E X P E R T C O M P A N Y S E R V I C E
Toll Free No.: 1800-103-2468 or
SMS us: +91 99410 32468 or
Email us: aosmithcs@aosmithindia.com
Monday to Friday: 9 am to 8 pm.
Saturday & Sunday: 9 am to 6 pm.
# For calls registered at A. O. Smith call centre before 4 pm only.
For more details please call our Toll Free No. 1800-103-2468
or log on to www.aosmithindia.com.
w w w . a o s m i t h i n d i a . c o m
USER GUIDE
Water Purifier
SUPERIOR TECHNOLOGY FOR ADVANCED PROTECTION.
&
MINERALISED
WITH
&
HOT WATER
PURIFIED
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z6 and is the answer not in the manual?

Questions and answers

Related Manuals for A.O. Smith Z6

Summary of Contents for A.O. Smith Z6

  • Page 1 Water Purifier & MINERALISED WITH & HOT WATER PURIFIED SUPERIOR TECHNOLOGY FOR ADVANCED PROTECTION. E X P E R T C O M P A N Y S E R V I C E Toll Free No.: 1800-103-2468 or SMS us: +91 99410 32468 or Email us: aosmithcs@aosmithindia.com Monday to Friday: 9 am to 8 pm.
  • Page 3 Dear Customer, Congratulations and welcome to A. O. Smith family. We thank you for the trust you have shown in choosing the A. O. Smith water purifier. A. O. Smith water purifier is one of the most advanced RO water purifier available in the market today.

  • Page 4: Table Of Contents

    Contents Key Features of your A. O. Smith & RO water purifier ........01 Pre-instruction literature ..................02 General instructions ....................03 Introduction ......................04 Product overview ..................... 06 Function of indicators ....................08 Water flow ....................... 11 Electrical diagram..................... 12 Safety precautions....................

  • Page 5: Key Features Of Your A. O. Smith & Ro Water Purifier

    Key Features of your A. O. Smith & RO water purifier PURITY THROUGH 7 STAGE PURIFICATION 7S TECHNOLOGY: Pre-filter + Sediment filter + Pre Carbon filter + RO Membrane + MIN-TECH (Mineraliser Technology) + Silver Activated Post Carbon + SCMT (Silver Charged Membrane Technology).

  • Page 6: Pre-Instruction Literature

    Pre-instruction Literature On Receipt It is our policy to promote safe delivery of all orders. This product shipment has been thoroughly checked, packed and quality certified before leaving our plant. Visible Loss or Damage If any of the goods called for on the bill of lading or express receipt are damaged or the quantity is short, do not accept them until the freight or express delivery agent makes an appropriate notation on your freight bill or receipt.

  • Page 7: General Instructions

    General Instructions Safety Your safety and the safety of your loved ones is paramount to us. There are several safety related messages in this manual, which have been provided during various stages such as installation, operation and maintenance of your A. O. Smith RO water purifier.

  • Page 8: Introduction

    Introduction A. O. Smith RO water purifier uses one of the latest technologies that is used in water purification process. A. O. Smith RO water purifier works under the principle of RO (Reverse Osmosis) technology which is found to be one of the most effective process.
  • Page 9 Stage 3 – Pre Carbon filter  The Pre Carbon filter uses carbon block with high adsorbtion capacity which reduces harmful chemicals including pesticides, volatile organic compounds, residual chlorine etc., from water. It also adsorbs bad taste and odour causing organic compounds from water.

  • Page 10: Product Overview

    Product Overview A. O. Smith RO water purifier Figure 2 Front View Top Cover LED Display Panel Indicators Water Level Indicator Water Level Indicator Child Lock Button Normal Water Faucet Hot Water Faucet Faucet Lever Main Body Front Cover Hot Water Tank Drip Tray Cover Removable Drip Tray Back View...
  • Page 11 A. O. Smith RO water purifier Figure 3 Front View Top Cover LED Display Panel Indicators Water Level Indicator Water Level Indicator Normal Water Outlet Hot Water Outlet Main Body Front Cover Hot Water Tank Drip Tray Cover Removable Drip Tray Back View Rear Cover Reject water...

  • Page 12: Function Of Indicators

    Function of indicators Power Button This button is used to switch ON/OFF the water purifier. • When there is a leak in the water purifier, the power button starts to blink with continuous beep till it is fixed. • When the water pressure is lower than required water pressure limits, the power button starts to blink continuously with the beep sound for 10 seconds till the water pressure becomes normal.
  • Page 13 RO change indicator This indicates that the MIN-TECH, Silver Activated Post Carbon, SCMT filter and/or ROmembrane needs to be replaced. • RO change indicator glows when 10% life is remaining, indicating that it is time to replace MIN-TECH, Silver Activated Post Carbon, SCMT filter and/or RO membrane. •...
  • Page 14 Water Heating Button This purifier is capable of dispensing warm water (45°C) and hot water (80°C) as per customer desire. This button is used to heat the water inside the hot water tank of the purifier. Child Lock Button (for A. O. Smith only) As a safety feature while dispensing hot water, the purifier has a built-in Child lock feature.

