USER GUIDE
Cutout & Product Dimensions

PREPARE SITE

Your U-Line product has been designed for either free-
standing or built-in installation. When built-in, your unit
does not require additional air space for top, sides, or
rear. However, the front grille must NOT be obstructed,
and clearance is required for an electrical connection in
the rear.
CAUTION
!
Unit can NOT be installed behind a closed cabinet
door.
CUTOUT DIMENSIONS
Preferred location
for electrical outlet
is in an adjacent
cabinet.
24"
34"
(610 mm)
(864 mm)
PRODUCT DIMENSIONS
REAR
Power Cord
6 ft (183 cm)
Cutout & Product Dimensions
5⁄8"
(16 mm)
7"
(178 mm)
4" (102 mm)
15 3/16"
(386 mm)
7 ⁄ "
(187 mm)
1 ⁄ "
(35 mm)
FRONT
TOP
SIDE
8
u-line.com
14 ⁄ "
(379 mm)
28"
33 ⁄ "
(711 mm)
(855 mm)
3 ½"
(89 mm)
10 ⁄ "
(271 mm)
21 / "
(535 mm)
1 ⁄ "
(48 mm)
16"
(406 mm)
22 ⁄ "
(583 mm)
24 ⁄ "
(630 mm)
24 / "
(616 mm)
17 / "
(445 mm)
4"
(102 mm)
