OWNER'S MANUAL
DIGITAL SPEAKER MANAGEMENT
M-6
Karaoke
UHF
Frequency Selectable
SET
®
Better Music Builder
PROGRAM EFFECTS
DIGITAL SPEAKER MANAGEMENT M-6
1. PRO STAR
2. KARAOKE REVERB
Digital Input & Analog Input / Built-In 2 Wireless Microphones
3． CONCERT REVERB
4． CATHEDRAL
5． CHORUS REVERB
6． SPEECH REVERB
7． LIVE SPEECH
POWER
8． VOCAL TEST
COX
Passionate about Music
It's what we do!
®
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual
carefully before operating it. Please
retain this manual for future reference.
Better Music Builder is protected by the
U.S.
and
international
copyright.
w w w. B e t t e rM usi c B ui l d e r.c o m
MAPS Generation
2022
Advertisement
Table of Contents
Related Manuals for Better Music Builder M-6
Summary of Contents for Better Music Builder M-6
- Page 1 Owner's Manual carefully before operating it. Please Please note that this procedure is retain this manual for future reference. exclusively for notifying Better Music Better Music Builder is protected by the Builder and its affiliates that your U.S. international copyright.
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..............................Intro SYSTEM FEATURES ............................Features SAFETY INSTRUCTIONS ..........................Safety PACKAGE ACCESSORIES ..........................Package SPEAKER CONNECTION METHODS AND INFORMATION ..............Connection SYSTEM APPLICATIONS ........................... Applications • Connecting the Whole System ........................• Multimedia Expansion Bay – Mp3 Source Input (USB) ................ -
Page 3: Introduction
Intro Features DIGITAL SPEAKER MANAGEMENT AMPLIFIER The new M-Series Multi-Function Digital Speaker Management Amplifier M-2/M-4/M-6 is our newest state of the art amplifier series designed to suit a home/commercial FEATURES: karaoke entertainment. The M-series allows for a versatile • Multi-Function: Power Amplifier + Wireless Microphone + karaoke system with multifunction device as wireless Pre-Effector, with simple connection and convenient matching. -
Page 4: Safety Instructions
DIGITAL ® PROFESSIONAL PROM 1 SUPER HALL BIG HALL Better Music Builder ® DIGITAL SPEAKER MANAGEMENT M-6 PROM 2 PROM 3 MIDDLE HALL MINI HALL Digital Input & Analog Input / Built-In 2 Wireless Microphones ® MIC VOL MUSIC VOL... - Page 5 DIGITAL ® PROFESSIONAL PROM 1 SUPER HALL BIG HALL Better Music Builder ® DIGITAL SPEAKER MANAGEMENT M-6 PROM 2 PROM 3 MIDDLE HALL MINI HALL Digital Input & Analog Input / Built-In 2 Wireless Microphones ® MIC VOL MUSIC VOL...
-
Page 6: Package Accessories
® DIGITAL PROM 1 PROM 2 PROM 3 PROM 4 Better Music Builder ® DIGITAL SPEAKER MANAGEMENT M-6 PROM 5 PROM 6 PROM 7 PROM 8 Digital Input & Analog Input / Built-In 2 Wireless Microphones ® MIC VOL MUSIC VOL EFFECTS VOL separately. -
Page 7: Speaker Connection Methods And Information
SPEAKER CONNECTION METHODS AND INFORMATION Connection METHODS OF SPEAKER CONNECTIONS SPEAKON CONNECTORS 1. Insert Type (Poor Connection) INPUT OUTPUT E R S S P E A K – GOOD NO GOOD 2– 2. Single Banana Plug Type (Better Connection) 1– E R S REFERENCE CONNECT S P E A K... -
Page 8: System Applications
SYSTEM APPLICATIONS Applications CONNECTING THE WHOLE SYSTEM M-6 focuses on karaoke business for multi sound function Bluetooth), 4 Analog Signal Inputs (VOD / HDMI 1 / HDMI purposes. It has 2 separate HDMI inputs and 1 HDMI 2 / 1/8” 3.5mm Stereo), 3 audio outputs (Main out / TV-ARC output, also available for connecting Bluetooth Center / Subwoofer) and 1 HDMI TV-ARC output. - Page 9 App Store Calculator Library Camera Recorder Setting Time Search ® Better Music Builder UHF Wireless System VM-52U G2 2-in-1 BASE RECEIVER MODULE POWER RF AF RF AF 15” STAGE BASS SUB Safari Mail Pictures iPod MIC 1 VOLUME MIC 2 VOLUME...