  • Page 15: Water Flow

    Water flow Figure 4 Inlet Solenoid Low Pressure valve Switch Flow Ball Pump Restrictor water Valve Inlet water Pre-filter Sediment Pre Carbon 3-way joint Waste filter Pure water water Flush Solenoid Overflow Storage Level 1 valve water Tank Sensor Level 2 Check Sensor Valve...

  • Page 16: Electrical Diagram

    Electrical diagram Figure 5 Figure 6 Hot Water Tank Temperature Sensor Lower Upper Level Level Sensor Sensor Main Control Board 150V - 300V SMPS 50 Hz 1- φ AC supply Terminal Block LED1 LED2 Reset Flush Pressure Night Switch Assist Inlet Pump Water...

  • Page 17: Safety Precautions

    Safety Precautions Electrical safety Even though these products are designed keeping highest safety standards in mind, there are certain Do’s and Dont’s which need to be followed while using these products. Power plug must be used with a Do not move the product when product is grounded 230V outlet.
  • Page 18 Product should be installed only by Do not connect hot water to the product. A. O. Smith Company authorised service (Figure 13) technician. (Figure 12) Figure 12 Figure 13 CAUTION CAUTION Heater Connect the product to the power supply Figure 14 only with the plug that is provided with the purifier.
  • Page 19 When it is used Do not put heavy objects on the product. Do not put foreign objects or hand inside (Figure 17) the purifier. (Caution is needed, especially for children). (Figure 18) Figure 17 Figure 18 CAUTION Do not drink the water from the reject water tube. Reject water should not be consumed in any form.

  • Page 20: How To Use

    How to use A. O. Smith A. O. Smith 1. Turn ON the water connection 1. Turn ON the water connection through the ball valve. (Figure 20) through the ball valve. (Figure 21) Figure 20 Figure 21 2. Switch ON the power supply and press 2.
  • Page 21 A. O. Smith A. O. Smith To dispense normal water 1. To dispense normal water from the 1. To dispense normal water from the storage tank, push and hold the storage tank, press the normal water normal water faucet lever. (Figure 24) button once, the normal water button LED glows.
  • Page 22 A. O. Smith A. O. Smith Setting to Warm/Hot water temperature. This purifier is capable of dispensing at two temperature choices warm water (45°C) and hot water (80°C). Setting to warm water temperature (45°C) 1. Press the water heating button 1.
  • Page 23 A. O. Smith A. O. Smith Setting to hot water temperature (80°C) 1. Press and hold the water heating 1. Press and hold the water heating button for 3 seconds. This will set button for 3 seconds. This will set temperature to 80°C which will be temperature to 80°C which will be displayed on LED.
  • Page 24 A. O. Smith A. O. Smith To dispense hot water To dispense hot water, first disable child lock (if water temperature is more than 50°C) 1. Press the child lock button once, to 1. Press and hold the water heating unlock the hot water faucet.
  • Page 25 DANGER NOTICE Hot water is • Discard the first cycle of pure water, before you start using it dangerous, especially for consumption. for children, aged or the disabled. The • Make sure to discard the water water purifier allows from the storage tank if you have you to control the not used the purifier for more temperature of your...

  • Page 26: Draining Drip Tray

    Draining Drip Tray We have provided removable Drip Tray with the product. In case there is spillage of water, it gets collected in Drip Tray. A. O. Smith A. O. Smith 1. Remove the Drip Tray assembly by 1. Remove the Drip Tray assembly by pulling forward.
  • Page 27 A. O. Smith A. O. Smith 3. Clean the surface of water tray with a soft cloth. (Figure 39) Figure 39 4. Re-attach the Drip Tray assembly into 4. Re-attach the Drip Tray assembly into the purifier. (Figure 40) the purifier. (Figure 41) Figure 40 Figure 41...

  • Page 28: How To Maintain Your Product

    How to maintain your product Do not splash water directly or clean with Replace filters regularly according to the benzene, pesticides, thinner, alcohol, etc., replacement indications. This must be but use a soft, dry cloth to clean the done only by A. O. Smith Company purifier.

  • Page 29: Troubleshooting

    Troubleshooting Your A. O. Smith RO water purifier may not function at its desired capability if used incorrectly. This may not necessarily mean that the product is faulty. For instances like these, please follow the steps given below to troubleshoot the problem without the help from a certified technician.
  • Page 30 Buzzer beeps and Water leak alarm is Switch OFF the water power LED blinks triggered indicating purifier and call Customer continuously. that there is a leakage care centre. inside the purifier. Buzzer beeps and Overflow alarm is Switch OFF the water tank full LED blinks triggered indicating purifier and call Customer...
  • Page 31 SCPA change LED glows. SCPA change indicator Call Customer care centre glows when 10% life is for filters replacement. remaining indicating that it is time to replace filters. Buzzer beeps for SCPA change alarm is Switch OFF the water 10 times and SCPA triggered indicating that purifier and call Customer change LED blinks...

