HP ProCurve 4148 Specifications page 13

ProCurve Switch 4100gl Series
ProCurve Gigabit-SX-LC Mini-GBIC (J4858C)
A small form factor pluggable (SFP) gigabit SX
transceiver that provides a full-duplex gigabit solution
up to 550 meters on multimode fiber.
ProCurve Gigabit-LX-LC Mini-GBIC (J4859C)
A small form factor pluggable (SFP) gigabit LX
transceiver that provides a full-duplex gigabit solution
up to 10 km (singlemode) or 550 m (multimode).
ProCurve Gigabit-LH-LC Mini-GBIC (J4860C)
A small form factor pluggable (SFP) gigabit LH
transceiver that provides a full-duplex gigabit solution
up to 70 km on singlemode fiber.
Ports
1 LC 1000Base-SX port (IEEE 802.3z
Type 1000Base-SX)
Duplex: full only
Physical characteristics
Dimensions: 2.24(d) x 0.54(w) x
0.486(h) in. (5.69 x 1.37 x 1.23 cm)
Weight: 0.04 lb. (0.02 kg)
Cabling
Type:
• 62.5/125 µm or 50/125 µm
(core/cladding) diameter, graded-index,
Ports
1 LC 1000Base-LX port (IEEE 802.3z Type
1000Base-LX)
Duplex: full only
Physical characteristics
Dimensions: 2.24(d) x 0.54(w) x
0.486(h) in. (5.69 x 1.37 x 1.23 cm)
Weight: 0.04 lb. (0.02 kg)
Cabling
Type:
• Either single mode or multimode
• 62.5/125 µm or 50/125 µm
(core/cladding) diameter, graded-index,
low metal content, multimode fiber optic,
complying with ITU-T G.651 and ISO/IEC
Ports
1 LC 1000Base-LH port (no IEEE standard
exists for 1550 nm optics)
Duplex: full only
Physical characteristics
Dimensions: 2.17(d) x 0.60(w) x 0.46(h)
in. (5.5 x 1.53 x 1.18 cm)
Weight: 0.04 lb. (0.02 kg)
Cabling
low metal content, multimode fiber optic,
complying with ITU-T G.651 and ISO/IEC
793-2 Type A1b or A1a, respectively
Maximum distance:
• 220 m (62.5 µm core diameter, 160
MHz/km bandwidth)• 275 m (62.5 µm
core diameter, 200 MHz/km
bandwidth)• 500 m (50 µm core
diameter, 400 MHz/km bandwidth)• 550
m (50 µm core diameter, 500 MHz/km
bandwidth)
793-2 Type A1b or A1a, respectively
• Low metal content, single-mode
fiber-optic, complying with ITU-T G.652
and ISO/IEC 793-2 Type B1
Maximum distance:
• 10 km (single mode) or 550 m
(multimode)
Notes
A mode conditioning patch cord may be
needed in some multimode fiber
installations.
Type:
• Low metal content, single-mode
fiber-optic, complying with ITU-T G.652
and ISO/IEC 793-2 Type B1
Maximum distance:
• 70 km
