Operating Instructions
Wi-Fi Direct Guide
For safe and correct use, be sure to read Safety Information separately
provided before using the machine.

Advertisement

Table of Contents
loading

Related Manuals for Ricoh P 310

Summary of Contents for Ricoh P 310

  • Page 1 Operating Instructions Wi-Fi Direct Guide For safe and correct use, be sure to read Safety Information separately provided before using the machine.

  • Page 3: Table Of Contents

    P 310/311/M 320............................5 Connecting Using Mac............................8 M 320FB/320F.............................8 P 310/311/M 320............................9 Connecting Using Android Device......................... 11 M 320FB/320F............................11 P 310/311/M 320........................... 12 Connecting Using iOS Device........................14 M 320FB/320F............................14 P 310/311/M 320........................... 16 2. Troubleshooting Connection Problems............................19 Connection has Succeeded but the Wireless LAN Cannot be Used............

  • Page 4: How To Read The Manuals

    How to Read the Manuals Symbols Used in the Manuals This manual uses the following symbols: Indicates points to pay attention to when using the machine, and explanations of likely causes of paper misfeeds, damage to originals, or loss of data. Be sure to read these explanations. Indicates supplementary explanations of the machine’s functions, and instructions on resolving user errors.

  • Page 5: Easy Setup Using Wi-Fi Direct

    1. Easy Setup Using Wi-Fi Direct This chapter describes basic troubleshooting procedures. Checking the SSID • Before turning on the machine, insert the wireless LAN option into the USB port on the back of the machine. • Before doing the following procedure, install the printer driver. For details, see Setup Guide. •...

  • Page 6: Connecting Using Windows

    1. Easy Setup Using Wi-Fi Direct Connecting Using Windows M 320FB/320F • Before doing the following procedure, enable the Wi-Fi Direct function on your computer. For details about enabling the Wi-Fi Direct function, see the computer manual. • In Steps 5 to 8, configure each setting within two minutes. Press the wireless LAN icon.
  • Page 7 Confirm the status of the selected SSID changes to "Connected". Configuring the Wi-Fi settings is complete. P 310/311/M 320 • Before doing the following procedure, enable the Wi-Fi Direct function on your computer. For details about enabling the Wi-Fi Direct function, see the computer manual.
  • Page 8 1. Easy Setup Using Wi-Fi Direct Press the [Wi-Fi Direct] key. M 320 DYG612 P 310/311 DYG613 The LED of the [Wi-Fi Direct] key starts flashing.
  • Page 9 Connecting Using Windows Select the SSID (DIRECT-XXXXXX) of the machine from available wireless connection in your computer, and then click [Connect]. DYG620 A window for entering the encryption key opens. Enter the encryption key for Wi-Fi Direct. The default encryption key is "admin123". For details about changing the encryption key, see page 21 "How to Change the Encryption Key of Wi-Fi Direct".

  • Page 10: Connecting Using Mac

    1. Easy Setup Using Wi-Fi Direct Connecting Using Mac M 320FB/320F • In Steps 5 to 11, configure each setting within two minutes. Press the wireless LAN icon. DYG611 Enter the password using the number keys, and then press [OK]. Press [Wireless (Wi-Fi) Sett.].
  • Page 11 Connecting Using Mac P 310/311/M 320 • In Steps 1 to 7, configure each setting within two minutes. Press the [Wi-Fi Direct] key. M 320 DYG612 P 310/311 DYG613 The LED of the [Wi-Fi Direct] key starts flashing. Start System Preferences in your computer.
  • Page 12 1. Easy Setup Using Wi-Fi Direct For details about changing the encryption key, see page 21 "How to Change the Encryption Key of Wi-Fi Direct". The LED of the [Wi-Fi Direct] key stops flashing and it lights up. Confirm the status of the selected SSID changes to "Connected". Configuring the Wi-Fi settings is complete.

  • Page 13: Connecting Using Android Device

    Connecting Using Android Device Connecting Using Android Device M 320FB/320F • In Steps 5 to 12, configure each setting within two minutes. Press the wireless LAN icon. DYG611 Enter the password using the number keys, and then press [OK]. Press [Wireless (Wi-Fi) Sett.]. Press [Wi-Fi Direct].
  • Page 14 1. Easy Setup Using Wi-Fi Direct P 310/311/M 320 • In Steps 1 to 8, configure each setting within two minutes. Press the [Wi-Fi Direct] key. M 320 DYG612 P 310/311 DYG613 The LED of the [Wi-Fi Direct] key starts flashing.
  • Page 15 Connecting Using Android Device For details about changing the encryption key, see page 21 "How to Change the Encryption Key of Wi-Fi Direct". The LED of the [Wi-Fi Direct] key stops flashing and it lights up. Confirm the string under the SSID of the machine changes to "Connected". Configuring the Wi-Fi settings is complete.

