- Page 1 XPass D2 INSTALLATION GUIDE Version 1.03 English EN 101.00.XPD2-GDB V1.03A...
- Page 2 Contents...
-
Page 3: Safety Instructions
Safety instructions Safety instructions Observe the following instructions to use the product safely and prevent any risk of injury or property damage. Warning Noncompliance of instructions could lead to serious injury or death. Installation Do not install the product in a place with direct sunlight, moisture, dust, or soot. •... - Page 4 Safety instructions Operation Do not drop the product or apply an impact to the product. • A product failure may occur. When cleaning the product, wipe the product with a soft and dry cloth and no water, benzene or alcohol. •...
- Page 5 Introduction Introduction Components XPass D2 Drilling Template Wall Bracket Wall Fixing Screw x 2 Bracket Fixing Screw 120 Ω resistor PVC Anchor x 2 (Star Shaped) Shrink Tube Quick Guide Open Source Software Guide NOTE • Components may vary according to the installation environment.
-
Page 6: Name And Function Of Each Part
Blue/Green blinking: When initializing network settings • Green blinking: Waiting for an input • Green/White blinking: Connecting with the Airfob Pass (BLE) application of Suprema • White blinking: Connecting with the Device Manager application of Suprema RF card authentication unit Reads RF cards for entering and exiting. -
Page 7: Cables And Connectors
Introduction Cables and connectors Name Color PWR +VDC Black (White stripe) 485 TRXN Yellow (Black stripe) 485 TRXP Blue (White stripe) Green WG D0 WG D1 White LED RED Orange LED GRN Brown BEEP Purple TMPR Gray... -
Page 8: Installation
To avoid RF interference, a minimum separation distance must be maintained. Wall thickness Distance 100 mm 400 mm 120 mm 380 mm 150 mm 380 mm • When using Suprema Mobile Access, install a minimum distance of 1 m between devices to avoid BLE interference. - Page 9 Installation Install XPass D2 onto the fixed bracket. Assemble XPass D2 with the bracket by rotating the product fixing screw. NOTE • When assembling the product with the bracket, you can use the included bracket fixing screw(Star Shaped) instead of the product fixing screw for enhanced security.
-
Page 10: Cable Connection
Installation Cable connection XPass D2 can be used as an RFID card reader by connecting to a master device or a CoreStation. Power supply connection XPass D2 1 - PWR +VDC 2 - GND Black (White stripe) DC power NOTE •... -
Page 11: Restoring The Factory Defaults
Installation Wiegand and other cable connections 1 - PWR +VDC XPass D2 2 - GND Black (White stripe) 5 - WG D0 Green 6 - WG D1 White DC power 7 - LED RED Orange 8 - LED GRN Brown 9 - BEEP Purple 10 - TMPR... -
Page 12: Product Specifications
Product specifications Product specifications Specification Category Feature XPD2-GDB LF card option HF card option MIFARE, MIFARE Plus, DESFire EV1/EV2*, FeliCa Credential NFC card Supported BLE card Supported RF read range MIFARE/DESFire/EM : 50 mm, FeliCa: 30 mm 80 MHz Memory... - Page 13 Product specifications Dimensions (Unit: mm) * The tolerance is ±0.3mm. 116.1 72.4...
-
Page 14: Fcc Compliance Information
EU Declaration of Conformity (CE) This product is CE marked according to the provisions of the Radio Equipment Directive (RED) 2014/53/EU. Hereby, Suprema Inc. declares that this product is in compliance with the essential requirements and other relevant provisions of Radio Equipment Directive (RED) 2014/53/EU. -
Page 15: Copyright Notice
• Do not use the product of Suprema under the situations related to medical, rescue of human lives, or maintenance of life, as a person may get injured or lose his/her life due to product malfunction. If an accident occurs while a consumer is using the... - Page 16 Tel: +82 31 783 4502 I Fax: +82 31 783 4503 I Inquiry: sales_sys@supremainc.com ©2021 Suprema Inc. Suprema and identifying product names and numbers herein are registered trade marks of Suprema, Inc. All non-Suprema brands and product names are trademarks or registered trademarks of their respective companies. Product appearance, build status and/or specifications are subject to change without notice.
