C Series

Specifications

C 88:4 C 68:4
Model
Number of channels 4 4
Peak total output all channels driven 8800 W 6800 W
Peak output voltage per channel 141 V 141 V
35.5 24.5
Max. output current per channel
Arms Arms
Max Output Power
16 ohms per ch. (all ch.'s driven) 650 W 650 W
8 ohms per ch. (all ch.'s driven) 1250 W 1200 W
4 ohms per ch. (all ch.'s driven) 2100 W 1700 W
2 ohms per ch. (all ch.'s driven) 2200 W 1200 W
Hi-Z per ch. (all ch.'s driven): 70 Vrms / 100 V peak 2200 W 1600 W
Hi-Z per ch. (all ch.'s driven): 100 Vrms / 141 V peak 1700 W 1200 W
1)
16 ohms Bridged per ch. 2500 W 2400 W
8 ohms Bridged per ch. 1) 4200 W 3400 W
4 ohms Bridged per ch. 1) 4400 W 2400 W
2 ohms Bridged per ch. 1) n.r 4) n.r 4)
Hi-Z Bridged per ch. 1) : 140 Vrms / 200 V peak 4400 W 3200 W
Performance with Gain: 35 dB and VPL: 100 V / C 88:4: 35 dB and VPL: 141 V
THD 20 Hz - 20 kHz for 1 W <0.1%
THD at 1 kHz and 1 dB below clipping <0.05%
Signal To Noise Ratio >112 dBA
Channel separation (Crosstalk) at 1 kHz >70 dB
Frequency response (1 W into 8 ohms) +0/-3 dB 6.8 Hz - 34 kHz
Input impedance 20 kOhm
Common Mode Rejection (CMR) >50 dB, 20 Hz - 20 kHz
Output impedance @ 100 Hz 30 mOhm
Voltage Peak Limiter (VPL), max. peak output
VPL, selectable per ch. 3) 141, 118, 100, 85, 71, 59, 50, 42 V
VPL, when bridged 1) 3) 282, 236, 200, 170, 142, 118, 100, 84 V
Voltage Peak Limiter mode (per ch.) Hard / Soft
Gain and Level
Amplifier gain selectable (all channels) 1)
23, 26, 29, 32, 35, 38, 41, 44 dB
– rear-panel switches
Default gain 35 dB
Front-panel potentiometer, 21 position detented from -inf to 0 dB,
Level adjustment (per ch.)
