EWS: Available in 6 to 25 litre capacities
American technology
that ensures you have
a water heater that
works in Indian water
conditions.
Saves time.
Saves energy.
Saves money.
Fit it & Forget it
Why people prefer an
A. O. Smith water heater...
Heating technology
that will always give
you hot water...
Guaranteed!
Blue Diamond
Glass-Lined Tanks.
Glass Coated Elements.
Colour Options.
User Guide
Our new innovative
solutions are often
copied but never
equalled.
Guaranteed Service
within 24 hours.
Call: 1800.103.2468

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EWS-6 and is the answer not in the manual?

Questions and answers

Related Manuals for A.O. Smith EWS-6

Summary of Contents for A.O. Smith EWS-6

  • Page 1 Fit it & Forget it Why people prefer an A. O. Smith water heater... EWS: Available in 6 to 25 litre capacities American technology Heating technology Our new innovative that ensures you have that will always give solutions are often a water heater that you hot water…...
  • Page 2 A.O. Smith ColourMatch System allows you to match your water heater to the colour of your bathroom. Call the A. O. Smith Customer Care Centre [1.800.103.2468] to order one of the decorative front panel...
  • Page 3 Dear Customer, Congratulations! You have bought a world-class water heater from A. O. Smith Water Products Company, the largest water heater manufacturer in North America. A division of A. O. Smith Corporation, it is a global leader in innovative technology and energy efficient solutions. Our customer-centric approach manifests in many ways.

  • Page 4: Table Of Contents

    Contents Specifications ..............Key Features .

  • Page 5: Specifications

    Specifications Model EWS-6 EWS-10 EWS-15 EWS-25 Volume [L] Voltage/ Frequency [v/Hz] 230~50 Power [W] 2000 2000 2000 2000 Max Stdg. Loss [kWh/24h/45 C diff.] 0.792 0.99 1.138 1.386 [as per IS 2082:1993 amended in 2002] Actual Stdg. Loss [kWh/24h/45 C diff.] 0.444...

  • Page 6: Key Features

    Key Features Glass Coated Element increases the life of the heating element Scale and sediment build-up on the surface of standard elements leads to premature failure. An A. O. Smith Glass Coated Element helps to prevent scale formation on the element extending the life of the element.

  • Page 7: Installation

    Installation Mounting Wall 1. Make sure that the wall can withstand at least twice the weight of water heater when completely filled with water. 2. Before locating the position for installation, make sure that there is a clearance of no less than 300 mm between the front of the heater and the wall.

  • Page 8: Electrical Connections

    Electrical Connections The power cord and plug are connected with this water heater. Find a separate socket for power plug and make sure the socket is in contact with the plug. Filling Water 1. Open a hot water faucet nearby to permit the air to escape.

  • Page 9: Maintenance And Cleaning

    Maintenance and Cleaning Check proper functioning of the safety valve every two months by opening and closing the test lever. The heating element should be checked annually for scale formation, caused by impurities in the water supply. Also, the anode should be checked annually and replaced when worn out over 60%. For cleaning the element or replacing the anode, use the following procedure: Switch off the electric supply to the water heater.

  • Page 10: Troubleshooting

    Troubleshooting Problem Cause(s) Action No power to heater Green and Turn on electrical switch. Check for Red light off blown fuses or tripped breaker No hot water Thermal cutout switch open Call Customer Care Centre on 1.800.103.2468 Control circuit or internal wiring error Non-functioning Green light on...

  • Page 11: Warranty

    Warranty Terms & Conditions Your A. O. Smith water heater is warranted against defects arising from faulty design, workmanship and materials for a period of 24 months from the date of the invoice, subject to the following conditions: Warranty 1. The customer will notify the Company promptly about defects on tank noticed and give the Company or its authorized service provider adequate opportunity to inspect, test and remedy them, for which...

  • Page 12: General Terms Of Warranty

    General Terms of Warranty 1. The “goods” shall mean the goods described in the purchase agreement. 2. “The customer” shall mean the original purchaser under the purchase agreement. 3. “The Company” shall mean A. O. Smith India Water Heating Pvt. Ltd. 4.

  • Page 13: Warranty Card

    Warranty Card Warranty Card (Customer Copy) (To be retained by the Customer) Unit Serial Number: Invoice Number: Dated: Customer's Name and Address: Model: Capacity: Dealer’s Stamp and Signature …………………………………………………………………………………………….......... Warranty Card (Company Copy) (To be sent back to the Company) Unit Serial Number: Invoice Number: Dated:...

  • Page 14: Service And Maintenance

    Service and Maintenance For Service needs: Please contact our 24-hr A. O. Smith Toll Free Customer Care Centre Helpline at 1.800.103.2468 Factory Address A. O. Smith India Water Heating Private Limited Plot No. 300, Phase - 2, KIADB Industrial Area, Harohalli, Taluka Kanakpura, Dist.
  • Page 16 Manufactured by A. O. Smith India Water Heating Private Limited Plot No. 300, Phase - 2, KIADB Industrial Area, Harohalli, Taluka Kanakpura, Dist. Ramanagaram - 562 112. Karnataka, India. Toll Free: 1.800.103.2468 Website: www.aosmithindia.com...
