HP A5830 Switch Series

Installation Guide

Abstract

This document guides you through installation of HP A Series products, including installing the device,

connecting to the network, hardware management, and troubleshooting.

Part number: 5998-2058 Version 3

Document version: 6W100-20110720

Need help?

Do you have a question about the JC691A and is the answer not in the manual?

Questions and answers

Summary of Contents for HP JC691A

Page 1 HP A5830 Switch Series Installation Guide Abstract This document guides you through installation of HP A Series products, including installing the device, connecting to the network, hardware management, and troubleshooting. Part number: 5998-2058 Version 3 Document version: 6W100-20110720...
Page 2 The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an...
Page 3 Contents Preparing for installation ············································································································································· 1 Overview············································································································································································1 Safety recommendations ··················································································································································1 Installation site requirements ···································································································································1 Rack-mounting requirements····································································································································2 Installation tools·································································································································································2 Installing the switch ······················································································································································ 3 Confirming installation preparations ······························································································································4 Installing the switch in a 19-inch rack ····························································································································4 Mounting bracket and cable management bracket kits·······················································································4 Rack mounting rail kit ··············································································································································5 Rack-mounting procedure ········································································································································6 Identifying the mounting position····························································································································6...
Page 4 Maintenance and troubleshooting ····························································································································37 Power supply failure ······················································································································································ 37 Fan failure······································································································································································· 37 Configuration terminal problems·································································································································· 37 Support and other resources ·····································································································································39 Contacting HP ································································································································································ 39 Subscription service ·············································································································································· 39 Related information························································································································································ 39 Documents······························································································································································ 39 Websites ································································································································································ 39 Conventions ···································································································································································· 40 Appendix A Technical specifications ·······················································································································42...