hidden behind security panel/dust filter grille
Connectors and switches
Input connectors (per ch.) 3-pin Phoenix, electronically balanced
Output connectors (per ch.) Barrier strip 2-pole screw terminals
Output bridge mode A+B and/or C+D, inputs A and C are input source
High pass filter N/A
NomadLink network On board, 2 x RJ45 connectors IN and OUT
Intelligent fans (on/off) Yes, depending on presence of output signal
Power on/off and Remote enable on/off Individual switches on front panel
Cooling Two fans, front-to-rear airflow, temperature controlled speed
General Purpose Outputs (GPO) N/A
General Purpose Inputs (GPI) N/A
C 48:4 C 28:4 C 16:4 C 20:8X C 10:8X C 10:4X
4 4 4 8 8 4
4800 W 2800 W 1600 W 2000 W 1000 W 1000 W
141 V 141 V 141 V 100 V 100 V 100 V
17.5 12 8.5
8 Arms 5.6 Arms 8 Arms
Arms Armss Arms
625 W 600 W 400 W 250 W 125 W 250 W
1000 W 700 W 400 W 250 W 125 W 250 W
1200 W 700 W 300 W 250 W 125 W 250 W
600 W 300 W 140 W 125 W 60 W 125 W
1100 W 700 W 400 W 250 W 125 W 250 W
900 W 700 W 400 W n.a. n.a. n.a.
2000 W 1400 W 800 W 500 W 250 W 500 W
2400 W 1200 W 600 W 500 W 250 W 500 W
1200 W 600 W n.r 4) 250 W 125 W 250 W
n.r 4) n.r 4) n.r 4) n.r 4) n.r 4) n.r 4)
1800 W 1400 W 800 W 500 W 250 W 500 W
32 dB and VPL: 100 V
<0.1%
<0.05%
>112 dBA
>70 dB
6.8 Hz - 34 kHz
20 kOhm
>50 dB, 20 Hz - 20 kHz
48 mOhm
100, 63, 45, 32 V
200, 126, 90, 64 V
Hard / Soft
29, 32, 35, 38 dB
32 dB
Front-panel potentiometer, 21 position detented from -inf
to 0 dB, hidden behind security panel/dust filter grille
3-pin Phoenix, electronically balanced
Barrier strip 2-pole screw terminals
A+B, C+D, E+F, G+H, inputs A, C, E, G are signal source
Fixed at 35 Hz, switchable per channel
On board, 2 x RJ45 connectors, IN and OUT
Yes, depending on presence of output signal
Individual switches on front panel
Two fans, front-to-rear airflow, temperature controlled
speed
Contact Closure types, 2-pole Phoenix
Contact Closure types, 2-pole Phoenix
C 5:4X
Front-panel indicators
Common
4
500 W
100 V Per channel
5.6 Arms
Power
Operating voltage, 230 V / 115 V nominal
125 W
Minimum power-up voltage, 230 V / 115 V
125 W Power Average Limiter (PAL) 2)
125 W Power Factor Correction (PFC)
60 W Soft-start / Inrush Current Draw
125 W
5)
Mains connector
n.a.
250 W
Dimensions
250 W
Weight
125 W
Finish
n.r 4)
250 W
Note 1): Automatic -6 dB gain compensation when bridging channels. Ch.'s A+B and/or C+D, E+F, G+H, can be bridged individually.
Note 2): PAL can reduce the maximum output power to keep the power supply operating safely, and/or to prevent excessive current draw tripping the mains breaker.
Refer to Operation Manual.
Note 3): For sine waves, peak voltage output values translate to Vrms with the formula V/1.41 = Vrms. E.g. 100 V peak equals app. 70 V peak. Hence, outputs can be
set for high-impedance loads without requiring a transformer.
Note 4): Regarding n.r. (not recommended) notes: The amplifier will be fully operational in bridge-mode into 2 ohm and high impedance (Hi-Z) loads, but due to
physical constraints in the construction, the max. output power will not be significanty higher than running individual channels and therefore this mode of
operation is not recommended.
Note 5): C 88:4 mains connector: 30 A Twist lock.
Note 6): Separate 230 V or 115 V versions available. Not selectable on the amplifier.
All specifications are subject to change without notice.
C 88:4 C 68:4 C 48:4 C 28:4 C 16:4 C 20:8X
NomadLink Network; Power Average Limiter (PAL)
NomadLink Network; Power Average Limiter (PAL) 2) ; Power on
Power on
Signal present / High-impedance; -10 dB and -4 dB output Signal present / High-impedance; Voltage Peak Limiter
signal;Voltage Peak Limiter (VPL); Current Peak Limiter (CPL): Very High (VPL); Current Peak Limiter (CPL): Very High Frequency
Frequency (VHF); High temperature; Fault; Mute (VHF); High temperature; Fault; Mute
130-265 V / 65 -135 V 6) Universal power supply 65-265 V
171 V / 85 V 80 V
Yes Yes
No Yes
Yes / max. 5 A Yes / max. 5 A
230 V CE: 16 A, CEE7; 115 V ETL: 20 A / NEMA 5-20P; C16:4: 15A/NEMA
IEC Inlet
5-15P
W: 483 mm (19"), H: 88 mm (2 U), D: 343 mm (13.5") W: 483 mm (19"), H: 88 mm (2 U), D: 343 mm (13.5")
12 kg (26.4 lbs.) 8.5 kg (18.75 lbs.)
Black painted steel chassis with gray painted steel front Black painted steel chassis with gray painted steel front
