Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Wear
instruction
eye
manual
protection
1. SAFETY
i
Familiarise yourself with the application, limitations and potential hazards peculiar to the spray gun.
9
WARNING! Disconnect the spray gun from the air supply before changing accessories, servicing or performing any maintenance.
‰
Maintain the spray gun in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use authorised parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Keep the spray gun clean for best and safest performance.
9
Ensure that the compressed air system can supply the spray gun air consumption for the model to be used.
9
Wear approved safety respiratory protection and safety eye goggles.
9
I f spraying isocynate based finisher, wear approved respirator/clean air breathing apparatus and cover exposed skin with latex gloves
9
and impervious hooded coverall.
R emove ill-fitting clothing. Remove ties, watches, rings and other loose jewellery and tie back long hair.
9
L ocate the spray gun in a suitable work area. Keep area clean and tidy and free from unrelated materials and ensure that there is
9
adequate ventilation and lighting.
K eep children and unauthorised persons away from the work area.
9
W hen not in use, ensure that the air supply is turned off.
9
Avoid unintentional operation of spray gun.
9
T he spray gun has been treated with an anticorrosive agent at the factory and MUST be flushed out thoroughly with thinner before use.
9
DO NOT point spray gun at yourself, other persons or animals.
8
DO NOT direct air from the air hose at yourself, other persons or animals.
8
DO NOT carry the spray gun by the hose, or yank the hose from the air supply.
8
DO NOT exceed the working pressure of 43psi (3bar).
8
DO NOT use the spray gun for any purpose other than that for which it is designed.
8
DO NOT allow untrained persons to operate the spray gun.
8
DO NOT get the spray gun wet or use in damp or wet locations or in areas where there is condensation.
8
DO NOT operate the spray gun if any parts are missing or damaged as this may cause failure and/or personal injury.
8
When not in use, disconnect the spray gun from the air supply, clean thoroughly and store safely.
9
2.
INTRODUCTION
i
Gravity feed spray gun using standard pressure which creates a flat and smooth fan pattern ideal to get the best clear finishing coats. Air cap
engineered to provide 26psi of mist pressure for fast application and extended working distance. Greater efficiency than HVLP and less material
wastage than conventional spray guns. MVMP Technology and precision engineering delivers consistent and unrivalled results. Features air and
fluid flow controls for fine adjustment of spray pattern.
3. SPECIFICATION
Model no: ..................................................................... SP01
Standard set up: .......................................................... 1.4mm
Available set ups: ................................... 1.2, 1.3, 1.7, 1.8mm
Air pressure: ............................................................ 30-43psi
Air consumption: ......................................................... 9.5cfm
Pot capacity: ................................................................ 600ml
4. AIR SUPPLY
4.1.
RECOMMENDED HOOK-UP See fig.1
4.1.1.
Ensure spray gun air valve (or trigger) is in the off position before connecting to the air supply.
4.1.2.
You will require an air pressure of 43psi, and an air flow according to specification.
WARNING! Ensure the air supply is clean and does not exceed 43psi while operating the spray gun. Too high an air pressure and/or
‰
unclean air will shorten the product life due to excessive wear, and may be dangerous causing damage and/or personal injury.
4.1.3.
Drain the air tank daily. Water in the air line will ruin the paint finish and damage the spray gun.
4.1.4.
Clean air inlet filter weekly.
4.1.5.
Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter
should be 1/4" I.D. and fittings must have the same inside dimensions.
© Jack Sealey Limited
SP GRAVITY FEED SPRAY GUN 1.4MM SET-UP
MODEL NO:
Wear respiratory
Wear
protection
protective
gloves
Original Language Version
SP01
Wear
Wear
protective
protective
clothing
footwear
SP01 Issue 1 09/01/19
Advertisement
Related Manuals for Sealey Premier SP01
Summary of Contents for Sealey Premier SP01
- Page 1 SP01 MODEL NO: Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions, and properly maintained, give you years of trouble free performance. IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED.
- Page 2 Use the needle (paint) adjustment knob (fig.4.2) to adjust the amount of paint flow. The atomizing air flow is controlled by the control knob (fig.4.1). The volume of air input is controlled by the adjustment knob (fig.4.3). As width of spray is increased more material must pass through the gun to obtain the same coverage on the increased area. Turn the air nozzle (fig.4.4) to achieve a horizontal or vertical fan spray. Lock the nozzle with retaining ring (fig.4.5). The spray pattern of the gun is variable from round to flat with all patterns in between. In normal operation, the wings on the nozzle are horizontal (fig.5). This provides a vertical fan-shaped pattern which gives maximum, uniform and even coverage when moving the gun back and forth, parallel to the work surface (fig.6). fig.4 fig.3A fig.5 fig.6 fig.3B SP01 Issue 1 09/01/19 © Jack Sealey Limited Original Language Version...
- Page 3 Important: No Liability is accepted for incorrect use of this product. Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim. Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR 01284 757500 01284 703534 sales@sealey.co.uk...
