HP ProCurve Switch 4100gl series

Specifications

Standard configurations
8-slot chassis has an integrated
switching engine and a power
supply. Supports a maximum
of 192 10/100 ports or
160 Gigabit ports and
16 mini-GBICs.
Switch 4160gl:
60 RJ-45 10/100/1000 ports
(3 x J4908A);
6 mini-GBIC slots;
5 open module slots
Switch 4108gl bundle:
72 10/100 ports (3 x J4862B);
3 transceiver ports (1 x J4864A);
4 open module slots
Switch 4108gl:
8 open module slots
4-slot chassis has an integrated
switching engine and a power
supply. Supports a maximum of
96 10/100 ports or 80 Gigabit
ports and 8 mini-GBICs.
Switch 4140gl:
40 RJ-45 10/100/1000 ports
(2 x J4908A);
4 mini-GBIC slots;
2 open module slots
Switch 4148gl:
48 10/100 ports (2 x J4862B);
2 open module slots
Switch 4104gl:
4 open module slots
© 2003 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change
without notice. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
To learn more, visit www.hp.com/go/hpprocurve.
5981-9641EN, 08/2003
Physical characteristics
Dimensions
– Switch 4160gl, 4108gl bundle,
and 4108gl:
17.4 × 15.3 × 8.75 in.
(44.2 × 38.9 × 22.23 cm)
(5U height)
– Switch 4140gl, 4148gl, and
4104gl:
17.4 × 15.3 × 5.25 in.
(44.2 × 38.9 × 13.34 cm)
(3U height)
Weight
– Switch 4160gl:
30.6 lb. (13.9 kg)
– Switch 4108gl bundle:
22.9 lb. (10.4 kg)
– Switch 4108gl:
20.7 lb. (9.4 kg)
– Switch 4140gl:
24.1 lb. (10.9 kg)
– Switch 4148gl:
15.85 lb. (7.2 kg)
– Switch 4104gl:
14.75 lb. (6.7 kg)
Memory and processor
Fabric: Motorola PowerPC @ 200
MHz, 8 MB flash, 32 MB
SDRAM
Packet buffer size: 1 MB (8-slot
Fabric); 512 KB (4-slot Fabric)
Mounting
Mounts in an EIA-standard 19 in.
telco rack or equipment cabinet
(hardware included); horizontal
surface mounting only
Performance
Latency:
– 100 MB:
<10.2 µs (FIFO 64-byte packets)
– 1000 MB:
<3.5 µs (FIFO 64-byte packets)
Throughput:
– Switch 4160gl, 4108gl bundle,
and 4108gl: up to 71.4 mpps
– Switch 4140gl, 4148gl, and
4104gl: up to 35.7 mpps
Switch fabric speed:
– Switch 4160gl, 4108gl bundle,
and 4108gl: 36.6 Gbps
– Switch 4140gl, 4148gl, and
4104gl: 18.3 Gbps
Address table size: 8,000 entries
Environment
Operating
– Temperature: 32º F to 131º F
(0º C to 55º C)
– Relative humidity: 15% to 95% @
104º F (40º C) non-condensing
Non-operating/Storage
– Temperature: –40º F to 158º F
(–40º C to 70º C)
– Relative humidity: 15% to 95% @
149º F (65º C) non-condensing
Altitude: up to 15,091 ft. (4.6 km)
Electrical characteristics
Heat dissipation:
2,152 BTU/hr
Power: 630W
Voltage: 100–127 VAC/
200–240 VAC
Current: 8.2A/3.8A
Frequency range: 50/60 Hz
Safety
cUL (CSA 950)
EN 60950/IEC 950
NOM-019-SCFI-1994
UL 1950 3rd edition
Emissions
FCC Class A
EN 55022/CISPR-22 Class A
VCCI Class A
Immunity
EN 55024/CISPR-24
ESD: IEC 61000-4-2, 4 kV CD,
8 kV AD
Radiated: IEC 61000-4-3, 3V/m
EFT/Burst: IEC 61000-4-4, 1.0 kV
(power line), 0.5 kV (signal line)
Surge: IEC 61000-4-5, 1 kV/2 kV
AC
Conducted: IEC 61000-4-6, 3V
Power frequency magnetic field:
IEC 61000-4-8, 1A/m, 50 or
60 Hz
Voltage dips and interruptions:
IEC 61000-4-11, >95%
reduction, 0.5 period, 30%
reduction, 25 periods
Harmonics: EN 61000-3-2/IEC
61000-3-2
Flicker: EN 61000-3-3/IEC
61000-3-3
Management
HP ProCurve Manager (included);
HP ProCurve Manager Plus;
command line interface; Web
browser; configuration menu;
out-of--band management (serial
RS-232C)
Standards and protocols
RFC 783 TFTP
RFC 951 BootP
RFC 1542 BootP
RFC 854 Telnet
RFC 768 UDP
RFC 792 ICMP
RFC 793 TCP
RFC 826 ARP
RFC 2030 Simple Network Time
Protocol
IEEE 802.3X Flow Control
DHCP Relay
RFC 2236 IGMPv1/v2/v3
IEEE 802.1D Spanning Tree
IEEE 802.1w Rapid Convergence
Spanning Tree
IEEE 802.3ad Link Aggregation
Control Protocol
Cisco Fast EtherChannel (FEC)
®
RFC 1492 TACACS+
RFC 2138 RADIUS
RFC 2866 RADIUS accounting
SSHv1/SSHv2 Secure Shell
IEEE 802.1X Network Login
IEEE 802.1Q VLAN tagging
IEEE 802.1Q GVRP
IEEE 802.1p Priority
SNMPv1/v2c/v3
HTML and telnet management
RFC 1493 Bridge MIB
RFC 1213 MIB II
RFC 2096 IP Forwarding Table
MIB
RFC 2737 Entity MIB
RFC 2863 Evolution of Interface
RFC 2665 Ethernet MIB
RFC 2819 Four groups of
RMON: 1 (statistics), 2 (history),
3 (alarm), and 9 (events)
RFC 2021 RMON probe
configuration (RMON v2)
RFC 2668 802.3 MAU MIB
RFC 2613 SMON
RFC 2674 802.1p and 802.1Q
Bridge MIB
RFC 2618 RADIUS Client MIB
RFC 2620 RADIUS Accounting
MIB