Page 5 96G Model Switch BJNGA-AC0002 A5830AF-96G IMPORTANT: For regulatory identification purposes, the switches are assigned RMN. These regulatory numbers should not be confused with the marketing name HP A5830AF, or the product numbers JC691A, and JC694A. Safety recommendations WARNING! Compliance and Safety Gui...
Page 6 Rack-mounting requirements Before rack-mounting a switch, make sure the rack meets the following requirements: HP recommends that you mount a switch in an open rack. If you mount a switch in a closed rack, • make sure there is a good heat dissipation system.
Page 7 CAUTION: Keep the tamper-proof seal on a mounting screw on the chassis cover intact. If you want to open the chassis, contact HP for permission. Otherwise HP shall not be liable for any consequence. Figure 1 Hardware installation flow Start...
Page 8 NOTE: When you install a 96G model switch, skip the procedure for installing an expansion interface card. The switch does not support expansion interface cards. Confirming installation preparations Before you install the switch, make sure: You have read “Preparing for installation” carefully and the installation site meets all the •...
Page 9 Figure 3 2U cable management bracket and mounting bracket kit (1) Cable management bracket (2) Mounting bracket Rack mounting rail kit The switches come with a pair of chassis rails and a pair of slide rails. Figure 4 Chassis rail and slide rail kit for the 48G model (1) Chassis rail (2) Slide rail The slide rails supplied with a 48G model switch are short.
Page 10 Figure 5 Chassis rail and slide rail kit for the 96G model (1) Chassis rail (2) Slide rail Rack-mounting procedure You can install a switch in a 19-inch rack using different mounting positions. Figure 6 shows the rack- mounting procedure. Figure 6 Rack-mounting procedure NOTE: If a rack shelf is available, you can put the switch on the rack shelf, slide the switch to an appropriate...
Page 11 Table 6 Minimum and maximum distances required between front and rear rack posts Minimum distance Maximum distance Switch model Mounting accessories between front and between front and rear rack posts rear rack posts Mounting brackets and short slide rails (supplied 401 mm (15.79 in) 654 mm (25.75 in) with the switch)
Page 12 If the mounting brackets are in the rear mounting position, align the chassis rails with the screw holes at the front of the side panels (see Figure 8). If the mounting brackets are in the front mounting position, align the chassis rails with the screw holes at the rear of the side panels (see Figure Use M4 screws (supplied with the switch) to fix the chassis rails to the chassis.
Page 13 Figure 9 Attaching the front mounting brackets and the chassis rails to the chassis Installing the mounting brackets, chassis rails, and grounding cable (for the 96G model) The 96G model switch has one front mounting position near the network ports and one rear mounting position near the power supplies.
Page 14 Align the chassis rails with the screw holes at the side panels (see Figure 11 Figure 12). Use M4 screws supplied with the switch to fix the chassis rails to the chassis. Connecting the grounding cable to the switch chassis CAUTION: The primary grounding point and auxiliary grounding point are located on the left side panel.
Page 15 Figure 12 Attaching the front mounting brackets and the chassis rails to the chassis Rack-mounting the 48G model switch To attach the slide rails to the rack: Identify the rack attachment position for the slide rails. Install cage nuts (user-supplied) in the mounting holes in the rack posts. Align the screw holes in one slide rail with the cage nuts in the rack post on one side, and use screws (user supplied) to fix the slide rail to the rack, as shown in Figure...
Page 16 Check that the slide rails have been correctly attached to the rack posts. Install cage nuts (user-supplied) to the front rack posts and make sure they are at the same level as the slide rails. Supporting the bottom of the switch, align the chassis rails with the slide rails on the rack posts, as shown in Figure 14.
Page 17 Rack-mounting the 96G model switch To attach the slide rails to the rack: Identify the rack attachment position for the slide rails. Install cage nuts (user-supplied) in the mounting holes in the rack posts. Align the screw holes in one slide rail with the cage nuts in the rack post on one side, and use screws (user supplied) to fix the slide rail to the rack, as shown in Figure Repeat the preceding steps to attach the other slide rail to the rack post on the other side.
Page 18 Figure 17 Mounting the switch in the rack (I) Figure 18 Mounting the switch in the rack (II) Grounding the switch WARNING! Correctly connecting the switch grounding cable is crucial to lightning protection and EMI protection.
Page 19 The power input end of the switch has a noise filter, whose central ground is directly connected to the chassis to form the chassis ground (commonly known as PGND). You must securely connect this chassis ground to the earth so the faradism and leakage electricity can be safely released to the earth to minimize EMI susceptibility of the switch.
