UNDERMOUNTED RANGEHOODS
INSTRUCTION MANUAL
Installation / Operation / Maintenance
GA-600S
GA-900S
GA-1200S
Under our policy of continuous product
development, product specifications may
change without notice. Please refer to
the online version of the manual for the
latest updates and specifications.
Apr2022/ V1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-1200S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Schweigen GA-1200S

  • Page 1 UNDERMOUNTED RANGEHOODS INSTRUCTION MANUAL Installation / Operation / Maintenance GA-600S GA-900S GA-1200S Under our policy of continuous product development, product specifications may change without notice. Please refer to the online version of the manual for the latest updates and specifications.
  • Page 2 INDEX Welcome Important Safety Information Description Operation Cleaning and Maintenance Installation Condensation Information Troubleshooting Technical Specifications Disclaimer Page 2...
  • Page 3 WELCOME Thank you for purchasing this Schweigen IN appliance. IMPORTANT! To achieve the optimal performance from your The appliance should only be appliance, and to avoid the risk of accident or operated when you have read and damage, it is essential to read this manual before understood this manual thoroughly.
  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION Please read the instructions carefully. Only then Flames beneath the pan must be contained at all will you be able to operate your appliance safely times and cannot exceed the width of the pan in and correctly. Retain the instruction manual for use.
  • Page 5: Before Installation

    IMPORTANT SAFETY INFORMATION BEFORE INSTALLATION Schweigen will not be responsible for any installations executed by non-qualified technicians We recommend this appliance be installed or that fail to heed the applicable legislation on repaired by an experienced Home Appliances electrical safety.
  • Page 6: Product Use

    IMPORTANT SAFETY INFORMATION PRODUCT USE ELECTRICAL CORD This product is designed for household use and Ensure the supply cord is not exposed to heat, should not be used for commercial applications. chemicals or sharp objects. If the supply cord is damaged, it must be replaced by the manufacturer, After use, always ensure that all controls are in service agent or a similarly qualified person in order...
  • Page 7 DESCRIPTION For models GA-600S, GA-900S and GA-1200S 1. Socket lead to Isodrive motor ® 2. Main power cord 3. Single 200mm Outlet 4. Computer board* 5. Reducer 6. Filters (depending on model filters vary in size) 7. Lights 8. Instruction and screws pack...
  • Page 8: Operation

    OPERATION For models GA-600S, GA-900S and GA-1200S The rangehood has a 4-speed electronic keypad. Speed control usage suggestions: • Low speed for simmering. • Medium speed for light cooking. • High speeds are for heavy frying or heavy cooking. Electrical Tactile Keypad To obtain the best performance, switch the aspiration speed.
  • Page 9: Cleaning And Maintenance

    CLEANING AND MAINTENANCE WARNING Always switch off and disconnect power to the rangehood before cleaning. The manufacturer is exonerated from all responsibility in the event of fire due to poor maintenance of the filters and rangehood. Cleaning and user maintenance shall not be made by children without supervision. FILTERS the rangehood (removing the pins from the front guide), ease down slightly and remove.
  • Page 10: Cleaning The Interior

    CLEANING AND MAINTENANCE SURFACES Do not pour any liquid directly onto the rangehood, apply to a soft cloth first. The surface of the rangehood can be cleaned with The cloth must have no buttons, zips or fasteners warm soapy water and a soft sponge / cloth. that can scratch the surface.
  • Page 11: Replacing The Led Bulb

    CLEANING AND MAINTENANCE WARNING Always switch off and disconnect the power cord before replacing any lights. Failure to do so may cause serious injury. Please be aware that the LED light will retain heat for a short period of time after being switched off. Never attempt to replace the LED by yourself, always refer to a qualified Service Technician.
  • Page 12: Installation

    INSTALLATION RANGEHOOD SIZE VS COOKTOP SIZE In addition to the size, the height of the rangehood above the cooktop is important to obtain the best performance. INADEQUATE ADEQUATE OPTIMAL Rangehood smaller than Rangehood same size as Rangehood larger than cooking zone cooking zone cooking zone Page 12...
  • Page 13 INSTALLATION OVERHEAD CABINET RANGEHOOD INSTALLATION POSITION It is important to consider the benchtop and overhead cabinetry depth before installing the rangehood. The information below is to be used as a guide only, drawings are not to scale and do not account for all circumstances.
  • Page 14: Mounting Laws And Regulations

