(250PO) SPA (JET + HARD WATER) ENGLISH 7.5" X 10.3" PANTONE 295U 06/12/2015
PureSpa™
SPJ-H-10-2
110-120V~, 60Hz, 12A
For illustrative purposes only.
Do not forget to try these other fi ne Intex products: pools, pool
accessories, in-home toys, airbeds and boats available at fi ne
retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves
the right to change specifi cations and appearance, which may
result in updates to the instruction manual without notice.
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, visit
www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacifi c Time
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
IMPORTANT!
250
English
PO
250-*PO-R0-1606

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PureSpa SPJ-H-10-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Intex PureSpa SPJ-H-10-2

Summary of Contents for Intex PureSpa SPJ-H-10-2

  • Page 1 SPJ-H-10-2 110-120V~, 60Hz, 12A For illustrative purposes only. Do not forget to try these other fi ne Intex products: pools, pool accessories, in-home toys, airbeds and boats available at fi ne retailers or visit our website. Due to a policy of continuous product improvement, Intex reserves the right to change specifi...

  • Page 2: Table Of Contents

    (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English TABLE OF CONTENTS Warning..................3-5 Parts....................Set-up..................... 8-11 Operation..................LED Code Chart................13 Maintenance and Chemicals............14-19 Storage................... 19 Troubleshooting................20 Warranty..................21 Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 3: Warning

    (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed, including the following. READ AND FOLLOW ALL INSTRUCTIONS • A green coloured terminal or a terminal marked G, GR, Ground, Grounding, or the symbol is located inside the supply terminal box or compartment.
  • Page 4 (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed, including the following. READ AND FOLLOW ALL INSTRUCTIONS DANGER •...
  • Page 5 • Do not allow the water in the spa to freeze. Do not turn on the spa when the water is frozen. • Do not use the spa if damaged in delivery and/or malfunctioning in any fashion. Contact the Intex service center for further direction.

  • Page 6: Parts

    (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English PARTS Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. S AVE THESE INSTRUCTIONS Page 6...
  • Page 7 (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English PARTS (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. REF. NO. DESCRIPTION QTY. PART NO.

  • Page 8: Set-Up

    (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English PRODUCT SPECIFICATIONS Maximum seating capacity: 4 adults Water capacity: 210 gal (795 L) Inner/outer diameter: 57/77 in (145/196 cm) Height: 28 in (71 cm) Jet pump: 0.9HP / 120 V / 60 Hz Filter pump fl...
  • Page 9 Lay out all the parts on the ground and make sure all the parts are accounted for. For missing or damaged parts contact the appropriate Intex Service Center listed in the separate “Authorized service Centers” sheet. Safety Sign Card Posting The Safety Sign card included with the manual shall be posted in an area visible to the users of the spa to alert them of the safety rules and warnings.
  • Page 10 (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English SET UP (continued) Turn off the electric air pump. Disconnect the infl ation hose (7) from the electric air pump, then connect it to the manual pump to infl ate the spa tub for 1 - 2 minutes (see drawing 5). IMPORTANT: Do not over infl...
  • Page 11 (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English SET UP (continued) Defl ation For Spa Tub Wall: Unscrew the cap to reveal the stem, push the stem in and turn 90 degree right to secure it in the down position (see drawing 8).

  • Page 12: Operation

    (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English OPERATION SPA CONTROL UNIT PANEL A: Heat Button B: Celsius/Fahrenheit Toggle Button C: Temperature Increase Button D: Temperature Decrease Button E: Water Filter Button F: Water Jet Button G: LED Display H On/Off Button Once the unit is plugged in, use this button to active the control unit panel...

  • Page 13: Led Code Chart

    Plug the GFCI/RCD and restart all over again. • If problem persists, contact Intex Service Center. Water temperature sensor broken • Contact Intex Service Center. After 72 hours of continuous heating operation, the pump will hibernate • Press the water fi lter button to re-active the automatically.

  • Page 14: Maintenance And Chemicals

    Do not add chemicals if the spa is occupied. This can cause skin or eye irritation. Concentrated chlorine solutions can damage the spa tub. In no event is Intex Recreation Corp., Intex Development Co. Ltd., their related companies, authorized agents and service centers, retailers or employees liable to the buyer or any other party for costs associated with the loss of spa water, chemicals or water damage.
  • Page 15 (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English SPA WATER CHEMISTRY AND BALANCE Preferred Water Chemistry Reading Minimum Ideal Maximum 2 ppm 2 - 4 ppm 5 ppm Free Chlorine 7.2 - 7.6 60 ppm 80 ppm 120 ppm Total Alkalinity (TA)
  • Page 16 (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English SPA WATER CHEMISTRY AND BALANCE (continued) SPA Water Adjustment How to adjust the spa water chemistry when the levels are off the range. CAUTION: Always follow the chemical manufacturer’s directions, and the health and hazard warnings.
  • Page 17 (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English SPA WATER CHEMISTRY AND BALANCE (continued) Lowering pH Lowering pH Using Muriatic Acid From→To Volume Total Alkalinity 8.4→7.2 7.8→7.2 0.028 qt 0.019 qt 120 ppm 26 mL 18 mL 210 gal (800 L)
  • Page 18 (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English MAINTENANCE Spa Tub Drainage Turn off and unplug the spa control unit. Connect the drain valve adaptor to a garden hose and point the other end of the garden hose to a suitable draining area (see drawing 12).

  • Page 19: Storage

    (250PO) SPA (JET + HARD WATER) ENGLISH 7.5” X 10.3” PANTONE 295U 06/12/2015 English MAINTENANCE (continued) Spa Tub and Cover Air Bladder Repair Use the enclosed repair patch to repair any puncture: • Clean and dry the area to be repaired thoroughly. •...

  • Page 20: Troubleshooting

    • Turn off and unplug the spa. Let it cool down and NOT WORK restart all over again. • If problem persists contact Intex Service Center. JET OUTPUT IS WEAK • Low water level. • Add water between MIN and MAX level.

  • Page 21: Warranty

    WARRANTY Your PureSpa has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only to the PureSpa listed below. The provisions of this Limited Warranty apply only to the original purchaser and is not transferable.
