Type Plate - Binder KBF-S Operating Manual

Keep safety labels complete and legible.
Replace safety labels that are no longer legible. Contact BINDER Service for these replacements.
1.6

Type plate

The type plate sticks to the left side of the chamber, bottom right-hand.
Nominal temp. 70 °C
158 °F
IP protection 20
Safety device DIN 12880
Class 3.1
Art. No. 9020-0366
Project No.
Built 2021
Figure 3: Type plate (example KBF-S 240 regular chamber 9020-0366)
Nominal temp. 70 °C
158 °F
IP protection 20
Safety device DIN 12880
Class 3.1
Art. No. 9020-0367
Project No.
Built 2021
Figure 4: Type plate (example KBF-S 240-UL regular chamber 9020-0367)
Indications of the type plate (example)
Indication
BINDER
KBF-S 240
Constant climate chamber
Serial No.
Built
Nominal temperature
IP protection
Temp. safety device
Class
Art. No.
Project No.
1,40 kW
8,5 A
200-230 V / 50 Hz
200-230 V / 60 Hz
KBF-S / KBF-S-UL (E6) 11/2021
1,40 kW / 8,5 A
200-230 V / 50 Hz
200-230 V / 60 Hz
1 N ~
CONSTANT CLIMATE CHAMBER
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
1,40 kW / 8,5 A
200-240 V / 50 Hz
200-240 V / 60 Hz
2 ~
CONSTANT CLIMATE CHAMBER
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
Information
Manufacturer: BINDER GmbH
Model designation
Device name
00000000000000 Serial no. of the chamber
2021 Year of construction
70 °C / 158 °F Nominal temperature
20 IP type of protection acc. to standard EN 60529
Temperature safety device acc. to standard DIN
DIN 12880
12880:2007
3.1 Class of temperature safety device
9020-0366 Art. no. of the chamber
--- Optional: Special application acc. to project no.
Nominal power
Nominal current
Nominal voltage range +/-10%
at the indicated power frequency
Max. operating pressure 15 bar
R 134A – 0,27 kg
Contains fluorinated
greenhouse gases covered
by the Kyoto Protocol
KBF-S 240
E6
Serial No. 00000000000000
Made in Germany
Max. operating pressure 15 bar
R 134A – 0,27 kg
Contains fluorinated
greenhouse gases covered
by the Kyoto Protocol
KBF-S 240-UL
E6
Serial No. 00000000000000
Made in Germany
