Summary of Contents for Schweigen SXQU330-9S

  • Page 1 SXQU330-9S Rangehood & Installation Guide Under our policy of continuous product development, product specifications may change without notice. Please refer to the online version of the manual for the latest updates and specifications.
  • Page 2: Table Of Contents

    Rangehood Size Vs Cooktop Size Rangehood Installation Height Recommended Installation Height For Induction Cooktop Mounting System Mounting Position Installation Instructions Un-installation Instructions Optional Back Outlet Configuration Ducting Roof Mounted Motor System Overview Wall Mounted Motor System Overview SXQU330-9S Rangehood & Installation Guide...
  • Page 3: Welcome

    Some will insist on ducting being vented externally (i.e. not in to the ceiling cavity); others will not. It is imperative that you check with your state building authority and/or private certifier to confirm their position. SXQU330-9S Rangehood & Installation Guide...
  • Page 4: Your Safety

    18. Never cook foodstuff directly over the safety. Children should be supervised flame or have the gas burners on under to ensure that they do not play with the the rangehood without using cookware. appliance, it is not a toy. SXQU330-9S Rangehood & Installation Guide...
  • Page 5: Before Installation

    7. Schweigen Home Appliances will not be legislation. responsible for installations executed by non- qualified installers and installations that fail to meet legislation requirements.
  • Page 6: Product Use

    Staff kitchen areas in shops, offices and other working environments. • By clients in hotels, motels and other residential environments, excluding commercial kitchens. • Bed and breakfast type environments. This rangehood is not designed for outdoor or alfresco installation. SXQU330-9S Rangehood & Installation Guide...
  • Page 7: Description

    To ensure the correct fit for your rangehod in your cabinetry, use the below dimensions as a guide. It is always best to send your rangehood to your cabinet maker to ensure the correct fit prior to installation. 885mm approx. Dimensions may be subject to change. SXQU330-9S Rangehood & Installation Guide...
  • Page 8: Operation

    To activate the shutdown timer on the Touch Button Control Panel: When the rangehood is in operation and a fan speed has been chosen, press the on/off button once to activate the timer. The button will flash to indicate that the 10 minute timer has been activated. SXQU330-9S Rangehood & Installation Guide...
  • Page 9: Cleaning & Maintenance

    • The manufacturer will not be held responsible for functional or aesthetic damage caused by cleaning with products which are not suitable or using inadequate cleaning methods. SXQU330-9S Rangehood & Installation Guide...
  • Page 10: Filters

    STEP 1 STEP 1 STEP 2 STEP 2 N O T E The colour of the metal mesh filters may change after several washes. This is normal and it is not necessary to replace the filters. SXQU330-9S Rangehood & Installation Guide...
  • Page 11: Replacing The Led Light

    Unscrew and remove the internal panel. STEP 3 STEP 4 From inside the cavity, push down on the light Unclip the cord by pushing in the side clips until it pops out. and pulling the cord. SXQU330-9S Rangehood & Installation Guide...
  • Page 12 Clip the new light cord in. Push the light into the light cavity until it clicks into place. STEP 7 STEP 8 Screw the side panel back in place. Fit the filters back into the rangehood. SXQU330-9S Rangehood & Installation Guide...
  • Page 13: Installation

    I N S T A L L A T I O N P O S I T I O N The installation height and position of your rangehood will affect its performance. Schweigen recommends the rangehood be installed as close to the front of the cabinetry as possible. This will increase extraction efficiency as there will be greater coverage of the cooktop surface area.
  • Page 14: Rangehood Size Vs Cooktop Size

    In addition to the information in this manual, please check all relevant state requirements for minimum–maximum heights, as well as regulations regarding the expelling of air. Schweigen is not liable if your rangehood is not installed in accordance with these legal requirements.
  • Page 15: Rangehood Installation Height

    F O R I N D U C T I O N C O O K T O P To help avoid condensation, particular to cooking with an induction cooktop, Schweigen recommends a height between 700-750mm. Refer to page 26 for further information.
  • Page 16: Mounting System

    The rangehood can be installed either Proud or Flush mounted. The diagrams below show how the cabinetry will need to be constructed for each option. It is best to send the rangehood to your cabinet maker to ensure the correct fit. Cabinet RANGEHOOD Cabinet RANGEHOOD PROUD MOUNT FLUSH MOUNT SXQU330-9S Rangehood & Installation Guide...
  • Page 17: Installation Instructions