Page 20 The ground contact in the power outlet is securely connected to the ground in the power distribution • room or on the AC transformer side. The power cable is securely connected to the power outlet. • Figure 20 Grounding through the PE wire of an AC power cable Installing/removing a fan tray CAUTION: The switches have only one fan tray slot.
Page 21 For more information about the cooling system and fan tray specifications of the switch, see “ ” “Table 13." HP A5830 Switch Series Fundamentals • For more information about the fan prefer-direction slot command, see Command Reference Installing a fan tray...
Page 22 Figure 22 Installing a fan tray (for the 96G model) Removing a fan tray WARNING! Take out the fan tray after the fans completely stop rotating. To avoid an unbalanced fan causing loud noise, do not touch the fans, even if they are not rotating. Wear an ESD-preventive wrist strap: make sure it makes good skin contact and is well grounded.
Page 23 again. If you cannot insert the power supply into the slot, re-orient the power supply rather than use excessive force to push it in. Figure 23 Installing a power supply (for the 48G model Figure 24 Installing a power supply (for the 96G model) Removing a power supply CAUTION: If the switch has two power supplies, removing one power supply does not affect the operation of the...
Page 24 Figure 25 Removing the DC power cord (1) Press the tabs on the power cord connector with your (2) Pull the power cord connector out thumb and forefinger Figure 26 Removing the power supply (for the 48G model) (1) Pivot the latch to the right with your thumb (2) Pull the power supply out...
Page 25 Figure 27 Removing the power supply (for the 96G model) (1) Pivot the latch up with your thumb (2) Pull the power supply out Connecting the power cord Connecting the 650W AC power supply (JC680A) Insert the female connector of the AC power cord supplied with the power supply into the AC-input power receptacle of the power supply.
Page 26 If you cannot insert the plug into the receptacle, re-orient the plug rather than use excessive force to push it in. Use a cable tie to secure the power cord to the handle of the power supply, as shown in Figure Connect the other end of the power cord to the DC power source.
Page 27 Figure 31 Installing an interface card (1) Slide the interface card into the slot (2) Tighten the captive screws Removing an interface card Wear an ESD-preventive wrist strap: make sure it makes good skin contact and is well grounded. Use a Phillips screwdriver to loosen the captive screws at both sides of the interface card completely.
Page 28 Powering on the switch for the first time Setting up the configuration environment To set up the configuration environment, connect a terminal (a PC in this example) to the console port on the switch with a console cable. Figure 33 Network diagram for configuration environment setup Connecting the console cable Console cable A console cable is an 8-core shielded cable, with a crimped RJ-45 connector at one end for connecting...
Page 29 Identify the mark on the console port and make sure that you are connecting to the correct port. Plug the DB-9 female connector of the console cable to the serial port of the console terminal or PC. Connect the RJ-45 connector to the console port of the switch. NOTE: •...
Page 30 Figure 36 Setting the serial port used by the HyperTerminal connection Set Bits per second to 9600, Data bits to 8, Parity to None, Stop bits to 1, and Flow control to None, and click OK. Figure 37 Setting the serial port parameters Select File >...
Page 31 Figure 38 HyperTerminal window Click the Settings tab, set the emulation to VT100, and click OK in the Switch Properties dialog box. Figure 39 Setting terminal emulation in Switch Properties dialog box...
Page 32 Power on the switch (for example, an A5830AF-48G switch), and you can see the following information: System is starting... Booting Normal Extend BootWare..The Extend BootWare is self-decompressing.....Done! **************************************************************************** HP A5830AF BootWare, Version 1.03 **************************************************************************** Copyright (c) 2010-2011 Hewlett-Packard Development Company, L.P. Compiled Date : Feb 22 2011...
Page 33 System application is starting... User interface aux0 is available. Press ENTER to get started. Press Enter at the prompt. When the prompt <HP> appears, you can configure the switch. NOTE: HP A5830 Switch Series For more information about the configuration commands and CLI, see...
Page 34 Setting up an IRF fabric You can use HP IRF technology to connect and virtualize the switches into a virtual switch called an “IRF fabric” or “IRF virtual device” for flattened network topology, and high availability, scalability, and manageability. IRF fabric setup flowchart...