  • Page 32: Technical Specifications

    Technical Specifications Model A. O. Smith & Product Dimensions (H x D x W) 482 mm x 369 mm x 326 mm Net weight 10.8 kgs (approx.) Gross weight 15.2 kgs (approx.) Flow rate* Up to 15 litres per hour Storage tank capacity 9.2 litres (approx.) Storage tank capacity (Hot tank)
  • Page 33 Recommended input Feed water quality for the optimum performance of your product RECOMMENDED FEED WATER QUALITY Parameter Limits Total Dissolved Solids (TDS) Up to 2000 ppm Total hardness Up to 500 ppm Turbidity Up to 5 NTU Iron 0.3 ppm (max.) Feed water pressure 7 psi to 30 psi Feed water temperature...

  • Page 34: Faqs

    FAQs What is A. O. Smith RO water purifier? A. O. Smith RO is advanced 7 stages RO from A. O. Smith. It is 100% RO with no bypass of water for maximum purity. It is double purified by SCMT (Silver Charged Membrane Technology) and required essential minerals are added back to water.
  • Page 35 What is SCMT? Silver Charged Membrane Technology is double purification of water after the RO membrane to ensure absolute purity. What is RO+SCMT? It is unique double purification process to ensure absolute purity of water. Does it retain minerals? Yes, A. O. Smith RO water purifier has an additional mineral filter (MIN-TECH) which adds essential minerals back to water.
  • Page 36 What is the digital display in A. O. Smith RO water purifier? Digital display in A. O. Smith RO water purifier indicates 1) Tank full 2) Flushing of RO membrane 3) Change of SCPA (Sediment and Pre Carbon) 4) Change of RO membrane, Silver Activated Post Carbon, MIN-TECH and SCMT 5) Temperature indicator and error indicator.

  • Page 37: Warranty Terms And Conditions

    Warranty Terms and Conditions Product warranty A. O. Smith India Water Products Private Limited (“A. O. Smith or Company”) warrants this water purifier (“product”) against the defects arising from faulty design, workmanship and material subject to the following terms and conditions: 1.
  • Page 38 10. If an identical model is no longer available due to a change in law, regulation, or standard, A. O. Smith will replace the product with one having a similar capacity and input. In these instances, the customer will have the option of paying the difference between what was paid for the original model and the new model with the additional features, or receiving a refund of the portion of the purchase price on a pro rata basis allocable to the unexpired portion of the warranty.
  • Page 39 If product serial number is missing or altered. g. If damage is caused by pest infestation. h. If the input water emits pungent smell. If the input water is discoloured. If product is used for commercial purpose. 17. RO membrane will be covered for any material damage, malfunctioning under warranty for specified period as detailed below and effective from date of original purchase.
  • Page 40 Post Warranty 1. The customer may be offered a yearly Service Contract (PHCP*) at the prevailing Company rates and terms. 2. In case the customer does not wish to enter the Service Contract, customer has the option of calling our Authorised service provider and get A. O. Smith Water Purifier unit serviced on actual basis i.e.

  • Page 41: Warranty Card

    Warranty Card Customer Copy to be retained by the Customer Invoice Number: ______________________________ Dated: _________________________ Unit Serial Number: __________________________________ Model: _________________________ Capacity: ______________________ Customer's Name: _______________________________________________ Address: ____________________________________________________________________________ ____________________________________________________________________________________ Dealer’s Stamp and Signature Phone: ________________________ Mobile: ________________________ E-mail: ________________________ Company Copy to be sent back to the Company Invoice Number: ______________________________ Dated: _________________________ Unit Serial Number: __________________________________...

  • Page 42: Service And Maintenance

    Service and Maintenance For Service needs: Please contact our A. O. Smith Toll Free Number : 1800-103-2468 SMS us : +91 99410 32468 E-mail us : aosmithcs@aosmithindia.com Registered Office A. O. Smith India Water Products Private Limited (formerly known as A. O. Smith India Water Heating Private Limited) Plot No.

  • Page 43: Disclaimer

    Disclaimer Disclaimer Power of 1 is limited to: 1. Available in selected cities, for details log on to www.aosmithindia.com or call at 1800-103-2468. 2. Calls registered with A. O. Smith Customer Care Centre on working days before 4 pm. 3. Within city municipal limits only. 4.
  • Page 44 Manufactured by A. O. Smith India Water Products Private Limited (formerly known as A. O. Smith India Water Heating Private Limited) Plot No. 300, Phase-2, KIADB Industrial Area, Harohalli, Kanakapura Taluk, Ramanagara District - 562 112, Karnataka, India. Toll Free: 1800-103-2468  Website: www.aosmithindia.com CIN: U31909KA2006PTC040282 * Product colour and image may vary from the actual product.