-
Page 10: Multimedia Expansion Bay - Mp3 Source Input (Usb)
PROM 2 PROM 3 PROM 4 PROGRAM EFFECTS Better Music Builder ® 1. PRO STAR DIGITAL SPEAKER MANAGEMENT M-6 PROM 5 PROM 6 PROM 7 PROM 8 2. KARAOKE REVERB Digital Input & Analog Input / Built-In 2 Wireless Microphones 3． ... -
Page 11: Connecting Audio/Video Input & Output Source
26. video source. Please refer to the below diagram. To ensure 1. Connecting Audio Input (VOD / 1/8” 3.5mm STEREO ) M-6 REAR VIEW PIN 1+ &1 - PI N 1 + &1 - California Proposition 65 Warning... - Page 12 NOTE system to an ARC-compatible TV, a high-speed HDMI cable must be connected from the TV M-6 REAR VIEW HDMI (ARC) IN port on the TV to the HDMI P IN 1 +& 1- P I N 1 + &1 -...
-
Page 13: Connecting Audio Output
Rear microphone input is designed NOTE MIC 1 GAIN GAIN MIC 2 for wireless microphone. REAR MIC INPUT ® Better Music Builder UHF Wireless System VM-52U G2 2-in-1 BASE RECEIVER MODULE RF AF RF AF MIC 1 VOLUME MIC 2 VOLUME POWER... -
Page 14: Controls And Functions
PROM 2 PROM 3 PROM 4 Better Music Builder PROGRAM EFFECTS ® 1. PRO STAR DIGITAL SPEAKER MANAGEMENT M-6 PROM 5 PROM 6 PROM 7 PROM 8 2. KARAOKE REVERB Digital Input & Analog Input / Built-In 2 Wireless Microphones 3． ... -
Page 15: Rear Panel
AC POWER AUDIO OUTPUT AUDIO INPUT BLUETOOTH REAR MIC INPUT MODEL NO.: M-6 ANTENNA USA 020898-1 CALIFORNIA, UNITED STATES OF AMERICA E-mail: sales@bettermusicbuilder.com w w w . B e t t e r M u s i c B u i l d e r . c o m ENGINEERED AND DESIGNED IN U.S.A. -
Page 16: Remote Control
REMOTE CONTROL: 2 inches 50 mm PROM1 PROM2 PROM3 5.75 inches/150 mm PROM5 PROM6 MUTE EFFECT EFFECT+ MUSIC VOLUME MIC VOLUME Remote Control Unit CHANGING BATTERIES Open the battery compartment cover on the back of the remote control unit. The cover should open easily if you press and slide it in the direction of the arrow. -
Page 17: Handheld Microphone
HANDHELD MICROPHONE: HANDHELD MICROPHONE LCD DISPLAY: After turning on the power, the LCD screen will display the following: CHANNEL: Current frequency channel depends on setting. FREQUENCY: Current value depends on setting. BATTERY STATUS: Indicates battery life. BATTERY STATUS: INTERCHANGEABLE MICROPHONE HEAD Full Battery Low Battery LCD DIGITAL DISPLAY: Displays frequency, channel and... -
Page 18: Operation
OPERATION Welcome... Operating LCD CONTROL PANEL OPERATION • MIC SETTING: Microphone Equalizer Setting 1. ADJUSTING SETTING MIC EQ Setting... Return STEP 1: Press “SET” to go to the settings page. ( Hz) ENGLISH MIC 1 MIC 2 PROM 1 PROM 2 PROM 3 PROM 4 PROM 5... - Page 19 2. 8 PROGRAM MODES SELECTION: 3. ADJUSTING MIC/MUSIC/EFFECT VOLUMES STEP 1: Select the desired program modes. Press – or + to select the desired volume levels. ENGLISH ENGLISH MIC 1 MIC 2 MIC 1 MIC 2 PROM 1 PROM 2 PROM 3 PROM 4 PROM 1...