    The requirement of a mounting Mounting frame frame is dependent on the type and location of installation. Please contact your installer for more information. TOP VIEW STEP 2 Secure mounting frame to inside of cabinet. BOTTOM VIEW SXQU330-9S Rangehood & Installation Guide...
  • Page 18 STEP 3 Remove all filters. From inside the rangehood, loosen screws & for the spring brackets by turning anti-clockwise. Do not remove screws. STEP 6 Turn screw to align base of rangehood with cabinet. SXQU330-9S Rangehood & Installation Guide...
  • Page 19 Installation STEP 7 Tighten screws & to lock fixing bracket STEP 8 Screw all other fixing screws to mounting frame. N O T E Remove all plastic protection on the rangehood and filters before use. SXQU330-9S Rangehood & Installation Guide...
  • Page 20: Un-Installation Instructions

    & until the rangehood comes down to its lowest position. STEP 3 Tighten screws & to fix bracket. STEP 4 Turn screw clockwise to take spring bracket back while lifting the rangehood up. SXQU330-9S Rangehood & Installation Guide...
  • Page 21 Installation STEP 5 Pull out the rangehood. SXQU330-9S Rangehood & Installation Guide...
  • Page 22: Optional Back Outlet Configuration

    Unscrew and remove the back panel cover. Unscrew and remove the outlet panel cover. STEP 3 STEP 4 Place outlet panel over the back Place cover over the top opening opening and screw into place. and screw into place. SXQU330-9S Rangehood & Installation Guide...
  • Page 23: Ducting

    This reduces the size and efficiency of the ducting, lowers extraction and can cause excessive noise. 2. Sweeping curves and taut ducting reduces resistance and turbulence. The airflow and extraction will be more efficient and stronger. SXQU330-9S Rangehood & Installation Guide...
  • Page 24: Roof Mounted Motor System Overview

    The general power outlet for the rangehood should be located in an easy to access area. All electrical wiring from the motor to the rangehood should be kept inside the roof space. SXQU330-9S Rangehood & Installation Guide...
  • Page 25: Wall Mounted Motor System Overview

    Isodrive Bulkhead Ducting Motor Rangehood External wall mount examples. Please refer to the Isodrive® Motor manual for recommended ducting lengths. Images are for illustrative purposes only. SXQU330-9S Rangehood & Installation Guide...
  • Page 26: Condensation Information

    For further advice, tips or information regarding • Filter size – larger canopy preferred. cooking with induction, please contact your • Quality of pots or cookware you are using – induction cooktop manufacturer. high quality recommended. SXQU330-9S Rangehood & Installation Guide...
  • Page 27: Troubleshooting

    The below table lists a number of commonly reported faults and their causes. Please check the list below before lodging a service request Rangehood does not work Light does not work Rangehood air suction is weak Rangehood does not direct air out (through chimney) SXQU330-9S Rangehood & Installation Guide...
  • Page 28: Service

    It is not the responsibility of Schweigen to rectify any incorrect installations. A service call out fee will be charged for any Schweigen technician that attends a call, where it is found that the fault is due to an incorrect installation or non-manufacturing fault.
  • Page 29: Specifications

    LED linear light (Q type LED light strip) Rated wattage of the intended lamp Max wattage of a potential replacement lamp Nominal dimensions 120mm (L) x 33mm (W) (Q type) ILCOS Code DSL-2-S-120/33 Rated voltage 12V DC SXQU330-9S Rangehood & Installation Guide...
  • Page 30: Disclaimer

    Isodrive Motor, ® is on the understanding that Schweigen Home or online at schweigen.com.au). Appliances will not be liable for any loss, liability or damage of whatever kind arising as Schweigen Home Appliances has presented this a result of any reliance upon such information.
  • Page 31 Notes SXQU330-9S Rangehood & Installation Guide...
  • Page 32 © Schweigen Home Appliances Pty Ltd. 2021 Australia Unit 4/1-5 Lake Drive, Dingley Village, Victoria 3172 Phone: 1300 881 693 Email: sales@schweigen.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610 Phone: 0800 200 510 Email: info.parex@emerson.com Distributed by Schweigen Pty Ltd.
