Summary of Contents for Midea MF411W
-
Page 1: User Manual
Upright Freezer USER MANUAL MF411W... -
Page 2: Table Of Contents
CONTENTS Safety information ........2-3 Identifying parts of the freezer ........4 Transporting ........5 Installation ........5-6 Control features and functions ........7-9 Cleaning & Maintenance ........9-10 Energy saving tips ........11 Disconnection of the appliance ........11 Troubleshooting Guide ........ -
Page 3: Safety Information
The appliance has not been designed or manufactured for professional use. Midea declines all responsibility for damage deriving from improper use of the appliance. The freezer has undergone the necessary tests on the tightness of the refrigeration circuit and complies with the safety regulations. -
Page 4: Safety Information
- Do not place objects on top of the appliance which are magnetic, heavy or filled with water. - If the supply cord is damaged, it must be replaced by authorised Midea service personal, service agent or similarly qualified persons in order to avoid a hazard. -
Page 5: Identifying Parts Of The Freezer
IDENTIFYING PARTS OF THE FREEZER Light switch Door bin Temperature sensor Wire door bin Wire shelf Kick panel Wire drawer... -
Page 6: Transporting
TRANSPORTING Keep the freezer upright and avoid squeezing or vibration during transport. Avoid a slanting angle over 45 degrees during handling. Avoid the door or top cap from being under excessive stress when moving, otherwise it may become deformed. Do not connect your freezer to the power supply immediately after it is placed vertically. - Page 7 INSTALLATION Door Handle assembly 1. Remove the hexagonal key and the two screws from the plastic bag supplied inside the freezer and set the screws into the door holes. hole screw Position the door handle over the screws. Tighten the head cap screws in the side of the handle until secured in place on the door.
-
Page 8: Control Features And Functions
CONTROL FEATURES AND FUNCTIONS Buttons Quick freeze Temperature display format (°C or °F) Alarm Reset Lock / Unlock Temperature setting / Quick Freeze time setting down (decrease) Temperature setting / Quick Freeze time setting up (increase) Display Numeric display panel Alarm High temperature alarm Door open alarm... - Page 9 CONTROL FEATURES AND FUNCTIONS Locking and unlocking the display panel To lock the control panel, hold down the Lock / Unlock button (4) for 3 seconds until the Lock icon displays, this indicates the freezer control panel is locked. To unlock the control panel, press the Lock / Unlock button (4) until the Lock icon no longer displays.
-
Page 10: Cleaning & Maintenance
CONTROL FEATURES AND FUNCTIONS Error Codes display The error codes listed below may appear on the display. Firstly press Alarm Reset and contact Midea Customer Care if the error code still displays after you have reset the alarm. ERROR CODE... - Page 11 CLEANING & MAINTENANCE Replacing the Interior light Before replacing the light: Turn appliance off at the power point, then remove the power cord from the outlet. This will make sure there is no chance of electric shock. WARNING To replace the internal light, follow these steps. Note: Before step 1 replacing the bulb, disconnect the appliance from the mains power.
-
Page 12: Energy Saving Tips
ENERGY SAVING TIPS Reduce opening the door frequently. This will increase the appliance efficien reduce power consumption. Be sure to wrap foods properly, and wipe containers dry before placing them in the freezer. This cuts down on frost build-up inside the freezer. There should always be some space between food items for proper air circulation. -
Page 13: Troubleshooting Guide
TROUBLESHOOTING GUIDE If you think so e ing may be wrong with your freezer, you can carry out some easy checks before m th calling for service. Y o u m y lo e th e problem and spare yourself from inconvenience, saving time and money. -
Page 14: Repairs, Service & Warranty
Please refer to the enclosed warranty card or visit www.mideaappliances.com.au for warranty information. Ensure you have the appliance model number and proof of purchase handy before calling Midea Customer Care to enquire about a warranty claim. Complete and retain the following information for your records: Model No. -
Page 15: Specifications
SPECIFICATIONS Model MF411W Climate class Classification of installation and Class 1 Indoor use only Rated Total Gross Volume 411L Voltage 220-240V / 50Hz Noise Level 44dB Refrigerant type R134a Height 1550mm Dimensions Width 711mm Depth 750mm IP rating IPX0 Net Weight...