    Note: If the instructions for the gas cooktop specify a greater distance, this must be taken into account. RECOMMENDED INSTALLATION HEIGHT FOR INDUCTION COOKTOP To help avoid condensation, particular to cooking with an induction cooktop, Schweigen recommends a minimum height of 700mm. Refer to page 20 for further information.
  • Page 15 INSTALLATION NOTE GA-900S and GA-1200S have the same installation steps as GA-600S Installation for GA-600S Step 1 Cut the cabinetry to the correct size in order to fit the undermount, see figure on the right. NOTE: It is always best to use the rangehood as a cutting guide, not the cabinet cut out diagram as this is only a guide.
  • Page 16 INSTALLATION Step 4 Fix the undermount to the cabinetry with appropriate screws, using the pre-drill holes in the undermount body (C). Step 5 Once (D) has been firmly attached, fix the fascia (A) to the rangehood (D) the magnets (B) will hold the fascia in place.
  • Page 17 INSTALLATION Step 6 Re-attach the fascia by securing it with 4 x locking screws (E). Step 7 Re-install the filters. IMPORTANT Please ensure all plastic protection on the rangehood and filters are removed before use. Page 17...
  • Page 18 INSTALLATION Please DO NOT crush or kink the ducting. 1. Crushed or kinked ducting creates sharp corners that creates turbulence. This reduces the size and efficiency of the ducting, lowers extraction and may cause excessive noise. 2. Sweeping curves and taut ducting reduces resistance and turbulence.
  • Page 19: System Overview

    INSTALLATION SYSTEM OVERVIEW 1. Isodrive Motor ® 2. Roof Seal Kit (Dektite) (Not Supplied)* 3. Support Straps (Not Supplied)* 4. Attach Duct to Bell-Mouth Adaptor using ring clamp. Please DO NOT rip the ducting. 5. Isodrive Motor Power Lead (Plug) ®...
  • Page 20: Condensation Information

    CONDENSATION INFORMATION COOKING WITH INDUCTION How to reduce the possibility of condensation forming: COOKTOPS • Ensure the rangehood is installed by a qualified Cooking with an induction (or similar) cooktop, professional, carefully following the installation may produce condensation on the rangehood. guide.
  • Page 21: Troubleshooting

    TROUBLESHOOTING Before you contact the technical service department, make sure that the product IMPORTANT is plugged in and power is supplied. Never attempt to repair this • Do not take any action that will damage appliance by yourself. Always the product. refer to a qualified Service Technician.
  • Page 22: Faulty Installation

    0800 200 510 FAULTY INSTALLATION It is not the responsibility of Schweigen to rectify any incorrect installations. A service call out fee will be charged for any Schweigen technician that attends a call, whereby it is established that the fault is due to an incorrect installation or non-manufacturing fault.
  • Page 23: Technical Specifications

    TECHNICAL SPECIFICATIONS GA-600S 370,8 370,8 Ø199 CONFIDENT 370,8 28,1 28,1 254,4 39,8 190,4 39,8 28,1 254,4 254,4 28,1 Drawn by: D.IZQUIERDO Material: Drawn by: D.IZQUIERDO Code: Model: SCHWEIGWN Material: Thickness Description: Model: GA-600S Model: SCHWEIGWN Observations: Description: Feeding Voltage: 220-240V 50Hz Observations: Max Lamp Power: 2 x GLED Square 65 x 65mm Drawn by:...
  • Page 24 TECHNICAL SPECIFICATIONS GA-900S CONFIDENTIAL D. Izquierdo Drawn by: D. Izquierdo Drawn by: Material: Material: Model: GA-900S SCHWEIGEN Model: SCHWEIGEN Model: Drawn by: D. Izquierdo GA-900S Code: Feeding Voltage: 220-240V 50Hz Description: GA-900 GA-900 Description: Material: Thickness Weight: Qty. Max Lamp Power: 2 x GLED Square 65 x 65mm...
  • Page 25 TECHNICAL SPECIFICATIONS CONFIDENTIAL 1195 GA-1200S 1151 1150 Drawn b Materia D. Izquierdo GA-1200S Drawn by: Code: Model: Drawn Material: Thickness Weight: Qty. Descrip Mater SCHWEIGEN Model: Observa Model GA-1200 Description: 03/07/2020 Date: Sheet: Descr Observations: Rev. Scale: Obser Model: GA-1200S...
  • Page 26: Disposal Of Old Appliances

    All pictures used in own determination as to its suitability for their the guide are for illustrative purposes only. purpose/s prior to use. In no event will Schweigen Although our information and marketing states Home Appliances be responsible for damages of the term ‘Silent’...
  • Page 27 NOTES Page 27...
  • Page 28 © Schweigen Home Appliances Pty Ltd. Apr2022. Australia Unit 4/1-5 Lake Drive, Dingley Village, Victoria 3172 Phone: 1300 881 693 Email: sales@schweigen.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610 Phone: 0800 200 510 Email: info.parex@emerson.com www.schweigen.com.au...