- Page 20 4. Turn on Bluetooth Bluetooth Bluetooth 5. Turn on Bluetooth 5. Go into Bluetooth 6. Look for “M-6” on the list of “Devices” 6. Look for “M-6” on the list of “Availabe devices” Bluetooth General Bluetooth Bluetooth Available devices Devices Not Connected 7 .
- Page 21 PROM 2 PROM 3 PROM 4 PROGRAM EFFECTS Better Music Builder ® 1. PRO STAR DIGITAL SPEAKER MANAGEMENT M-6 PROM 5 PROM 6 PROM 7 PROM 8 2. KARAOKE REVERB 3． CONCERT REVERB Digital Input & Analog Input / Built-In 2 Wireless Microphones ®...
-
Page 22: Professional/Commercial Use
EFFECT CONTROL SOFTWARE SUITE INSTRUCTIONS EFFECT CONTROL SOFTWARE SUITE INSTRUCTIONS For Professional/Commercial use of the Better Music Builder connect the M-6 to the computer (PC) with the installed ® Effect Control Software Suite (M-6), use the USB cable and software. - Page 23 SOFTWARE INSTALLATION MAIN LEFT SPEAKER INTERFACE Open the control software by computer , then connect the USB cable, click the "Connect" in the software menu, if display "Connect successfully", it means you can control in real time. During the connection control period, the display of the amplifier will appear USB connection mark, so it is not available to manually control and intervene the computer control.
-
Page 24: Physical Dimensions
PROM 4 PROGRAM EFFECTS Better Music Builder ® Adjacent frequency suppression ＞60dBm 1. PRO STAR DIGITAL SPEAKER MANAGEMENT M-6 PROM 5 PROM 6 PROM 7 PROM 8 2. KARAOKE REVERB Digital Input & Analog Input / Built-In 2 Wireless Microphones 3． ... -
Page 25: Troubleshooting
TROUBLESHOOTING Troubleshooting 1. MUSIC VOLUME IS TOO LOW 8. NO VIDEO SIGNAL OR VIDEO SIGNAL IS UNSTABLE CAUSE: the music volume limiter is set too low. It is possible that your DVD player is in PAL video format. REMEDY: adjust to a higher “Max Music Volume.” NTSC video format is used in North America. -
Page 26: Appendix
15. NOISE COMING FROM MICROPHONE APPENDIX CAUSE: There is interference in the area. Appendix REMEDY: FCC FREQUENCY: 640.000-690.000 MHz • Change the frequency on the microphone and receiver. • Stand further away from speakers. • Check the amplifier status and adjust microphone and music UHF Frequencies Available for Use for Home Electronics in volumes. - Page 27 MIC 1 & MIC 2 FREQUENCY 640.000-690.000 MHz MIC 1 FREQUENCY 640.000-664.750 MHz MIC 2 FREQUENCY 665.000-689.750 MHz FREQUENCY FREQUENCY FREQUENCY FREQUENCY FREQUENCY FREQUENCY FREQUENCY FREQUENCY 646.250 652.500 658.750 671.250 677 .500 683.750 640.000 665.000 646.500 652.750 659.000 671.500 677 .750 684.000 640.250 665.250...
-
Page 28: Warranty
WARRANTY Warranty ONE-YEAR LIMITED WARRANTY FOR HOME USE ADDITIONAL NOTES: EQUIPMENT 1. Limited warranty for home use equipment is only valid in Our one-year warranty covers both parts and labors. The North America. warranty becomes effective from the date of your purchase 2. -
Page 29: Agency Regulatory Notices
AGENCY REGULATORY NOTICES Notices FEDERAL COMMUNICATIONS COMMISSION NOTICE your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a These limits are designed to provide reasonable protection manner that protects human health and the environment. For against harmful interference in a residential installation. -
Page 30: Final Words To User
DEALER NAME______________________________________ machine to shut down suddenly. CITY_____________ ST./PROV.______ZIP/P.C.____________ Again, we must thank you for choosing Better Music Builder DEALER WEBSITE http://www.________________________ product. We hope you can make the best use of the machine and enjoy it for years to come. If you have any... - Page 31 MAINTENANCE NOTE...
- Page 32 Owner's Manual carefully before operating it. Please retain this manual for future reference. 409220520600 Printed on 100% Recycled Paper Code: 20220427 Comments E-mail to sales@bettermusicbuilder.com Copyright © 2022 Better Music Builder. All rights reserved. Legal trademark.