Page 35 Power on the switches. N/A. Configure basic See HP A5830 Switch Series IRF Configuration Guide. settings. Connect the physical IRF ports on the switches. Use SFP+ transceiver modules and fibers to connect 10-Gigabit SFP+ ports over a long distance, or use...
Page 36 Prepare an IRF member ID assignment scheme. An IRF fabric uses member IDs to uniquely identify and manage its members, and you must assign each IRF member switch a unique member ID. Planning IRF topology and connections You can create an IRF fabric in daisy chain topology, or more reliably, ring topology. In ring topology, the failure of one IRF link does not cause the IRF fabric to split as in daisy chain topology.
Page 37 Table 20 Table 21 list the SFP+ transceivers and SFP+ cables available for IRF connections. The following subsections describe several HP recommended IRF connection schemes. All these schemes use a ring topology. IMPORTANT: In these schemes, all physical IRF ports are located on the same side. If physical IRF ports are on...
Page 38 Connecting the IRF member switches in one rack Use short-haul and long-haul SFP+ cables to connect the IRF member switches (four switches in this example) in a rack as shown in Figure 43. The switches in the ring topology (see Figure 44) are in the same order as connected in the rack.
Page 39 Create a Layer 3 interface, assign it an IP address, and make sure that the IRF fabric and the remote network management station can reach each other. Use Telnet, web, or SNMP to access the IRF fabric from the network management station. (See HP A5830 Switch Series Fundamentals Configuration Guide.) Check that you can manage all member switches as if they were one node.
Page 40 To avoid IP address collision and network problems, configure at least one MAD mechanism to detect the presence of multiple identical IRF fabrics and handle collisions. For more information about MAD HP A5830 Switch Series IRF Configuration Guide detection, see...
Page 41 Plug a new power supply of the same model into the same slot, and connect it to the same power input end. If the new power supply can work properly, the old power supply has failed. Contact HP technical support to replace the old power supply.
Page 42 Data bits—8 • Parity—none • Stop bits—1 • Flow control—none • Emulation—VT100 •...
Page 43 Related information Documents To find related documents, browse to the Manuals page of the HP Business Support Center website: http://www.hp.com/support/manuals For related documentation, navigate to the Networking section, and select a networking category. •...
Page 44 Conventions This section describes the conventions used in this documentation set. Command conventions Convention Description Boldface Bold text represents commands and keywords that you enter literally as shown. Italic Italic text represents arguments that you replace with actual values. Square brackets enclose syntax choices (keywords or arguments) that are optional. Braces enclose a set of required syntax choices separated by vertical bars, from which { x | y | ...
Page 45 Network topology icons Represents a generic network device, such as a router, switch, or firewall. Represents a routing-capable device, such as a router or Layer 3 switch. Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that supports Layer 2 forwarding and other Layer 2 features.
Page 46 Appendix A Technical specifications Technical specifications Table 9 Switch technical specifications Item 48G model 96G model Dimensions (H × W × 43.6 × 440 × 460 mm (1.72 × 17.32 86 × 440 × 700 mm (3.39 × 17.32 × ×...
Page 47 HP A5830AF-48G back (power side) to Back-to-front airflow fan tray JC692A front (port side) airflow Fan Tray (JC692A) HP A5830AF-48G front (port side) to back Front-to-back airflow fan tray JC693A (power side) airflow Fan Tray (JC693A) HP A5830AF-96G back (power side) to...
Page 48 Figure 47 Rear panel 100-240Vac 100-240Vac (1) System status LED (SYS) (2) Expansion interface card slot (3) Fan tray slot (4) Power supply slot 1 (PWR1) (5) Power supply slot 2 (PWR2) NOTE: The 48G model switch comes with the expansion interface card slot and the fan tray slot covered by filler panels and the power supply slots installed with filler modules.
Page 49 (9) System status LED (SYS) Figure 50 Rear panel (1) Power supply slot 1 (PWR1) (2) Power supply slot 2 (PWR2) (3) Fan tray slot (4) System status LED (SYS) NOTE: The 96G model switch comes with the fan tray slot covered by a filler panel and the power supply slots installed with filler modules.
Page 50 Figure 52 Airflow through the switch chassis with the back-to-front airflow fan tray (JC692A) Power side Port side (1) Power supply air vents (2) Fan tray air vents (3) Port side air vents Figure 53 Airflow through the switch chassis with the front-to-back airflow fan tray (JC693A) Power side Port side (1) Power supply air vents...
