510 SAN Configuration With Multipathing and Two Controllers FIGURE 1–3 Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 15: M How To Install A Storage Array

    This procedure assumes that the hardware is not connected. Before You Begin If you plan to attach a StorEdge 3510 or 3511 FC expansion storage array to a Note – StorEdge 3510 or 3511 FC RAID storage array, attach the expansion storage array before connecting the RAID storage array to the cluster nodes.
  • Page 16 Sun’s EarlyNotifier web pages. The EarlyNotifier web pages list information about any required patches or firmware levels that are available for download. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 17: Adding A Storage Array To A Running Cluster

    If you need to add a storage array to more than two nodes, repeat the steps for each additional node that connects to the storage array. Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...

  • Page 18: M How To Perform Initial Configuration Tasks On The Storage Array

    1. Install the SFPs in the storage array that you plan to add. Steps For the procedure on installing an SFP, see the Sun StorEdge 3000 Family Installation, Operation, and Service Manual. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 19: M How To Connect The Node To The Fc Switches Or The Storage Array

    5. Connect fiber-optic cables between the node and the FC switches or the storage array. For the procedure on installing a fiber-optic cable, see the Sun StorEdge 3000 Family Installation, Operation, and Service Manual. Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...
  • Page 20 “How to Install Sun Multipathing Software” in Sun Cluster Software Installation Guide for Solaris OS and follow the troubleshooting steps to clean up the device IDs. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 21: Configuring Storage Arrays In A Running Cluster

    Create a LUN “How to Create and Map a LUN” on page 22 Remove a LUN “How to Unmap and Remove a LUN” on page 23 Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...

  • Page 22: M How To Create And Map A Lun

    4. On one node that is connected to the storage device, use the format command to label the new LUN. 5. From any node in the cluster, update the global device namespace. # scgdevs Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 23: M How To Unmap And Remove A Lun

    # luxadm probe # scdidadm -L pathname 2. Is the LUN that you will remove a quorum device? # scstat -q If no, proceed to Step Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...

  • Page 24: Maintaining Storage Arrays

    Maintenance tasks are listed in Table 1–3 contain cluster-specific tasks. Tasks that are not cluster-specific are referenced in a list following the table. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...
  • Page 25 Replace the power cord of an FC switch. “Replacing a Node-to-Switch Component” on page 31 Replace the controller. “Replacing a Node-to-Switch Component” on page 31 Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...

  • Page 26: Storedge 3510 And 3511 Fc Raid Array Frus

    Steps 1. Does the storage array you are removing contain any quorum devices? # scstat -q If no, proceed to Step Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...
  • Page 27 10. Remove the host adapters from the node. For the procedure on removing host adapters, see the documentation that shipped with your host adapter and nodes. Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...

  • Page 28: M How To Upgrade Storage Array Firmware

    Refer to the Sun StorEdge 3000 Family RAID Firmware 3.25 and 3.27 User’s Guide and to any patch readme files for more information. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 29: M How To Replace A Disk Drive

    If yes, use volume manager commands to reattach the submirror or plex. For more information, see your Solstice DiskSuite/Solaris Volume Manager or VERITAS Volume Manager documentation. Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...

  • Page 30: M How To Replace A Host Adapter

    If yes, boot Node A into noncluster mode. Proceed to Step For more information about how to boot nodes, see your Sun Cluster system administration documentation. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 31: Replacing A Node-To-Switch Component

    Replacing a Node-to-Switch Component Use this procedure to replace a node-to-switch component that has failed or that you suspect might be contributing to a problem. Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...

  • Page 32: M How To Replace A Node-To-Switch Component In A Cluster That Uses Multipathing

    How to Replace a Node-to-Switch Component in a Cluster Without Multipathing 1. Check if the physical data path failed. Steps If no, proceed to Step If yes: Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...

  • Page 33: M How To Replace A Chassis In A Running Cluster

    3. Replace the chassis and backplane. For the procedure on replacing a chassis, see the Sun StorEdge 3000 Family Installation, Operation, and Service Manual. Chapter 1 • Installing and Maintaining Sun StorEdge 3510 and 3511 Fibre Channel RAID Arrays...
  • Page 34 If the WWNs change, and you must reconfigure your volume manager software to recognize the new WWNs. For more information, see your Solstice DiskSuite or VERITAS Volume Manager documentation. Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...
  • Page 35 Index help, 8 host adapters, replacing, 30-31 adding nodes, 26 storage array s, 17-20 arrays, See storage array s installing See also adding storage array s, 11-20 configuring, storage arrays, 21-24 cooling units, replacing, 26 creating, LUNs, 22-23 LUNs creating, 22-23 mapping, 22-23 disk drives, replacing, 29 removing, 23-24...
  • Page 36 17-20 configuring, 21-24 installing, 11-20 maintaining, 24-34 removing, 26-28 upgrading firmware, 28-29 technical support, 8 training, 10 upgrading, storage array firmware, 28-29 Sun Cluster 3.0-3.1 With Sun StorEdge 3510 or 3511 FC RAID Array Manual • January 2006, Revision A...
