- Page 1 XPass 2 INSTALLATION GUIDE Version 1.03 English EN 101.00.XP2-MDPB, XP2-GDPB, XP2-GKDPB V1.03A...
-
Page 2: Table Of Contents
CONTENTS Safety instructions Product specifications Instructional icons Dimensions XP2-MDPB XP2-GDPB, XP2-GKDPB Introduction FCC compliance information Components Name and function of each part EU Declaration of Conformity (CE) Installation Fixing the bracket and the product Appendices Power supply connection Disclaimers Network connection Copyright notice TTL input connection Open Source License... -
Page 3: Instructional Icons
Safety instructions Please read this safety instructions before you use the product to prevent injury to yourself and others and to prevent property damage. The term ‘product’ in this manual refers to the product and any items provided with the product. Instructional icons Warning: This symbol indicates situations that could result in death or severe injury. -
Page 4: Safety Instructions
The product may be affected by radio frequencies emitted by other products and the product may malfunction. Use the IEC/EN 62368-1 approved power adaptor that supports higher power consumption than the product. It is highly recommended to use the power adaptor sold by Suprema. •... - Page 5 Safety instructions RTC battery Discard the battery according to the appropriate regional or international waste regulations. Discard the battery according to the appropriate regional or international waste regulations.
-
Page 6: Introduction
XPD2-M XP2-M Drilling Template Shrink Tube 120 Ω resistor Ferrite Core XPass 2 XPass 2 XPass 2 XPass 2 MDPB XPass 2 GDPB XPass 2 GKDPB 201.00.XP2 V1.02A 201.00.XP2 V1.02A 201.00.XP2 V1.02A Open Source Software Linux Kernel GPL glibc LGPL... -
Page 7: Name And Function Of Each Part
Blue/Green blinking: When initializing network settings • Green blinking: Waiting for an input • Green/White blinking: Connecting with the Airfob Pass (BLE) application of Suprema • White blinking: Connecting with the Device Manager application of Suprema RF card and mobile access card authentication unit Reads RF cards for entering and exiting. - Page 8 Introduction Only the XP2-GKDPB model supports the keypad. Cables This document describes cable information based on the shape of the XP2-MDPB model. The same cable configuration is also used for XP2-GDPB and XP2-GKDPB models. Name Color 485 TRXP Blue (White stripe) 485 TRXN Yellow (Black stripe) 485 GND...
-
Page 9: Installation
XPass 2 will be installed. • If installing XPass 2 on a concrete wall, drill holes, insert PVC anchors, and fix them with fixing screws. • To avoid RF interference, a minimum separation distance must be maintained. - Page 10 Installation Install XPass 2 onto the fixed bracket. Assemble XPass 2 with the bracket by rotating the product fixing screw. • When assembling the product with the bracket, you can use the included bracket fixing screw(Star Shaped) instead of the product fixing screw for enhanced security.
-
Page 11: Power Supply Connection
22 - PWR GND Black (White stripe) DC power XPass 2 • Use the IEC/EN 62368-1 approved power adaptor that supports higher power consumption than the product. If you wish to connect and use another device to the power supply adaptor, you should use an adaptor with a current capacity which is the same or larger than the total power consumption required for the terminal and another device. -
Page 12: Ttl Input Connection
Installation LAN connection (connecting to a PC directly) XPass 2 has an automatic MDI/MDIX function so that it can be connected to a PC directly using a normal straight type CAT-5e cable, not a cross cable. XPass 2 TTL input connection... -
Page 13: Relay Connection
NOT recommended to use the internal relay of a reader to prevent any tampering attacks which can potentially trigger the door unlock. For such applications, it is highly recommended to use a separate relay unit for a lock control such as Suprema’s Secure I/O 2, DM-20 or CoreStation installed at a secure side of a door. - Page 14 NOT recommended to use the internal relay of a reader to prevent any tampering attacks which can potentially trigger the door unlock. For such applications, it is highly recommended to use a separate relay unit for a lock control such as Suprema’s Secure I/O 2, DM-20 or CoreStation installed at a secure side of a door.
-
Page 15: Connecting As A Standalone
Installation Connecting as a standalone XPass 2 can be connected to the door lock, door button, and door sensor directly without connecting a separate I/O device. XPass 2 Door button Fail Secure Lock Fail Safe Lock Power Door sensor TTL connection... - Page 16 Connecting to Secure I/O 2 Secure I/O 2 is an I/O device, can be connected to XPass 2 with the RS-485 cable. Security can be maintained even if the connection between XPass 2 and Secure I/O 2 has been lost or the power supply to BioEntry W2 has been shut off due to external factors.
