- Page 1 AF 3000 ITALIANO (lingua originale) ENGLISH (translation of original instructions) Adam Pumps S.p.A. Soc. con Socio Unico UM002 via della resistenza 46/48 - 41011 Campogalliano (MO) ITALIA 7/2020 - rev. 6 Tel +39 059 528128 - Fax +39 059 528437...
-
Page 2: Table Of Contents
(Annex II A DIR. 2006/42/EC) THE MANUFACTURER ADAM PUMPS S.p.A., with its registered office in Via della Resistenza, 46/48, 41011, Campogalliano (MO), ITALY; represented by Davide Stassi, authorised to compile the relevant technical file at the undersigned premises, DECLARES THAT THE MACHINE Used as a diesel fuel pumping system to be integrated into a system for transferring fuel from a gravity tank. -
Page 3: General Warnings
All rights under these rules belong to ADAM PUMPS S.p.A.: reproduction, even partial, of this manual, its publication, modification, transcription, public disclosure, distribution, marketing in any form, translation and/or development, loan, or any other activity reserved by law to ADAM PUMPS S.p.A. -
Page 4: Operating Conditions
The values refer to operation of the pump in bypass (maximum performance) (**) CAUTION! Operation in bypass is allowed only for brief periods (1-2 minutes at most) (***) The noise levels are measured at a distance of 1 metre from the electric pump in normal operating conditions. -
Page 5: Preliminary Checks And Positioning The
CAUTION! Do not use couplings or connection fittings with conical threading, as these could damage the pump coupling outlets if tightened too much. We recommend using ADAM PUMPS suction and discharge pipes, which are designed specifically for the pump in use; alternatively, respect the dimensions and specifications in the table below. -
Page 6: Intended Use
5.4 - Electrical connection of the pump To connect or replace the power cable, locate the pump, open the capacitor box cover and Single-phase asynchronous follow the connection diagram to the side. Single-phase asynchronous motors are equipped motors with phase capacitor and double-pole switch. The capacitor specifications are indicated for each model on the pump’s rating plate. - Page 7 6.2 - Intended use - If hoses are used, make sure the ends are properly connected to the tanks. - Firmly hold the end of the discharge pipe to prevent accidental spillage. - Before starting the pump, make sure the discharge valve or the nozzle is closed. - When you are ready, switch the unit on.
-
Page 8: Noise Level
6.5 - Noise level Under normal operating conditions the noise emitted by all models does not exceed 85 dB at a distance of 1 metre from the electric pump. 6.6 - Compatibility in an electromagnetic environment The machine is designed to operate correctly in an industrial electromagnetic environment, and staying within the Emission and Immunity limits laid down in the following Harmonised Standards: IEC EN 61000-6-2 Electromagnetic compatibility (EMC) - Generic standards - Immunity for industrial environments... -
Page 9: Maintenance
8 - MAINTENANCE Maintenance includes inspections, checks and interventions which, to prevent interruptions and breakdowns, systematically keep the machine lubrication status and the parts subject to wear under control. These operations, although simple, must be carried out by Qualified Personnel.The machine is designed to minimise routine maintenance. -
Page 10: Demolition And Disposal
D. Relocate the metallic locking plate and tighten the screws. Position the frontal plate and close the fuel dispenser. models AF3000 80-100L A. unscrew the screws that hold tight the front part of the metal sheet and open the distributor; B. -
Page 11: Warranty
Adam Pumps. The goods can be returned only if provided with an authorisation code. - Page 12 EXPLODED VIEWS TECH FLOW 3C-4C DESCRIPTION Q.TY DESCRIPTION Q.TY TF014N BOTTOM COVER TF018 CALIBRATION CAP 1/8" TF013N TOP COVER 11010100200 O-RING 108 NBR TF015G SIDE COVER WITH HOLE 11010050200 O-RING 2018 NBR 60302000 PLASTIC CAP TF010 METER FLANGE MA999 FACEPLATE OR002 O-RING 4500 TF044...
- Page 13 PA1 70A 230V CODE DESCRIPTION CODE DESCRIPTION ME033 wound stator p80 PA037 black reinforced bypass cap ME032 machined shield p.80 16001005 by-pass spring ME034 motor shaft p.80 140250500000 mec 63 fan cover 101001600000 bearing 6201 2rs 11010040200 o-ring 2015 nbr OR037 filter seal VT042...
- Page 14 PA1 70A 115V CODE DESCRIPTION Q.TY CODE DESCRIPTION Q.TY 15501600000X MACHINED SHIELD MEC 63 61004600000 TIE ROD M5 x 125 6290150000L ENGINE SHAFT MEC 63 140250500000 FUN COVER MEC 63 CP009X BODY PUMP PA 70L 61000003 ROTOR Ø45 PA018 SWIVEL LOCKING PLATE 71000522 SMALL VANE PA019...
- Page 15 PA2 80 - 100 CODE. DESCRIPTION Q.TY CODE. DESCRIPTION Q.TY 64100000000 Wrapped stator MEC 71 230V 140260400000 fan MEC 71 with ring Ø14 PA023 capacitor holder + cap 140260500000 fan holder MEC 71 140250300000 Cable lock 12001015020 Sealing ring 20x30x7 SNBR 190061000000 Capacitor 25 μF 90505050000...
- Page 16 AF 3000 CODE DESCRPTION Q.TY CODE DESCRPTION Q.TY AF022 meter support VT015 nut M4 UNI 5588 mechanical meter AF019 Nozzle holder A PA003 terminal cover FP71 71000532 meter pommel PA004 plate with cable gland 163013500000 protection cap Ø31 71000550 Electrical box exit...
-
Page 17: Wiring Diagrams
WIRING DIAGRAM S : switch ON-OFF M: motor T: thermal protection C: capacitor OVERALL DIMENSIONS AF 3000...
