FA Series

Specifications

FA602
Maximum Output Power
4 or 8 Ω per channel 60 W
Number of Ouput Channels
Number
Minimun Load Impedance
4 Ω mode
8 Ω mode
70 V output mode 82 Ω
100 V output mode 166 Ω
Controls
Front
Rear Gain control, input sensitivty select (4 dBu / -10 dBV), load config (4 Ω / 8 Ω / 70 V / 100 V), switchable 80 Hz high-pass filter
Indicators
Power
Limit (red LED), per channel
Signal (green LED), per channel
Fault (red LED)
System
Inputs
Input impedance
Input sensitivty
Maximum input level
Outputs
Output circuit type
Remote connector
Performance
Distortion, 1/8 rated power
Frequency response
Crosstalk
Signal-to-noise
High-pass filter
Circuit Protection
Cooling
Amplifier protection Thermal protection, over current protection, DC protection, high frequency protection
Load protection
Power Supply, Voltage
Main voltage
Power consumption 1/8th rated power @ 4 Ω 50 W
Mains connector
Dimensions / Weight
Dimensions (H x W x D)
Weight
Finish Brushed black anodized aluminum chassis with black painted steel bottom
Approvals CE, WEEE, CCC, cTUVus, PSE, RCM, RoHS, FCC part 15 Class B, Energy Star 3.0
FA1202 FA2402
120 W 240 W
2
4 Ω
8 Ω
41 Ω 20 Ω
82 Ω 41 Ω
N/A
On (blue), standby (yellow)
Input clip, output limit
>1.23 mV (-56 dBu)
Overheat, DC fault, over current etc
2 x 3-pin 5.08 mm Euroblock connector
10 kΩ unbalanced, 20 kΩ balanced
Balanced: 1.23 V (+4 dBu) or 316 mV (-10 dBV)
9.75 V (+22 dBu)
1 x 4-pin 5.08 mm Euroblock connector
Class D
2 x RJ45 Ethernet connector
<0.5%
20 Hz to 20 kHz, +0.5 / -1 dB
>65 dB
>100 dBA
80 Hz HPF
Convection-cooled, fanless
Controlled start and shutdown behaviour, DC-fault protection
100-240 V~, 50/60 Hz with active power factor correction
70 W 120 W
Standard IEC connector
44 x 218 x 280 mm (1.7 x 8.6 x 11.0")
2.6 kg (5.7 lbs)
