- Page 1 XPass D2 INSTALLATION GUIDE Version 1.07 English EN 101.00.XPD2-MDB, XPD2-GDB, XPD2-GKDB V1.07A...
-
Page 2: Table Of Contents
CONTENTS Safety instructions FCC compliance information Instructional icons EU Declaration of Conformity (CE) Introduction Components Appendices Name and function of each part Disclaimers Copyright notice Installation Open Source License Fixing the bracket and the product Power supply connection RS-485 connection Wiegand and other cable connections Restoring the Factory Defaults Resetting the baud rate of RS-485... -
Page 3: Safety Instructions
Safety instructions Please read this safety instructions before you use the product to prevent injury to yourself and others and to prevent property damage. The term ‘product’ in this manual refers to the product and any items provided with the product. Instructional icons Warning: This symbol indicates situations that could result in death or severe injury. - Page 4 The product may be affected by radio frequencies emitted by other products and the product may malfunction. Use the IEC/EN 62368-1 approved power adaptor that supports higher power consumption than the product. It is highly recommended to use the power adaptor sold by Suprema. •...
-
Page 5: Introduction
39.8 XPD2-M XP2-M Drilling Template Shrink Tube 120 Ω resistor XPass D2 XPass D2 XPass D2 XPass D2 MDB XPass D2 GDB XPass D2 GKDB 201.00.XPD2 V1.06A 201.00.XP2 V1.03A 201.00.XPD2 V1.03A Open Source Software Linux Kernel GPL BoringSSL Original SSLeay AOSP Apache 306.00 V1.00A... -
Page 6: Name And Function Of Each Part
Blue/Green blinking: When initializing network settings • Green blinking: Waiting for an input • Green/White blinking: Connecting with the Airfob Pass (BLE) application of Suprema • White blinking: Connecting with the Device Manager application of Suprema RF card and mobile access card authentication unit Reads RF cards for entering and exiting. - Page 7 Introduction Used to authenticate by entering the card ID directly. If you want to enter the ID directly, change the authentication method settings in BioStar 2. Keypad • 0 ~ 9: Enters number. • : Separates the FC code from the ID when entering the Wiegand card ID. •...
-
Page 8: Installation
XPass D2 will be installed. • If installing XPass D2 on a concrete wall, drill holes, insert PVC anchors, and fix them with fixing screws. • To avoid RF interference, a minimum separation distance must be maintained. - Page 9 Installation Install XPass D2 onto the fixed bracket. Assemble XPass D2 with the bracket by rotating the product fixing screw. • When assembling the product with the bracket, you can use the included bracket fixing screw(Star Shaped) instead of the product fixing screw for enhanced security.
-
Page 10: Power Supply Connection
Installation Power supply connection XPass D2 can be used as an RFID card reader by connecting to a master device or a CoreStation. 1 - PWR +VDC 2 - GND Black (White stripe) DC power XPass D2 • Use the IEC/EN 62368-1 approved power adaptor that supports higher power consumption than the product. -
Page 11: Wiegand And Other Cable Connections
Installation Wiegand and other cable connections XPass D2 1 - PWR +VDC 2 - GND Black (White stripe) 5 - WG D0 Green DC power 6 - WG D1 White 7 - LED RED Orange 8 - LED GRN Brown... -
Page 12: Product Specifications
Internally pulled up with 1 kΩ resistance DESFire EV2 cards are supported by having backward compatibility of DESFire EV1 cards. CSN and smart card functions are compatible with XPass D2. RF read range will vary depending on the installation environment. -
Page 13: Dimensions
Product specifications Dimensions (Unit: mm) * The tolerance is ±0.3mm. XPD2-MDB 144.7 132.2 39.8 XPD2-GDB, XPD2-GKDB 116.1 72.4... -
Page 14: Fcc Compliance Information
This product is CE marked according to the provisions of the Radio Equipment Directive (RED) 2014/53/EU. Hereby, Suprema Inc. declares that this product is in compliance with the essential requirements and other relevant provisions of Radio Equipment Directive (RED) 2014/53/EU. -
Page 15: Appendices
Information in this document is provided in connection with Suprema products. • The right to use is acknowledged only for Suprema products included in the terms and conditions of use or sale for such products guaranteed by Suprema. No license, express or implied, by estoppel or otherwise, to any intellectual property is granted by this document. -
Page 16: Open Source License
Open Source License MIT License Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions: The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software. - Page 17 QR code. https://supremainc.com/en/about/global-office.asp © 2022 Suprema Inc. Suprema and identifying product names and numbers herein are registered trade marks of Suprema, Inc. All non-Suprema brands and product names are trademarks or registered trademarks of their respective companies.