-
Page 17: Wiegand Connection
14 - WG D0 Green RFID reader / Control device XPass 2 Resetting Network Settings Turn the power on. Press and hold the reset button on the rear of device until the device restart automatically. Connect the device with default values. -
Page 18: Product Specifications
1 A @ 30 VDC Inductive load DESFire EV2 cards are supported by having backward compatibility of DESFire EV1 cards. CSN and smart card functions are compatible with XPass 2. RF read range will vary depending on the installation environment. -
Page 19: Dimensions
Product specifications Dimensions (Unit: mm) * The tolerance is ±0.3mm. XP2-MDPB 144.7 132.2 39.8 XP2-GDPB, XP2-GKDPB 116.1 72.4... -
Page 20: Fcc Compliance Information
This product is CE marked according to the provisions of the Radio Equipment Directive (RED) 2014/53/EU. Hereby, Suprema Inc. declares that this product is in compliance with the essential requirements and other relevant provisions of Radio Equipment Directive (RED) 2014/53/EU. -
Page 21: Appendices
Information in this document is provided in connection with Suprema products. • The right to use is acknowledged only for Suprema products included in the terms and conditions of use or sale for such products guaranteed by Suprema. No license, express or implied, by estoppel or otherwise, to any intellectual property is granted by this document. -
Page 22: Open Source License
To request the modified source code based on Linux Kernel 3.x and the source code of glibc and QT libraries, which are included in this product, please visit at https://support.supremainc.com and contact to Suprema Tech Team. GNU General Public License Version 3, 29 June 2007 Copyright ©... -
Page 23: Terms And Conditions
Appendices TERMS AND CONDITIONS 0. Definitions. “This License” refers to version 3 of the GNU General Public License. “Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks. “The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”. “Licensees”... - Page 24 Appendices 2. Basic Permissions. All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output from running a covered work is covered by this License only if the output, given its content, constitutes a covered work.
- Page 25 Appendices 6. Conveying Non-Source Forms. You may convey a covered work in object code form under the terms of sections 4 and 5, provided that you also convey the machine-readable Corresponding Source under the terms of this License, in one of these ways: a) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied by the Corresponding Source fixed on a durable physical medium customarily used for software interchange.
- Page 26 Appendices 7. Additional Terms. “Additional permissions” are terms that supplement the terms of this License by making exceptions from one or more of its conditions. Additional permissions that are applicable to the entire Program shall be treated as though they were included in this License, to the extent that they are valid under applicable law.
- Page 27 Appendices 9. Acceptance Not Required for Having Copies. You are not required to accept this License in order to receive or run a copy of the Program. Ancillary propagation of a covered work occurring solely as a consequence of using peer-to-peer transmission to receive a copy likewise does not require acceptance.
- Page 28 Appendices A patent license is “discriminatory” if it does not include within the scope of its coverage, prohibits the exercise of, or is conditioned on the non-exercise of one or more of the rights that are specifically granted under this License. You may not convey a covered work if you are a party to an arrangement with a third party that is in the business of distributing software, under which you make payment to the third party based on the extent of your activity of conveying the work, and under which the third party grants, to any of the parties who would receive the covered work from you, a...
-
Page 29: Gnu Lesser General Public License
Appendices 17. Interpretation of Sections 15 and 16. If the disclaimer of warranty and limitation of liability provided above cannot be given local legal effect according to their terms, reviewing courts shall apply local law that most closely approximates an absolute waiver of all civil liability in connection with the Program, unless a warranty or assumption of liability accompanies a copy of the Program in return for a fee. - Page 30 Appendices b) Accompany the object code with a copy of the GNU GPL and this license document. 4. Combined Works. You may convey a Combined Work under terms of your choice that, taken together, effectively do not restrict modification of the portions of the Library contained in the Combined Work and reverse engineering for debugging such modifications, if you also do each of the following: a) Give prominent notice with each copy of the Combined Work that the Library is used in it and that the Library and its use are covered by this License.
-
Page 31: Openssl License
Appendices OpenSSL License Copyright (c) 1998-2017 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. - Page 32 Appendices include an acknowledgement: "This product includes software written by Tim Hudson (tjh@cryptsoft.com)" THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
- Page 33 QR code. https://supremainc.com/en/about/global-office.asp © 2022 Suprema Inc. Suprema and identifying product names and numbers herein are registered trade marks of Suprema, Inc. All non-Suprema brands and product names are trademarks or registered trademarks of their respective companies.
