- Page 1 设 计 陈丽平 图号/物料编码 PART NO. 图纸名称 PART NAME DESIGN 2020.3.21 校 对 1XXXXXXX 宗培 CO.BY MIDEA新加坡 MDRC280FZG01-SG BD-199说明书 标准化 材料 MATERIAL STANDARD 80g双胶纸 业务 图样标记 版本号 重量(g) 比例 张兵 seller REV.NO. WEIGHT scale 批 准 AUTHORI 美的冰箱事业部 MIDEA REFRIGERATION DIVISION 共...
- Page 2 USER MANUAL CHEST FREEZER Please read the Manual carefully before use. The Manual shall be kept in good custody for later reference MODEL: MDRC280FZG01-SG www.midea.com...
-
Page 3: Table Of Contents
1 Safety warnings 1. 1 Warning · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·1-2 1.2 Meaning of safety warning symbols· · · · · · · · · · · · · · · · · 3 1.3 Electricity related warnings·... -
Page 4: Safety Warnings
1 Safety warnings 1.1 Warning Warning risk of fire / flammable materials THIS appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments;... - Page 5 REFRIGERANT and cyclopentane foaming material used for the appliance are flammable. Therefore, when the appliance is scrapped, it shall be kept away from any fire source and be recovered by a special recovering company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the environment or any other harm.
-
Page 6: Meaning Of Safety Warning Symbols
1.2 Meaning of safety warning symbols The symbols indicate prohibited matters, and those behaviors are forbidden. Non-compliance with the instructions may result in product damages or endanger the personal safety of users. Prohibition symbols The symbols indicate matters that must be followed, and those behaviors must be strictly executed in line with the operation requirements. -
Page 7: Related Warnings For Use
1.4 Related warnings for use Do not arbitrarily disassemble or reconstruct the freezer, nor damage the refrigerant circuit; maintenance of the appliance must be conducted by a specialist. Damaged power cord must be replaced by the manufacturer, its maintenance department or related professionals in order to avoid danger. -
Page 8: Warnings Related To Placing Items
1.5 Warnings related to placing items Do not put flammable, explosive, volatile and highly corrosive items in the freezer to prevent damages to the product or fire accidents. Do not place flammable items near the freezer to avoid fires. This product is household freezer and shall be only suitable for the storage of foods. -
Page 9: Names Of Components
Names of components Door handle(optional) Lamp(optional) Hinge Shelving basket Cabinet Power cord Shutter Drainage hole Temperature control panel ( The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor ) The low temperature of freezer may keep food fresh for a long time and it is mainly used to store frozen foods and making ice. -
Page 10: Temperature Control
Temperature Control Please electrify the chest freezer, the "POWER" lamp will shine(green light). Rotate the thermostat knob clockwise,the temperature inside chest freezer will be lower and lower. "COOLING " means cooling zone,"FREEZING--SUPER"means the freezing zone. When set the thermostat knob to "SUPER" position, the chest freezer enters into super freeze mode, during this mode the compressor keeps running without interruption. -
Page 11: Placement
2.3 Placement Before using the freezer, The freezer should be placed remove all packaging in a well-ventilated indoor materials including bottom place; the ground shall be flat, cushions and foam pads and sturdy . and tapes inside the freezer, tear off the protective film on the door and the freezer body. -
Page 12: Maintenance Of Freezer
3 Maintenance of freezer 3.1 Cleaning Dusts behind the freezer and on the ground shall be timely cleaned to improve the cooling effect and energy saving. Check the door gasket regularly to make sure there are no debris. Clean the door gasket with a soft cloth dampened with soapy water or diluted detergent. -
Page 13: Trouble Shooting
Trouble shooting The following simple issues can be handled by the user. Please call the after-sale service department if the issues are not settled. Whether the freezer is plugged and connected to power; Low voltage; Inoperation Whether temperature control knob is in the work area; Failure power or tripping circuit. - Page 14 make yourself at home...
