26
C Series
Line Current *2)
Level
Load
Rated power
115 VAC
Standby with remote power off via NomadLink
Powered on, idling.
Pink noise
8 Ω / Ch.
1200 x 4
16.0
(1/8 rated power)
16 Ω / Bridged
2400 x 2
4 Ω / Ch.
1700 x 4
22.4
8 Ω / Bridged
3400 x 2
2 Ω / Ch.
1200 x 4
21.2
4 Ω / Bridged
2400 x 2
100 V / Ch.
1600 x 4
21.0
200 V / Bridged
3200 x 2
Pink noise
8 Ω / Ch.
1200 x 4
32.6
(1/4 rated power)
16 Ω / Bridged
2400 x 2
*3)
4 Ω / Ch.
1700 x 4
38.8
8 Ω / Bridged
3400 x 2
4 Ω / Ch.
1200 x 4
35.2
8 Ω / Bridged
2400 x 2
100 V / Ch.
1600 x 4
35.4
200 V / Bridged
3200 x 2
Mains connector, 230 V CE version
16 A, CEE7
Mains connector, 115 V ETL version
20 A / 5-20P
*1) The amplifier's PSU operates as a non-resistive load, so the calculation "Volts x Amps = Watts" would not be correct. Instead, measured and specified here is what
is known as the "Active Power" in the amplifier providing useful, real-world values of power consumption and heat dissipation.
*2) Current draw figures measured at 230 V. 115 V figures are 230 V figures multiplied by two.
*3) Figures measured at maximum power before amplifier protection and limiter features are engaged. Typically this is between 1/4 and 1/3 of rated power. Note that
the max. power condition is very extreme and will not occur during normal operation. Also note that the mains breaker will not be tripped even if operation is in excess
of max. ratings.
C 68:4
Watt *1)
Thermal Dissipation
230 VAC
In
Out
Dissipated
BTU/hr
0
0
0
0
133
0
133
454
Amp (I)
Watt
8.0
1123
600
523
1784
11.2
1578
850
728
2484
10.6
1378
600
778
2655
10.5
1463
800
663
2262
16.3
2429
1600
829
2829
19.4
2697
1700
997
3402
17.6
2296
1200
1096
3740
17.7
2605
1600
1005
3429
Level
Load
kCal/hr
0
Standby with remote power off via NomadLink
114
Powered on, idling.
Pink noise
8 Ω / Ch.
450
(1/8 rated power)
16 Ω / Bridged
4 Ω / Ch.
626
8 Ω / Bridged
2 Ω / Ch.
669
4 Ω / Bridged
100 V / Ch.
570
200 V / Bridged
713
Pink noise
8 Ω / Ch.
(1/4 rated power)
16 Ω / Bridged
*3)
4 Ω / Ch.
857
8 Ω / Bridged
4 Ω / Ch.
942
8 Ω / Bridged
864
100 V / Ch.
200 V / Bridged
Mains connector, 230 V CE version
Mains connector, 115 V ETL version
*1) The amplifier's PSU operates as a non-resistive load, so the calculation "Volts x Amps = Watts" would not be correct. Instead, measured and specified here is what
is known as the "Active Power" in the amplifier providing useful, real-world values of power consumption and heat dissipation.
*2) Current draw figures measured at 230 V. 115 V figures are 230 V figures multiplied by two.
*3) Figures measured at maximum power before amplifier protection and limiter features are engaged. Typically this is between 1/4 and 1/3 of rated power. Note that
the max. power condition is very extreme and will not occur during normal operation. Also note that the mains breaker will not be tripped even if operation is in excess
of max. ratings.
C 48:4
Line Current *2)
Watt *1)
Rated power
115 VAC
230 VAC
In
Out
0
0
123
0
Amp (I)
Watt
1000 x 4
13,8
6,9
945
500
2000 x 2
1200 x 4
17,4
8,7
1171
600
2400 x 2
600 x 4
12,4
6,2
769
300
1200 x 2
900 x 4
13,2
6,6
840
450
1800 x 2
1000 x 4
28,2
14,1
2116
1333
2000 x 2
1200 x 4
30,6
15,3
2168
1200
2400 x 2
600 x 4
21,6
10,8
1368
600
1200 x 2
900 x 4
26,4
13,2
1827
1200
1800 x 2
16 A, CEE7
20 A / 5-20P
27
Quick Start Guide
Thermal Dissipation
Dissipated
BTU/hr
kCal/hr
0
0
0
123
420
106
445
1518
383
571
1948
491
469
1600
403
390
1331
335
783
2670
673
968
3303
832
768
2620
660
627
2139
539