  • Page 16: Connecting Using Ios Device

    1. Easy Setup Using Wi-Fi Direct Connecting Using iOS Device M 320FB/320F • In Steps 5 to 10, configure each setting within two minutes. Press the wireless LAN icon. DYG611 Enter the password using the number keys, and then press [OK]. Press [Wireless (Wi-Fi) Sett.].
  • Page 17 Connecting Using iOS Device Tap [Settings] in your iOS device. DYG614 Tap [Wi-Fi]. DYG615...
  • Page 18 For details about changing the encryption key, see page 21 "How to Change the Encryption Key of Wi-Fi Direct". Confirm the selected SSID is checked. Configuring the Wi-Fi settings is complete. P 310/311/M 320 • In Steps 1 to 6, configure each setting within two minutes. Press the [Wi-Fi Direct] key. M 320...
  • Page 19 Connecting Using iOS Device P 310/311 DYG613 The LED of the [Wi-Fi Direct] key starts flashing. Tap [Settings] in your iOS device. DYG614...
  • Page 20 1. Easy Setup Using Wi-Fi Direct Tap [Wi-Fi]. DYG615 Tap the SSID (DIRECT-XXXXXX) of the machine. DYG616 The screen for entering an encryption key is displayed. Enter the encryption key of Wi-Fi Direct, and then tap "Join". The default encryption key is "admin123". For details about changing the encryption key, see page 21 "How to Change the Encryption Key of Wi-Fi Direct".

  • Page 21: Troubleshooting

    2. Troubleshooting This chapter describes basic troubleshooting procedures. Connection Problems Problem Possible cause Solution Problems occur even The SSID or encryption Check that the SSID or encryption key is after you configure the key is not entered entered correctly. connection settings correctly.

  • Page 22: Connection Has Succeeded But The Wireless Lan Cannot Be Used

    2. Troubleshooting Connection has Succeeded but the Wireless LAN Cannot be Used Problem Possible cause Solution A connection has been An Ethernet cable is If Ethernet and wireless LAN are both established but the connected to the connected, Ethernet has priority. To use the wireless LAN cannot be machine.

  • Page 23: Appendix

    3. Appendix This appendix describes trademarks for the machine. How to Change the Encryption Key of Wi-Fi Direct M 320FB/320F You can change the encryption key of Wi-Fi Direct by using the control panel, Web Image Monitor, or Smart Organizing Monitor. Configuring Settings Using the Control Panel Press the wireless LAN icon.
  • Page 24 3. Appendix Click [Network Settings]. DYG617 Click the [Wireless] tab. Enter the encryption key in [WPA Passphrase] under [Wi-Fi Direct Settings]. Click [OK]. Enter the administrator password. Close your web browser. Turn off the machine, and then turn it back on. Configuring Settings Using Smart Organizing Monitor Install and start Smart Organizing Monitor.
  • Page 25 Press the [ ] or [ ] key to select [Wi-Fi Direct PWD], and then press the [OK] key. Press the number keys (M 320) or the scroll keys (P 310/311) to enter the password of Wi-Fi Direct, and then press the [OK] key.
  • Page 26 3. Appendix Click [Network Settings]. DYG618 Click the [Wireless] tab. Enter the encryption key in [WPA Passphrase] under [Wi-Fi Direct Settings]. Click [OK]. Enter the administrator password. Close your web browser. Turn off the machine, and then turn it back on. Configuring settings using Smart Organizing Monitor Install and start Smart Organizing Monitor.
  • Page 27 How to Change the Encryption Key of Wi-Fi Direct Enter the access code, and then click [OK]. The default access code is "Admin". Click the [Network 1] tab. Enter the encryption key in [Wi-Fi Direct Password:]. Click [OK]. If the confirmation message is displayed, click [OK]. Click [Close].

  • Page 28: Trademark

    3. Appendix Trademark Android is a trademark of Google LLC. IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license. Wi-Fi, Wi-Fi Direct are registered trademarks of Wi-Fi Alliance. Mac is a trademark of Apple Inc., registered in the United States and other countries. Microsoft, Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries/regions.
  • Page 29 MEMO...
  • Page 30 MEMO M0ER-8508...
  • Page 32 EN GB EN US EN AU M0ER-8508 © 2021 Ricoh Co., Ltd.
