Canon imagePROGRAF iPF8300 Setup Manual page 8

10
In the Method of Configuring IP Addresses window, enter the IP
address in Configure manually, under Method of Configuring
IP Addresses. Click Install to start the installation process. Also
enter your preferred name for the printer in Device Name and the
installation location in Printer Location under Information About
Printer to Configure, as desired.
The installation process begins.
11
After reviewing the installation results in
the Complete Installation window, click
Next.
When the printer cannot be found on the network
If your printer cannot be found when connecting to
the network for the first time, setup an IP address
for the printer and then configure it on the printer.
When ink fills the system for the first time, after
printhead adjustment is finished, specify the IP
address on the printer's control panel.
• When ink fills the system for the first
time, do not operate the printer until
printhead adjustment is finished.
4
Enter the IP address. Navigate through
the following menus using the ▲ and ▼
keys on the control panel.
1. Select IPv4 and press OK.
2. Select IPv4 Settings and press OK.
3. Select IP Address and press OK.
4. Enter the IP address.
7
In the Search Results window, select
Specify the IP address of available
printers in the network and click Next.
The IP Address Specification window
appears. Follow steps 8-11 on page 10 to
finish installing the printer driver.
12
In the Finish window, select Restart my
computer now and click Restart.
1
On the tab selection screen of the control
panel, press the and
(settings/adj. tab) and press OK.
No Paper Loaded
OK:Setting/Adj. Menu
Maint. cart.
Remaining Amount
How to enter IP addresses
1. Press the and keys to select a
MEMO
field for inputting values.
2. Use the ▲ and ▼ keys to input values.
• Pressing ▲ increases the value by
one.
• Pressing ▼ decreases the value by
one.
• Holding down either the ▲ or ▼ keys
continually increases or decreases
the value.
3. Press OK once you have finished.
• If the following screen appears, click
Retry and select Specify the IP
MEMO
address of available printers in
the network on the next screen that
appears.
8
• If you use a DHCP server for automatic assignment of the printer's IP
address, printing may no longer be possible after the printer is turned
off and on. This is because a different IP address has been assigned.
When using DHCP server functions, consult your network administrator
and configure the settings in one of the following ways:
• Configure the setting for dynamic DNS updating
In the printer menu, either set DNS Dync update to On, or activate the
setting Enable DNS Dynamic Update in RemoteUI.
(→"Menu Settings", User Manual)
(→"Configuring the Printer's TCP/IP Network Settings", User Manual)
• Configure the setting for assignment of the same IP address each time
the printer starts up
13
The printer driver settings take effect after
the computer restarts. This completes
printer driver installation.
An iPFxxxx Support desktop icon
is created after installation. (iPFxxxx
represents the printer model.)
Next, follow steps 12-16 on page 6 to install
the User Manual.
2
Use the ▲ and ▼ keys to select Interface
keys to select Setup and press OK.
3
Use the ▲ and ▼ keys to select TCP/IP
and press OK.
5
Press Menu.
6
Press OK on the registration confirmation
message that appears.
The IP address is set on the printer.
Next, restart installation of the printer
driver.
Next, follow steps 12-16 on page 6 to install
the User Manual.
