DEMO MANUAL DC2608

PARTS LIST

ITEM QTY REFERENCE
DC2608 Required Circuit Components
1 21 C1 TO C11
2 7 C22, C24, C25, C30,
C31, C33, C34
3 7 C23, C26, C27, C28,
C29, C32, C35
4 4 E1, E2, E3, E4
5 1 J1
6 1 J2
7 1 R1
8 1 R2
9 3 R3, R4, R5
10 1 U1
11 1 U2
12 2 MH1, MH2
DC2210 Required Circuit Components
1 1 C1
2 1 J1
3 2 J2, J3
4 0 R1, R2
5 1 R3
6 1 U1
7 4 MH1-MH4
20
PART DESCRIPTION
CAP., NP0, 100pF 100V, 5%, 0603
CAP., X7R, 10µF 10V, 10%, 0805
CAP., X7R, 0.1µF 25V, 10%, 0603
TURRET, TESTPOINT 0.064"
CONN., 40P, CON-HIROSE-FX2-40P-1.27DS
CONN., HEADER 14POS 2mm VERT GOLD
RES., CHIP, 1Ω, 1/10W, 5% 0603
RES., CHIP, 100k, 1/10W, 1% 0603
RES., CHIP, 4.99k, 1/10W, 1% 0603
I.C., LTC2986CLX-1, LQFP48LX-7X7
I.C., 24LC025-I/ST, TSSOP8
STANDOFF, NYLON, 0.25", 1/4"
CAP., X7R, 0.1μF 25V, 10%, 0603
CONN., 40P, CON-HIROSE-FX2-40S-DAUGHTER
CONN., TERM BLOCK 2.54mm 12POS
RES., 0603
RES., CHIP, 4.99k, 1/10W, 1% 0603
I.C., EEPROM 2KBIT 400kHz 8TSSOP
STANDOFF, NYLON, 0.25", 1/4"
MANUFACTURER/PART NUMBER
MURATA, GRM1885C2A101JA01D
MURATA, GRM21BR71A106KE51L
MURATA, GRM188R71E104KA01D
MILL-MAX, 2308-2-00-80-00-00-07-0
HIROSE, FX2-40P-1.27DS
MOLEX, 87831-1420
VISHAY, CRCW06031R00FJEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW06034K99FKEA
LINEAR TECH., LTC2986CLX-1
MICROCHIP, 24LC025-I/ST
KEYSTONE, 8831 (SNAP ON)
MURATA, GRM188R71E104KA01D
HIROSE, FX2-40S-1.27DS(71)
PHOENIX, 1725753
OPT
PANASONIC, ERJ-3EKF4991V
MICROCHIP, 24LC025-I/ST
KEYSTONE, 8831 (SNAP ON)