Page 51 Cooling system of the 96G model When a back-to-front airflow fan tray (JC695A) is used, ambient air flows in through the air vents in • the fan tray panel and the power supply panels, circulates through the chassis and the power supplies, and exhausts at the port side, as shown in Figure When a front-to-back airflow fan tray (JC696A) is used, ambient air flows in through the air vents in...
Page 52 • Rated input voltage range: 100 VAC to 240 VAC; 50 Hz or 60 48G model 650W AC HP A58x0AF 650W • Max input voltage range: power supply Power Supplies User 90 VAC to 264 VAC; 47 Hz or 63 Hz...
Page 53 Min power 0.87 W consumption Documentation HP A5830AF-48G Fan Trays (JC692A & JC693A) User Guide reference Front-to-back airflow fan tray (JC693A) (for the 48G model) Fans Four 40 × 40 × 28 mm (1.57 × 1.57 × 1.1 in) fans Max fan speed 9500 R.P.M...
Page 54 Table 14 A5830AF-48G interface card Card model Name Description Provides two 1-/10- Gbps SFP+ LSPM2SP2P(JD368B) 2-port 10 GE SFP+ optical interface card fiber ports For more information about the interface card, see HP LSPM2SP2P Interface Card User Guide.
Page 55 Appendix C Ports and LEDs Ports Console port Every switch has one console port. Table 15 Console port specifications Item Specification Connector type RJ-45 Compliant standard EIA/TIA-232 Transmission baud rate 9600 bps (default) to 115200 bps • Provides connection to an ASCII terminal. Services •...
Page 56 (nm) (μm) distance (MHz × km) 550 m (1804.46 50/125 500 m (1640.42 HP X120 1G SFP LC SX JD118B Transceiver 275 m (902.23 62.5/125 220 m (721.78 10 km (6.21 9/125 miles) HP X120 1G SFP LC LX 550 m (1804.46...
Page 57 9/125 1610 Transceiver miles) IMPORTANT: You must use the HP X120 1G SFP LC BX 10-U Transceiver (JD098B) and the HP X120 1G SFP LC BX 10-D Transceiver (JD099B) in pairs. Table 19 100 Mbps SFP transceiver modules Central Product...
Page 58 15 km (9.32 miles) BX 10-D Transceiver RX: 1310 IMPORTANT: You must use the HP X115 100M SFP LC BX 10-U Transceiver (JD100A) and the HP X115 100M SFP LC BX 10- D Transceiver (JD101A) in pairs. NOTE: • To guarantee the functionality of the SFP ports, use only HP SFP transceiver modules.
Page 59 • The SFP and SFP+ transceiver modules available for this switch series are subject to change over time. For the most up-to-date list of SFP transceiver modules, consult your HP sales representative or technical support engineer. HP A-Series Switches Transceiver Modules User Guide •...
Page 60 Availability SFP+ port LED Entire series Management Ethernet port LEDs Entire series Interface card status LED 48G model System status LED Every switch has a system status LED on both the front and rear panels. The two LEDs are the same and concurrently show the operating status of the switch.
Page 61 Table 26 SFP+ port LED description Port LED status Description The port is operating properly. The port LED fast flashes when the port is Steady green sending or receiving data. No link is present on the port. Management Ethernet port LEDs The switches have two management Ethernet port LEDs (LINK and ACT).
Page 62 Index chassis 10/100/1000 Base-T Ethernet port, 51 attaching mounting bracket and chassis rails to switch chassis (48G model), 7 port LED, 56 attaching mounting bracket and chassis rails to 650W switch chassis (96G model), 9 AC power supply, 21 connecting grounding cable to switch chassis (48G DC power supply, 21 model), 8 connecting grounding cable to switch chassis (96G...
Page 63 AC switch through PE wire, 15 port technical specifications, 51 cable (48G model rack mounting), 7 cable (96G model rack mounting), 9 contacting HP, 39 data bits (parameter), 25 connecting cable to switch chassis (48G model), 8 connecting cable to switch chassis (96G model),...
Page 64 icons used, 40 management Ethernet port technical specifications, subscription service, 39 mounting bracket, 4 support contact information, 39 port technical specifications, 51 symbols used, 40 power supply installation, 18 websites, 39 power supply removal, 18, 19 icons, 40 rack chassis rail installation (48G model), 7 identifying rack chassis rail installation (96G model), 9 IRF master switch, 31...
Page 65 planning IRF cabling scheme, 33 identifying master switch, 31 identifying physical ports on the member switches, rack mounting grounding cable installation (48G model), 7 planning cabling scheme, 33 rack mounting grounding cable installation (96G model), 9 planning connections, 32 no terminal display, 37 planning fabric setup, 31 parity (parameter), 25 planning member IDs, 31...
Page 66 fan tray, 16, 18 connecting console cable, 24 grounding AC powered switch through PE wire, 15 interface card, 22, 23 grounding switch with grounding strip, 15 power supply, 18, 19 identifying rack mounting position, 6 requirements installing fan tray, 17 installation site, 1 rack-mounting, 2 installing interface card, 22...
Page 67 port, 51 installation, 3 installing interface card, 22 SFP port, 52 IRF basic settings configuration, 35 SFP port LED, 56 planning IRF cabling scheme, 33 SFP+ port, 54 planning IRF connections, 32 SFP+ port LED, 56 switch (Appendix A), 42 planning IRF fabric setup, 31 planning IRF member IDs, 31 system status LED, 56...
