Summary of Contents for HP Compaq Presario,Presario 700
Page 1
Presario 700 System Boards (w/o processor) Assembly 486 System Board, 4 MB 004105 004259 486 System Board, 8 MB 004093 004842 586 System Board, P5, 8 004378 586 System Board, P54C, 004447 8 MB 004654 Presario 720, CDS 720, 724, CDTV 720. Presario CDS 762.
Page 2
Presario 700 System Configuration Jumper Settings (004093, 004842) Jumper Function Setting Clock Select 1 - 2 2 - 3 DX4 Core Speed 1 - 2 2 - 3 CMOS Power 1 - 2 Open Configuration Jumpers for 586 Models (004378, 004447, 004654) Jumper Function Setting...
Page 3
Presario 700 Hard Drives Type Inter-leave 270 MB, IDE 65/66 420 MB, IDE 540 MB, IDE 725 MB, IDE Presario CDS 720, 724, CDTV720. Presario CDS 742; CDTV 720. Presario CDS 744, 762, 772, 774, CDTV 748. “ Hard Drive Select” cable required. CD-ROM Drive CD-ROM, IDE, 2-speed CD-ROM, IDE, 4-speed...
Page 4
Presario 700 Cable Information LED Cable/Assembly Audio External CPU/Audio Module Audio Internal CD-ROM/System Board Audio Internal PCTV/System Board Diskette Drive Cable Hard Drive Data/CD ROM Cable Serial Port Cable Telephone Cable TV Loopback Cable TV Cable Adapter Video Internal TV Board to System Board Cable ROM Information Board Assembly System...
Page 5
Presario 700 Memory Upgrade Chart 486 SYSTEM BOARD W/4 MB MEMORY (004105-101, 004259-101) ADD ANY OF THE FOLLOWING UP TO 100-MB TOTAL SYSTEM MEMORY. Use SIMMs with gold contacts only. 4-MB MEMORY MODULE (70ns) OPTION PN 147522-001 8-MB MEMORY MODULE (70ns) OPTION PN 147523-001 16-MB MEMORY MODULE (70ns) OPTION PN 147524-001 32-MB MEMORY MODULE (70ns) OPTION PN 147525-001 Volume Two...
Page 6
Presario 700 Memory Upgrade Chart 486 SYSTEM BOARD W/8 MB MEMORY 004093, 004842 ADD ANY COMBINATION OF THE FOLLOWING MEMORY MODULES, UP TO 104 MEGABYTES TOTAL SYSTEM MEMORY. Use SIMMs with gold contacts only. 4-MB 70ns - OPTION PN 147522-001 8-MB 70ns - OPTION PN 147523-001 16-MB 70ns - OPTION PN 147524-001 32-MB 70ns - OPTION PN 147525-001...
Page 7
Presario 700 Memory Upgrade Chart 586 SYSTEM BOARD W/8 MB MEMORY 004378-101 A bank of memory must contain same size memory modules (2 x 4 or 8 or 16 or 32). Populate first half of bank first, then second half. To populate with different size modules, populate first half of bank 1, then first half of bank 2 (i.e., U77 then U79).
Page 8
Presario 700 Memory Upgrade Chart 586 SYSTEM BOARD W/8 MB MEMORY 004447-101, 004654-101 A bank of memory must contain same size memory modules (2 x 4 or 8 or 16 or 32). Populate first half of bank first, then second half. To populate with different size modules, populate first half of bank 1, then first half of bank 2 (i.e., U77 then U79).
